Blackmagic Design DFR-8321-C-P OpenGear Frame, 21-Slot with Cooling Fans, Power Supply and Built-in Basic Networking Capabilities

About the Blackmagic Design DFR-8321-C-P

The DFR-8321-C-P OpenGear Frame from Blackmagic Design is a 21-slot, open-standards chassis that can be mounted in a rack for conversion and processing work. The chassis accepts different modules to enhance its functionality, allowing the solution to be expanded or scaled at will.

This model contains cooling fans, one power supply and built-in basic networking capabilities. One of the twenty-one slots is dedicated for the optional MFC-8320-N-P or MFC-8320-NS-P network controller cards. There is also an extra slot where a redundant PS-8300 power supply can be added.

The basic networking feature only allows setup and configuration within the frame. Many applications may require the MFC-8320-N-P network controller card for operation. Basic networking only allows one DashBoard application connection at a time.

DataSafe, slot renaming and SNMP are not supported on this model. It is also not possible to upload perimeters from a file or any other cards.
