Item Includes
Blackmagic Design Intensity Pro HDMI Editing Card - Software CD-ROM - Breakout Cable - Neoscene - Blackmagic Design 1 Year Warranty
|
Description
The Blackmagic Design Intensity Pro HDMI Editing Card is an excellent choice for your digital and analog capture needs. The card fully supports NTSC, PAL and HD video via HDMI, component, composite or S-Video. It supports two channels of embedded, RCA or S/PDIF audio at television-standard sampling rates. The Intensity Pro supports 4:2:2 color sampling for superior chromakey performance. The card can work with both Windows and Macintosh computers, making it an excellent choice for your editing needs regardless of your operating platform.
With Neo Scene you will convert your difficult-to-edit HDV, AVCHD, or Canon 5D Mk II camera footage to CineForm AVI or MOV files and then benefit from the same theatrical quality format and real-time editing performance as professionals. Feature films are shot and edited at 24 progressive frames per second (North America) or 25 (Europe / Japan) yielding the coveted "cinema look" you see in theaters. Neo Scene uniquely extracts 24p / 25p progressive frames from all your HDV or AVCHD material for editing in your favorite NLE. |
Features
 |
True HDMI Digital Connections: Intensity features HDMI-in for connecting to cameras and digital set-top boxes for the highest quality capture. Get higher quality capture from HD cameras by capturing direct and bypassing the HDV compression chip for high quality video captured |
|
Go Beyond HDV Video Quality: HDV video compression suffers from not being full 1920 HD resolution and the extra processing required makes editing difficult. With Intensity, you can now capture and play back full resolution HDTV uncompressed video for true broadcast and feature film quality editing |
|
Windows Compatible: Plug into Windows computers with the same card and use your favorite software, including Final Cut Pro, Premiere Pro, After Effects, Photoshop, Fusion and many more |
|
Professional Video Standards: Instantly switch between HD and SD video standards including HDTV 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, NTSC and PAL |
|
True 64 Bit PCI Express: Break the 2GB memory limit and add as much RAM to your system as you need, so your favorite video software renders faster and takes advantage of the latest high speed computers. Blackmagic Design features true 64 bit PCI Express so you're getting the latest technology. |
|
HDMI Quality: Unlike analog connections, HDMI is the new digital standard appearing in the latest cameras, televisions and video projectors. HDMI is fully digital and has no video compression, so it doesn't suffer from any image degradation. |
|
Neo Scene Files created: 10-bit CineForm Intermediate (4:2:2) with AVI (Windows) |
|
Neo Scene Spatial resolution: Up to 1920x1080. |
|
Neo Scene HD camera support: HDV, AVCHD, Canon 5D Mk II. |
|
Neo Scene Chroma Interpolation: 4:2:0 ? 4:2:2. Background: Most HDV and AVCHD camcorders record chroma (color) in a format known as 4:2:0. Without boring you with details, 4:2:0 chroma is half the color resolution of more professional 4:2:2 formats.. |
|
Neo Scene NLE Compatibility: Windows: Adobe Elements, Adobe CS3/CS4; Sony Vegas or Movie Studio |
|
Neo Scene File Compatibility: Because CineForm files use industry-standard AVI or MOV wrappers they are compatible with virtually any video application that supports standard interfaces, including from Adobe, Apple, Microsoft and Sony.. |
|
Neo Scene Image processing during conversion: Telecine removal (24p extraction from 60i), Deinterlacing (30p/25p from 60i/50i). |
Specifications
| Digital Video Input | 1 x HDMI input |
| Digital Video Output | 1 x HDMI output |
| Supported HDMI formats | 525 NTSC, 625 PAL, 720HD and 1080HD switchable |
| HDMI Audio Input | 2 Channels |
| HDMI Audio Output | 2 Channels |
| Analog Video Input | Component, NTSC, PAL or S-Video |
| Analog Video Output | Component, NTSC, PAL or S-Video |
| Analog Audio Input | 2 Channel RCA HiFi audio in 24 bit |
| Analog Audio Output | 2 Channel RCA HiFi audio in 24 bit |
| SPDIF Audio Output | 2 Channel 24 bit |
| Dual Rate support | HDMI and Analog Component switches between high definition and standard definition |
| Sync Input | No |
| Device Control | No; Use FireWire if capturing from HDMI cameras |
| Updates | Firmware for cards built into software driver
Loaded at system start, or via updater software |
| HD Format Support | 1080i50, 1080i59.94, 720p50 and 720p59.94 |
| SD Format Support | 625/25 PAL and 525/29.97 NTSC |
| HDMI Video Sampling | 4:2:2 |
| HDMI Color Precision | 4:2:2 |
| HDMI Color Space | YUV 4:2:2 |
| HDMI Audio Sampling | Television standard sample rate of 48 kHz and 24 bit |
| Card type | PCI Express 1 lane, compatible with 1,4,8 and 16 lane PCIe slots |
| Copy Protection | For legal reasons, capture devices from Blackmagic Design are designed not to capture, convert or transmit video or audio from copy-protected sources, e.g. video devices using HDCP |
| Colorspace Conversion | Hardware based real time |
| HD Down Conversion | Real time 1080HD and 720HD to standard definition during video playback
Real time standard definition to 1080HD and 720HD during video capture |
| Firmware Upgrade | Firmware for cards built into software driver
Loaded at system start, or via updater software |
| Installation | PCI Express 1 lane, compatible with 1, 4, 8, 16 lane PCI Express slots |
| Neo Scene Operating System | Windows XP / Vista; 32-bit or 64-bit |
| Neo Scene CPU | Min: Core 2 Duo 2GHz
Preferred: Core i7 |
| Neo Scene RAM | 3GB or greater |
| Neo Scene System Drive | 7200 rpm SATA (Capacity: User Preference) |
| Neo Scene Media Drive | Single SATA separate from OS |
| Neo Scene File Output | CineForm AVI |
| Neo Scene Chroma format | YUV 4:2:2 (4:2:0 sources interpolated to 4:2:2) |
| Neo Scene I/O Precision | 10-bit |
| Neo Scene Max resolution | 1920 x 1080 |
| Neo Scene Encoder Quality Controls | Three: User selectable |
| Neo Scene Video Formats (HD and SD) | 720p, 1080i/p |
| Neo Scene Frame Rates | 24p, 25p, 30p, 50i, 50p, 60i, 60p |
| Neo Scene HD camera sources | HDV, AVCHD, Canon 5D Mk II |
| Neo Scene NLE Compatibility | Adobe CS3/CS4
Sony Vegas, Movie Studio |
| Neo Scene CineForm file sizes | Variable based on image sizes and frame rates
1920x1080 24p approx 10 MB/sec or 35 GB/hour |
| Neo Scene Media Storage Recommendation | For best performance, it is recommended to use a separate mediate hard drive from your OS drive |
| Neo Scene Telecine removal | 24p frame extraction from 60i |
| Neo Scene Deinterlacing | 60i --> 30p and 50i --> 25p |
| Warranty | Blackmagic Design 1 year warranty |
| | |
|
