| Type | Digital AF/AE SLR with built-in flash |
| Recording Medium | CompactFlash (CF) Card Type I & II |
| Image Format | 0.87 x 0.58 in./22.2 x 14.8mm (APS-C size sensor) |
| Compatible Lenses | Canon EF Lenses including EF-S Lenses (Focal length conversion factor: Equivalent to approx. 1.6x indicated focal length compared to 35mm format) |
| Lens Mount | Canon EF mount |
| Image Sensor Type | High-sensitivity, high-resolution, single-plate CMOS sensor |
| Pixels/Total Pixels | Approx. 10.10 megapixels/Approx. 10.50 megapixels |
| Aspect Ratio | 3:2 (Horizontal : Vertical) |
| Color Filter System | RGB primary color filters |
| Low-pass Filter | Fixed position in front of the CMOS image sensor |
| Recording Format | JPEG, RAW, and RAW+JPEG simultaneous recording provided.
The RAW and JPEG imagesare saved as separate files in the CF card. |
| Image Format | JPEG and RAW (CR2) |
| File Size | (1) Large/Fine: Approx. 3.8MB (3,888 x 2,592)
(2) Large/Normal: Approx. 2.0MB (3,888 x 2,592)
(3) Medium/Fine: Approx. 2.3MB (2,816 x 1,880)
(4) Medium/Normal: Approx. 1.2MB (2,816 x 1,880)
(5) Small/Fine: Approx. 1.3MB (1,936 x 1,288)
(6) Small/Normal: Approx. 0.7MB (1,936 x 1,288)
(7) RAW: Approx.9.8MB (3,888 x 2,592) |
| Folders | Automatic folder creation;
up to 9,999 images per folder
(new folder created when the file number reaches 9999) |
| File Numbering |
(1) Continuous numbering
(2) Auto reset
(3) Manual reset (the image numbering isreset to 0001, a new folder is created where subsequent images are saved) |
| Interface | USB 2.0 Hi-Speed, mini-B port. NTSC/PAL for video output |
| White Balance Settings | Auto, Preset (Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash), Manual (Custom, or user-set Color Temperature)
Auto white balance with the image sensor
Color Temperature Compensation: White balance bracketing: +/- stops in 1-stop increments
White balance correction: blue/amber bias +/- 9 levels, magenta/green bias +/- 9 levels |
| Viewfinder Type | Eye-level SLR with pentamirror |
| Coverage | Approx. 95% vertically and horizontally |
| Magnification | 0.8x (-1 diopter with 50mm lens at infinity) |
| Eyepoint | Approx. 21mm |
| Dioptric Adjustment Correction | -3.0 - +1.0 diopters |
| Mirror | Quick-return half mirror (Transmission: reflection ratio of 40:60) |
| Viewfinder Information | AF (AF points, focus confirmation light), Exposure (shutter speed, aperture, exposure level, AE lock, exposure compensation, AEB level, bulb), Flash (flash ready, red-eye reduction lamp on, high-speed sync, FE lock, FEB shooting, flash exposure compensation, insufficient flash warning during FE lock), White balancecorrection, Maximum burst, CF card full warning, CF card error warning, No CF card warning |
| Depth-of-Field Preview | Enabled with depth-of-field preview button (with Speedlite 580EX, 430EX, MR-14EXor MT-24EX; pressing the depth-of-field preview button fires a modeling flash) |
| Eyepiece Shutter | None (eyepiece cover provided on strap) |
| Autofocus Type | TTL-CT-SIR with AF-dedicated CMOS sensor |
| AF Points | 9 AF points |
| AF Working Range | EV -0.5-18 (ISO 100 at 73°F/23°C) |
| Focusing Modes | Autofocus: One-Shot AF, Predictive AI Servo AF, AI Focus AF (automatic switching between One-Shot/Predictive AI Servo AF); Manual Focus (MF) |
| AF Point Selection | Automatic selection, Manual AF point selection |
| Selected AF Point Display | Superimposed on viewfinder and LCD monitor |
| AF-assist Beam | Intermittent firing of built-in flash (Emitted automatically when necessary under low light, and linked to all 9 AF points. Not emitted in the Landscape, Sports and Flash OFF modes) |
| Exposure Control: Metering Modes | Max. aperture TTL metering with 35-zone SPC
(1) Evaluative metering (linked to all AF points)
(2) Partial metering (approx. 9% at center of viewfinder)
(3) Center-weighted average metering |
| Metering Range | EV 1-20 (ISO 100 at 73°F/23°C with EF 50mm f/1.4 USM lens) |
| Exposure Control Systems | Program AE (shiftable), Shutter-priority AE, Aperture-priority AE, Auto Depth-of-field AE (non-shiftable), Full auto (Program AE, non-shiftable), Programmed image control modes, Manual exposure (including bulb), E-TTL II autoflash program AE |
| ISO Speed Range | Basic Zone: automatically set by the camera
Creative Zone: equivalent to ISO 100-1,600 |
