Yamaha

Yamaha 3 Input USB Computer-Based Recording System, 2 Output USB Interface, 16-bit Converters

SKU: YMAUDIOGRAM3 MFR: AUDIOGRAM3
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$149.00 List Price

Our Price

$99.99 $4 per week
Free Expedited Shipping
Qty:
Add to Wishlist

About this item

The Yamaha 3 Input USB Computer-Based Recording System is a computer-based recording system that is easy to set-up and use. The system is a complete kit and bundles together a hardware interface that provides the audio inputs and outputs to the computer, software for recording and producing music and a USB cable for connecting the audio interface to the computer.

With a focus on simplicity and ease-of-use, the compact audio interface features both a mono and stereo input channel. Providing maximum flexibility for recording from almost any audio source, the mono input channel features a combo-type connector that can be set for microphone or line level input, while the stereo channel has both phone and RCA connectors.

The Yamaha USB Computer-Based Recording System is USB bus-powered and does not need an external power supply, making it an ideal solution for mobile applications.

What's Included With This Item

  • Yamaha 3 Input USB Computer-Based Recording System
  • USB Cable
  • Cubase AI DVD-ROM
  • Yamaha Warranty

Summary of Customer Reviews

(1)
Customers most agreed on the following attributes:
Reviewer Profile:
Experienced (1)

Key Features

  • Streamlined Audio Interface: With a focus on simplicity and ease-of-use, the AUDIOGRAM3 delivers a compact audio interface complete with both a mono and stereo input channel
  • High-Quality Microphone Preamp: Also supporting microphone-level input, the AUDIOGRAM3 mono channel features a microphone preamp offering excellent audio quality. And should you want to connect a condenser microphone for higher-quality recordings, this channel can even be phantom powered
  • Direct Connection of Electric Guitars and Basses: With one touch of the MIC/INST select button, you can set the sensitivity of the AUDIOGRAM3 mono channel for direct connection of either microphones or instruments
  • Stereo Channel For Practically All Sound Input Devices: With the AUDIOGRAM3, you also get a stereo input channel with both phone and RCA pin connectors that can be used to conveniently connect not only synthesizers, portable keyboards and electronic pianos

Technical Specs

Sampling Frequency Rate USB AUDIO 1.1, 16bit/44.1kHz
Connectivity Headphones: Stereo Phone connector x 1
Microphone: Mic/Hi-Z input x 1
Line Out: Phone connector x 2 (L, R)
USB to HOST: USB (TO HOST)
LINE IN: Phone connector x 2, RCA connector x 2 (Parallel)
Power Supply USB powered
System Requirements-1 Windows: PC: Windows-based computer with built-in USB interface Windows-based computer with built-in USB interface
CPU: 1 GHz or better Intel Core / Pentium / Celeron processor 750 MHz or better Intel Core / Pentium / Celeron processor
Support OS: Windows Vista / Windows XP Professional / XP Home Edition
Memory: More than 1 GB More than 128 MB
System Requirements-2 Macintosh: PC: Macintosh computer with built-in USB interface
CPU: Intel CPU / Macintosh G3 processor 300 MHz or better
Support OS: Mac OS X 10.3.3 or higher
Memory: More than 128 MB
Types: Dynamic No
