Description
DV converter specialized for broadcast NLE... ADVC1000 is a professional, high-quality bidirectional SDI/DV video converter designed for use with broadcast studio equipment.
Featuring front-side controls and LCD display, analog video and unbalanced audio outputs for monitor preview, and a solid half 19-inch rack mount design, ADVC1000 is an ideal SDI in/out solution for any DV interface in a studio environment.
|
Features
 |
Canopus 's proprietary DV technologies provide the best picture quality preservation |
|
SDI and DV I/O - Digital audio I/O ( AES/EBU) Reference input |
|
Analog video and unbalanced audio output (for monitor preview) |
|
Quick configuration using front panel controls |
|
Front LCD panel for status and settings display |
|
9-pin serial port (AV/C-RS422 command convert function) |
|
Solid half 19-inch rack mount design |
|
NTSC and PAL compatible |
|
Windows and Mac OS compatible |
|
ADVC1000 converts DV device control signals to RS422, to control an external VTR |
|
Such control makes it possible to take in data from professional VTRs such as Digital BetaCam from any standard DV editing software that features DV device control. |
|
Reference input and LTC input/output can be utilized to create a professional video editing system with editors or switchers |
|
Reference Input |
|
LTC input/output |
|
Reciprocal TC conversions (LTC, VITC, DV TC) |
|
SDI supports up to four channels of embedded audio |
|
It transfers professional level video/audio signals and can connect to long distance transmission systems |
|
ADVC1000 has AES/EBU terminals to support MA operation with a professional audio mixer |
|
ADVC1000 is quickly configurable. Front panel controls include a mode switch and menu selection buttons with an LCD display for conversion settings. |
|
ADVC1000 can operate as a stand-alone device not requiring a computer while keeping any preprogrammed settings. |
Specifications
| Digital Video Input/Output (DV) | 1 x 4-pin FireWire
1 x 6-pin FireWire |
| Digital Video Input (SDI) | 2 x BNC (SDI and Active Through, SMPTE 259M-C) |
| Digital Video Output (SDI) | 2 x BNC (SDI, SMPTE 259M-C) |
| Analog Video Output (For monitoring | 1 x S - Video (4-pin miniDIN)
1 x composite video (RCA) |
| Digital Audio Input | SDI
Embedded audio (SMPTE 272M-A, 20-bit/48kHz, locked)
4-channel input support
For SDI
- DV (2ch): ch1/2 or ch3/4 (choose either)
For SDI
- DV (4ch): converts ch1 ch4 to 32kHz/12-bit/ch1 ch4
AES/EBU
> 2 x BNC (channel 1/2, channel 3/4)
32kHz, 44.1kHz, 48kHz, 16-bit, 20-bit, 24-bit unlocked/locked
DV
32kHz, 44.1kHz, 48KHz, 16bit, 2-channel unlocked/locked
32kHz, 12-bit, 4-channel unlocked/locked |
| Digital Audio Output | SDI
Embedded audio (SMPTE 272M-A, 20bit/48kHz, locked)
4-channel output support
For DV (48kHz/2-channel)
- SDI conversion, a copy of channel 1/2 is output to channel 3/4
AES/EBU
2 x BNC (channel 1/2, channel 3/4)
48kHz (locked) or AES input through
DV
48kHz, 16-bit, 2-channel locked
32kHz, 12-bit, 4-channel locked |
| Analog Audio Output (for Monitoring) | 2 x RCA (unbalanced)
Select output channel:
channel 1/2, channel 3/, channel 1+3/2+4 mix or 1+2+3+4 mix |
| Timecode | 1 x BNC LTC input
1 x BNC LTC output
VITC input (decoded from SDI input)
VITC output (encoded in SDI output, line selection available) |
| REF In | 2 x BNC B.B. input (input and loop thru, automatic 75 Ohm ON/OFF)
> SDI output available by REF sync |
| Device Control | 1 x D-SUB 9-pin (female) RS422A
AV/C - RS422A command conversion feature |
| Power | DC-12V, 1.2A (AC adapter) |
| Unit Dimensions | Width 215mm x Depth 240mm x Height 44mm |
| Service & Support | Three-year limited Canopus Warranty |
| | |
|
