| Wireless LAN standards |
IEEE 802.11n, IEEE 802.11b/g |
| Interfaces |
1 X RJ45, 10/100 Mbps port for wired WAN interface 1 X RJ45, 10/100 Mbps port for wired LAN networking 1 X USB 2.0 Host for 3G/4G modem or tethered smartphone WPS button, reset button |
| Wireless LAN security |
64/128 bits WEP (Wired Equivalent Privacy) WPA (WiFi Protected Access) and WPA2 SSID stealth; WPS for easy security setup |
| Internet security |
Stateful Packet Inspection (SPI) Firewall Network Address Translation (NAT) Denial of Service (DoS) attack detection Virtual Private Networking (PPTP, L2TP, IPSec) pass through MAC, Packet and Domain name filtering URL Blocking |
| Management |
Universal Plug and Play (UPnP) Browser based management Wizard-assisted setup Simple Network Management Protocol (SNMP) support |
| Advanced router functions |
Quality of Service (QoS) support URL Blocking/Filtering (parental control) Scheduling rules (parental control) Virtual Server, Port triggering and DMZ host Dynamic DNS Configuration Backup/Restore Wireless Distribution System (WDS) support Wireless Multimedia Extension (WME), WiFi Multimedia (WMM) support |
| Supported WAN protocols |
3G; 4G LTE; Static IP Address; Dynamic IP Address; PPP over Ethernet; PPTP WAN type; L2TP WAN type |
| Antenna |
One external antenna with pivoting position adjustment |
| Power adapter output |
5 Volts, 2.0 Amps |
| Transmission rates |
Maximum physical rate of up to 150 Mbps in 802.11n mode; 6/9/11/12/18/24/36/48/54 Mbps in 802.11g mode; 1/2/5.5/11 Mbps in 802.11b mode |
| Range coverage |
Indoors: Up to 100 meters (330 feet), depending upon the environment Outdoors: Up to 300 meters (990 feet), depending upon the environment |
| LED status indicators |
Four indicators, reporting: 3G/4G WAN connection established, data being transferred, device status LAN connection using Ethernet, data being transferred Wireless LAN connection available, data being transferred Wired WAN interface connection established, data being transferred |
| Wireless LAN channels frequency range |
United States (FCC) channel 1 through 11 Europe (ETSI) channel 1 through 13 |
| Dimensions |
5 x 5.13 x 1.25" / 12.1 x 13 x 3.2 cm |
| Weight |
8.2 oz / 232.46 g |
