| Input Type |
Color |
| Imaging sensor |
Dual Charge-Coupled Device (CCD) |
| Grayscale Depth (External) |
8-bit (256 gray levels) |
| Color Depth (External) |
24-bit (16.7 million colors) |
| Optical Resolution |
600 dpi |
| Scan Mode |
Single/duplex pass |
| Automatic Duplexing |
Yes |
| Scan Element Type |
Dual CCD |
| Max Document Scan Speed B/W |
40 ppm |
| Max Document Scan Speed Color |
40 ppm |
| Duty Cycle |
3000 scans per day |
| Scanner Speed Details |
80 ipm, duplex black&white (back) 200 dpi (back), 80 ipm, duplex color (back) 150 dpi (back), 40 ppm black&white (back) 200 dpi (back), 40 ppm color (back) 150 dpi (back) |
| Scanner Technology |
Visioneer OneTouch with Kofax VRS Technology |
| Compliant Standards |
TWAIN, ISIS, WIA |
| Max Document Size |
8.5 in x 14 in |
| Supported Document Type |
Plain paper |
| Supported Document Size Details |
ADF, up to 8.5 in x 38 in, Flatbed, up to Legal (8.5 in x 14 in) |
| Document Feeder Type |
Autoload |
| Feeder Capacity |
50 sheets |
| Interfaces |
1 x Hi-Speed USB, 4 pin USB Type B |
| ENERGY STAR Qualified |
Yes |
| Power Device |
Power adapter, external |
| Power Consumption (Standby) |
30 Watt ( 5 Watt ) |
| OS Required |
Microsoft Windows XP SP2, Microsoft Windows 7, Microsoft Windows Vista |
| System Requirements Details |
Windows XP SP2, Pentium 4, RAM 512 MB, HD 350 MB, Windows 7/Vista, Pentium 4, RAM 1GB, HD 350 MB |
| Dimensions (W x D x H) |
11.6 x 7.0 x 7.6" / 29.46 x 17.78 x 19.30 cm |
| Weight |
7.83 lbs / 3.55 kg |
