ZyXEL USG100: Picture 1 regular $94.99

About ZyXEL USG100

The ZyWALL SSL2TO5USG100 is a Unified Security Gateway, integrated with complete, enterprise-level and advanced security solutions designed for Small/Medium Business (SMB) recommended for up to 25 PC users. Its flexible configuration helps network administrators set up the network and enforce security policies more efficiently.

It also provides bandwidth management, for QoS of VoIP or mission critical applications, Multiple-WAN Failover and Load Balancing. Moreover, IPSec VPN and SSL VPN design for telecommuters and home workers can access data more easily and safely at home. Remote access with SSL VPN requires only a standard web browser. ZyWALL USG 100's excellent throughput is the key to implement features of an enterprise level to provide a full-time, non-stop and secure service.

ZyXEL USG100 Features

  • The ICSA-certified, stateful inspection firewall protects the network and vital Internet services like e-mail, Web browsing, servers and file transfers
  • For protection against viruses and spyware, choose the ICSA-certified ZyXEL Anti-Virus or one powered by Kaspersky Labs
  • The IDP engine protects your network from intrusions such as Trojans and worms
  • Use IPSec VPN to secure connections to branch offices, partners and headquarters. Road warriors and telecommuters can use SSL or L2TP VPN to securely access the company network without having to install VPN software
  • Application Patrol controls who can use what IM and P2P applications like MSN and BitTorrent and even who can use specific features within an application
  • The anti-spam feature can tag or discard unsolicited commercial or junk e-mail
  • User-aware configuration lets you control access to applications or resources and apply security scans by user or user group
  • Bandwidth management lets you prioritize time-sensitive applications like VoIP and video conferencing
  • Multiple WAN ports let you use multiple ISP links and load balancing to enhance traffic. Throughput, optimize bandwidth usage and help ensure continuous uptime if a link goes down
  • Along with your regular user name and password, use the ZyWALL OTP (One Time Password). hardware token* to generate a new PIN code each time you log in
  • Use the extension card slot and USB ports for multiple 3G wireless WAN connections

ZyXEL USG100 Specifications

Clientless Secure Remote Access(Reverse Proxy Mode)
SecuExtender (Full Tunnel Mode)
A Unified Policy Enforcement
Supports Two-factor Authentication
Customizable User Portal
User Licenses
Routing Mode/Bridge Mode/Mixed Mode
Layer 2 Port Grouping
Tagged VLAN (802.1Q)
Virtual Interface (Alias Interface)
Policy-Based Routing (User-Aware)
Policy-Based NAT (SNAT/DNAT)
RIP v1/v2
IP Multicasting (IGMP v1/v2)
DHCP Client/Server/Relay
Built-in DNS Server
Dynamic DNS
Internal User Database
Microsoft Windows Active Directory
External LDAP/RADIUS User Database
ZyWALL OTP (One Time Password)
Forced User Authentication (Transparent Authentication)
System Management 1
Role-Based Administration
Multiple Administrator Login
Multi-Lingual Web GUI (HTTPS/HTTP)
Object-Based Configuration
Command Line Interface (Console/Web Console/SSH/TELNET)
Comprehensive Local Logging
Syslog (send to up to 4 servers)
E-mail Alert (send to up to 2 servers)
System Management 2
Real-Time Traffic Monitoring
System Configuration Rollback
Text-Based Configuration File
Firmware upgrade via FTP/FTP-TLS/Web GUI
Advanced Reporting (Vantage Report)
Centralized Network Management (Vantage CNM)
3G Support
Advanced Wireless Security Transmission with WEP Encryption and WPA/WPA2 Support
PCMCIA: Sierra Wireless AC850
USB: Huawei E220
ICSA Certified Firewall
ICSA Certified IPSec VPN
ICSA Certified Anti-Virus
Standards Compliance
HSF (Hazardous Substance Free): RoHS and WEEE
EMC: FCC Part 15 Class B, CE-EMC Class B, C-Tick Class B, VCCI Class B
Safety: CSA International (ANS/UL60950-1,CSA60950-1, EN60950-1, IEC60950-1)
Memory size
256 MB DDR2 RAM/256 MB Flash
GbE x 7 (RJ-45 with)
Auto-negotiation and Auto MDI/MDI-X
RS-232 (DB9F)
RS-232 (DB9M)
LED Indicator
Reset Button
Expansion Card Slot
USB Ports
Power Requirements
Input: 100 - 240 V; 1.2 A, 50 - 60 Hz
Output: 12 V; 3.5 A
Operating temperature
0deg.C - 50deg.C/32deg.F - 122deg.F
Storage temperature
-30deg.C - 60deg.C/-22deg.F - 140deg.F
Operating humidity
5% - 90% (noncondensing)
Dimensions (W x D x H)
242 x 175 x 35.5 mm/9.5 x 6.9 x 1.4 in
1.2 Kg/2.6 lbs
Mfr #

ZyXEL USG100 Reviews Powered by TurnTo®

Reviewed by 1 customers


Excellent Value, Excellent Features


This is a powerful security appliance. Perfect for small / medium business use. Features contained inthis product can be found in the Cisco networking line for thousands of dollars more. I have installed three of these for client use and they have been rock solid. Interface is intiuitive once you get to understand their object based methods of configuration. Excellent security subscription service you can snap in to further protect your network from intrusions, spam, viruses and harmful websites! This product is not for the novice technical person.