| Exposure Compensation | (1) User-set with multi-controller
(2) AEB (Auto Exposure Bracketing)
Bracketing range: +/- 2 stops in 1/3- or 1/2-stop increments |
| AE Lock | Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved
User-set: Applied with AE lock button |
| Shutter Type | Vertical-travel, mechanical, focal-plane shutter with all speeds electronically controlled |
| Shutter Speeds | 1/4000 to 30 sec. (1/3- and 1/2-stop increments), X-sync at 1/200 sec. |
| Shutter Release | Soft-touch electromagnetic release |
| Self-timer | 10 sec. delay, 2 sec. delay with C.Fn-7-1 (mirror lockup) |
| Remote Control | Remote control with Remote Switch RS-60E3 or Wireless Remote Controllers RC-1/RC-5 |
| Built-in Flash/Type | Auto pop-up, retractable, built-in flash in the pentaprism |
| Guide Number | 43 ft./13m (ISO 100) |
| Recycling Time | Approx. 3 sec. |
| Flash-ready Indicator | Flash-ready indicator lights on in viewfinder |
| Flash Coverage | Up to 17mm focal length (equivalent to 27mm in 35mm format)
Flash Exposure Compensation: +/-2 stops in 1/3- and 1/2-stop increments |
| EOS External Flash/Dedicated Speedlights | E-TTL II autoflash with EX Series Speedlites
PC Terminal Provided; not sensitive to flash polarity |
| Drive Modes | (1) Single, (2) Continuous, (3) Self-timer/Remote Control |
| Continuous Shooting Speed | Approx. 3 fps (at shutter speed of 1/250 sec. or faster) |
| Max. Burst During Continuous Shooting | JPEG: approx. 27 frames (Large/Fine)
RAW: approx. 10 frames
RAW+JPEG: approx. 8 frames (Large/Fine) |
| LCD Monitor Type | TFT Color, Liquid-Crystal Monitor |
| Screen Monitor size | 2.5" diagonal with a viewing angle of approx. 160° vertically and horizontally |
| Pixels | Approx. 230,000 pixels (Displayed pixels) |
| Coverage | Approx. 100% |
| Brightness Control | 7 levels provided |
| Playback Image Display Format | Single image, 9-image index, Magnified zoom (approx. 1.5x to 10x), Auto play, Auto review right after shooting, Histogram, Rotate, Jump |
| Highlight Alert | In the single image (INFO) display mode, the highlight portions containing no image information will blink |
| Protection | A single image can be protected or unprotected |
| Erase | A single image or all images stored in a CompactFlash (CF) card can be erased if theyare unprotected
Direct Printing from the Camera : Enabled with the Print/Share button
Compatible Printers: CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge compatible printers (via USB Interface Cable IFC-400PCU)
Settings: Print quantity, style (image, paper size, borders, date), trimming |
| Menu Categories | Shooting menu: red
Playback menu: blue
Setup menu: yellow |
| LCD Monitor Language | 15 languages provided (English, German, French, Dutch, Danish, Finnish, Italian,Norwegian, Swedish, Spanish, Russian, Simplified Chinese, Traditional Chinese, Korean, Japanese) |
| Firmware Update | Enabled by the user |
| Battery Power | One Battery Pack NB-2LH
Number of Shots: Approx. 500 (73°F/23°C, flash off), approx. 370 (32°F/0°C, flash off)
The above figures comply with CIPA testing standards and apply when a fully-charged Battery Pack NB-2LH is used.
Battery Check: Automatic
Power Saving: provided; power turns off after set time of 30 sec., 1, 2, 4, 8, 15 min. or off
Back-up Battery: One CR2016 Lithium Battery |
| Dimensions (W x H x D) | 4.98" x 3.71" x 2.56" / 126.5 x 94.2 x 65mm |
| Weight | 18 oz./510g (body only) |
| Operating Temperature Range | 32-104° F/0-40° C |
| Operating Humidity Range | 85% or less |
| Other |
Dust Delete Feature:
(1) Auto Sensor Cleaning
(2) Dust Delete Data
(3) Manual Sensor Cleaning
Picture Style: Six preset Picture Style settings plus three user-defined custom Picture style settings with individual adjustments for Sharpness, Contrast, Color saturation, 2nd Color tone; Filter effect, Toning effect for black & white images |
| Note | Included Zoom Lens Specifications:
Focal Length & Maximum Aperture - 18-55mm 1:3.5-5.6
Lens Construction - 11 elements in 9 groups
Diagonal Angle of View - 75° 20' - 27° 50'
Focus Adjustment - Inner focusing system with MM
Closest Focusing Distance - 0.28m / 0.92 ft. to infinity
Zoom System - Rotating Type
Filter Size - 58mm
Max. Diameter x Length, Weight - 2.7" x 2.6", 6.07oz. / 69mm x 66.2mm, 190g |
| | |
