ZyXEL ZyWALL USG1000 iCard Internet Security Gateway with SSL VPN 5 to 25 Tunnel Upgrade License

SKU: ZYSU525U1000 MFR: SSL5TO25USG1000

About ZyXEL USG1000

ZyWALL USG 1000 (SSL5TO25USG1000) is a Unified Security Gateway engineered to provide a variety of security services on top of a robust, hardware-accelerated platform. By integrating both IPSec VPN and SSL VPN technologies, the ZyWALL USG 1000 allows organizations to establish Virtual Private Network (VPN) connections amongst multiple locations such as remote branch offices, business partner sites and even a remote teleworker getting connected in a potentially unsafe hotel hotspot.

Communication channels are securely encrypted so that information leakage / data theft can be mitigated when transmitting confidential information over insecure networks, such as the Internet. The Hub and Spoke VPN feature is capable of reducing policy management overhead dramatically in a complex, multi-site corporate network infrastructure.

ZyXEL USG1000 Features

  • Comprehensive threat protection with firewall, VPN, anti-virus, content filtering, anti-spam, Intrusion detection and prevention to secure front line threats
  • IM/P2P management can prevent P2P or Instant Messaging applications to increase productivity
  • Flexible security zone using VLAN technology to segregate local networks
  • User-aware policy engine can set bandwidth or network access based on user login
  • Bandwidth management for traffic prioritization for VoIP or mission critical applications
  • Network resilience with multiple WANs, 3G cellular support and device high availability

ZyXEL USG1000 Specifications

No of users
5-25 Users
SPI Firewall Throughput
IPSec VPN (AES) Throughput
Maximum Concurrent NAT Sessions
Maximum IPSec VPN Tunnels
Maximum SSL VPN Tunnels
New Session Rate
13000 (sessions/sec)
Clientless Secure Remote Access (Reverse Proxy Mode)
SecuExtender (Full Tunnel Mode)
Unified Policy Enforcement
Supports Two Factor Authentication
Customizable User Portal
Routing Mode / Bridge Mode / Mixed Mode
Layer 2 Port Grouping
Ethernet / PPPoE / PPTP
Tagged VLAN (802.1Q)
Virtual Interface (Alias Interface)
Policy-Based Routing (User-Aware)
Policy-Based NAT (SNAT / DNAT)
RIP v1 / v2
IP Multicasting (IGMP v1 / v2)
DHCP Client / Server / Relay
Built-in DNS Server
Dynamic DNS
Bandwidth Management
Bandwidth Priority
Policy-Based Traffic Shaping
Maximum / Guaranteed Bandwidth
Bandwidth Borrowing
Internal User Database
Microsoft Windows Active Directory
External LDAP / RADIUS User Database
ZyWALL OTP (One Time Password)
Force User Authentication (Transparent Authentication)
High Availability
Device HA (Active-Passive Mode)
Device Failure Detection
Link Monitoring
Auto-Sync Configurations
Multiple WAN Load Balancing
VPN HA (Redundant Remote VPN Gateways)
System Management 1
Role-Based Administration
Simultaneous Administrative Logins
Multi-Lingual Web GUI (HTTPS / HTTP)
Object-Based Configuration
Command Line Interface (Console / WebConsole / SSH / TELNET)
Comprehensive Local Logging
System Management 2
Syslog (4 Servers)
E-mail Alert (2 Servers)
Real-Time Traffic Monitoring
System Configuration Rollback
Text-Based Configuration File
Firmware upgrade via FTP / FTP-TLS / WebGUI
Advanced Reporting (Vantage Report 3.1 Patch 1)
Centralized Network Management (Vantage CNM 3.0)
1GB RAM / 256MB Flash
GbE x 5 (RJ-45, with LED)
Auto-Negotiation and Auto MDI/MDI-X
RS-232 (DB9F)
RS-232 (DB9M)
LED Indicator
Power Switch
Reset Pinhole
Extension Card Slot
Yes (1)
Yes (2)
Optional HDD
Yes (IDE, 2.5")
Rack Mountable
Yes (19-inch, rack-mount kit included)
Input Voltage
100-240VAC, 50/60Hz, 1A Max
Power Rating
80W Max
Operating Temperature
0deg.C - 40deg.C
Storage Temperature
-30deg.C - 60deg.C
5% - 90% (non-condensing)
Standard Compliance
HSF (Hazardous Substance Free): RoHS and WEEE
EMC: FCC Part 15 Class A, CE-EMC Class A, C-Tick Class A, VCCI Class A
Safety: CSA International (ANS/UL60950-1, CSA60950-1, EN60950-1, IEC60950-1)
Dimension (W x D x H)
430.7 x 292.0 x 43.5 mm / 16.92" x 11.49" x 1.71"
4700 g / 165.78 oz
