| SDI Video Input |
Switchable between SD, HD and 3 Gb/s SDI. |
| SDI Redundant Input |
None |
| SDI Video Outputs |
6 x outputs automatically match the SD, HD and 3 Gb/s SDI video input unless up, down, cross and/or standards conversion is enabled. |
| Optical Fiber Video Input |
None |
| Optical Fiber Video Output |
None |
| Multi Rate Support |
Auto detection of HD or standard definition SDI inputs. |
| Updates and Configuration |
Via USB 2.0 high speed. (480 Mb/s) |
| Re-clocking |
Yes |
| Optical Fiber Audio Input |
None |
| Optical Fiber Audio Output |
None |
| Analog Audio |
None |
| AES/EBU Digital Audio |
None |
| HDMI |
None |
| Analog Video |
None |
| Reference Input |
Blackburst and TriSync for SD & HD. |
| SDI Format Support |
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60. |
| SDI Compliance |
SMPTE 259M, SMPTE 292M, SMPTE 296M, ITU-R BT.656, ITU-R BT.601 and SMPTE 297M for Optical Fiber SDI. |
| SDI Video Sampling |
4:2:2 |
| SDI Video Rates |
SDI video connections are switchable between standard definition and high definition. |
| SDI Color Precision |
4:2:2 |
| SDI Color Space |
YUV |
| SDI Audio Sampling |
Television standard sample rate of 48 kHz and 24 bit. |
| SDI Auto Switching |
Automatically selects between SD SDI, HD-SDI and 3 Gb/s SDI. |
| Analog Format Support |
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60. |
| Analog Color Precision |
4:2:2 |
| Analog Color Space |
YUV |
| HDMI Format Support |
625/25 PAL, 525/29.97 NTSC, 625/50p PAL, 525/59.94p NTSC, 1080p23.98/24, 1080i50, 1080i59.94/60, 720p50 and 720p59.94/60. |
| HDMI Color Precision |
4:2:2 and 4:4:4 |
| HDMI Color Space |
YUV and RGB |
| Copy Protection |
For legal reasons HDMI input is unable to receive copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
| Format Conversion |
Up, down, cross conversion and/or NTSC/PAL standards conversion. |
| 110 Volt Power Consumption |
88 mA |
| 220 Volt Power Consumption |
47 mA |
| Software Control |
Mac OS X and Windows software upgrade via USB. |
| Settings Control |
Mini Switches or USB software. |
| Firmware Upgrade |
Via included firmware updater application. |
| Power Supply |
+12V universal power supply included with international socket adapters for all countries. Cable tie point. |
