| Magnification |
4x - 16x |
| Objective / Field of View |
44mm / 27.4' (8.4m) @ 4x at 100 yds.(100m), 7.4' (2.3m) @ 16x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
2.0" |
| Eyepiece Tube Diameter |
1.5" |
| Lens Coatings |
XR Anti-Reflective Fully Multi Coated Optics |
| Reticle |
Dead-Hold BDC |
| Reticle Image Plane (Magnifying) |
Second |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/4 MOA Per Click |
| Maximum Adjustment |
50 MOA W & E |
| Exit Pupil |
Not Specified by Manufacturer |
| Eye Relief |
4.0" / 101.6mm @ 2.5x, 4.0" / 101.6mm @ 10x |
| Parallax Correction Control |
50 Yards to Infinity with Side Parallax Adjust |
| Diopter Adjustment |
No Diopter Adjustment |
| Material |
Aluminum Alloy |
| Nitrogen Filled |
Argon Gas |
| Waterproof / Fogproof |
Yes |
| Length |
13.7", (348.0mm) |
| Mounting Length |
5.6" |
| Weight |
20.0 oz., 567.0g |
| Special Features |
Reticle Image in the Second Focal Plane. Argon Gas Purging. Side Parallax Adjust |
