| Projector Display System |
Single 0.65" DLP Technology by Texas Instruments |
| Native Resolution |
Native Resolution: XGA (1024 x 768) Max. Resolution: UXGA (1600 x 1200) Uniformity: 85% |
| Number of Pixels |
1024 x 768 = 786,432 |
| Brightness |
5200 Lumens (Typical) |
| Contrast Ratio |
2500:1 (Full On/Off) |
| Aspect Ratio |
4:3 Native, 16:9 Compatible |
| Colors |
1.07 Billion |
| Scan Rate |
Horizontal Scan Rate: 15, 30 to 90 KHz Vertical Scan Rate: 43 to 85 Hz |
| System |
NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I, M, N), SECAM (B, D, G,K, K1, L) |
| Computer Compatibility |
UXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized; VESA Standards; PC and Macintosh Compatible |
| Lens |
F=2.46 - 2.56, f=22.82 - 28.49mm |
| Focus/Zoom Adjusting |
1.25:1 Manual Zoom/Focus |
| Lens Shift |
Vertical: ±100%, Horizontal: -10% to +110% |
| Throw Ratio |
1.6 to 2.0:1 (Distance/Width) |
| Image Size |
37 to 215" (0.9 to 5.5 m) |
| Recommended Projection Size |
4.9 to 23' (1.5 to 7 m) |
| Keystone Correction |
±30deg. Vertical |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Projection Tilt Option |
Yes |
| Inputs/Outputs |
HDMI v1.3, DVI-D, VGA-In (x 2), VGA-Out, BNC, Component Video, S-Video, Composite Video, RCA Audio-In (x 2), Mini-jack Audio (x 3), 12V Trigger (x 2), RS-232c, RJ45, USB (Service Only) |
| Lamp (Bulb) |
2000/1500 Hours (Standard/Boost Mode), 380W UHP |
| Fan Noise |
37dB/33dB (Boost/Standard Mode) |
| Security |
Kensington Lock Port, Security Bar |
| Remote Control |
Yes |
| Power Requirements |
Supply: AC 100-240V, 50/60Hz Consumption: 335W (Standard Mode), 390W (Boost Mode), <1W (Standby) |
| Operating Temperature |
41 to 104deg.F (5 to 40deg.C) |
| Dimensions (W x H x D) |
17 x 7.1 x 13.5" (431 x 180 x 343mm) |
| Weight |
19 lb. (8.6kg) |
