| Image device |
1/4" CMOS |
| Pixels |
310,000 |
| White Balance, Exposure, Gain |
Auto |
| Viewing angle |
Horizontal: 100°, Vertical: 75° |
| Focal length |
f=2.5mm |
| Aperture |
F2.0 |
| Image compression |
MPEG-4, MJPEG |
| Max. frame rate |
30fps @ 640×480 |
| Audio compression |
AMR(4.75 12.2Kbps), G.726 (40/32/24/16Kbps) |
| Built-in microphone |
Electret Condenser Microphone |
| Network Authentication |
2 levels, up to 64 users, 16 simultaneous |
| Network protocols |
TCP,UDP,IP,ARP,ICMP,DHCP,DNS,HTTP,FTP,SMTP,NTP,UPnP,DDNS |
| Stream type |
HTTP, RTSP/RTP/RTCP, 3GPP, ASF |
| Network connection |
Ethernet (10BASE-T/100BASE-TX) |
| Power over Ethernet (PoE) |
802.3af |
| Wireless |
Wireless technology: IEEE802.11b/g Frequency: 2.412-2.462GHz Transmission speed: Auto Switch up to 54Mbps Security: WEP (64/128 bit), WPA-PSK (AES/TKIP), WPA2-PSK (AES/TKIP) |
| External Ports |
Audio output (2 way audio): Yes SD slot: microSD card (16MB 8GB) Digital I/O: 1 input, 1 output |
| Minimum PC Requirements |
Operating system: Windows 2000/XP/Vista/Windows 7/Windows 7 Processor: Intel Pentium III, 1GHz Memory: 256MB RAM |
| Minimum Mac Requirements |
Operating system: Mac OSX 10.4 (Tiger) Processor: 800MHz PowerPC G4 or Intel Memory: 128MB RAM (256MB recommended) |
| Viewing System Requirements |
Web Browser Setup/Viewing Microsoft Internet Explorer version 5.5 or later, Mozilla Firefox, Google Chrome, Safari & most other browsers
Mobile Phone Viewing 3GPP player, VLC, Real Player, QuickTime and most other VLC players. Y-cam Mobile Live Images feed can be viewed via most internet enabled devices |
| Other Requirements |
Broadband connection with at least 128kb/s upload recommended for Internet viewing This Y-cam is for indoor use only. |
| General |
Power requirements: DC 12V Power consumption: 2.5W Operating temperature: -5 to +45 °C (+22 to +113 °F) Storage temperature: -20 to +60 °C (-4 to +140 °F) Operating humidity: 20-80%RH (Non-condensing) Storage humidity: 20-95%RH (Non-condensing) Dimensions (D x L): 3.5 x 3.5 x 3.5" / 90 x 90 x 90mm Weight: 5.6 oz / 160g |
