| Scanner Type |
Flatbed color image scanner |
| Photoelectric Device |
Color Epson Matrix CCD line sensor |
| Optical Resolution |
3200 dpi |
| Hardware Resolution |
3200 x 9600 dpi |
| Maximum Resolution |
12,800 x 12,800 dpi |
| Effective Pixels |
27,200 x 37,440 (3200 dpi) |
| Color Hardware Bit Depth |
48-bit internal/external |
| Grayscale Hardware Bit Depth |
16-bit internal/external |
| Optical Density |
3.2 Dmax |
| Transparency Unit |
35mm Transparency Adapter, 6 negatives/4 slide capacity |
| Buttons |
4 buttons; Scan, E-mail, Copy and PDF |
| Maximum Read Area |
8.5" x 11.7" (216 x 297mm) |
| Light Source |
White cold cathode flourescent lamp |
| Interface |
Hi-Speed USB 2.0 |
| Scanning Speed |
3200 dpi high-speed mode Monochrome: 14.6 msec/line: Full color: 14.6 msec/line |
| Reliability |
MCBF - 10,000 cycles |
| Environment Conditions |
Temperature: Operating 410 F to 950 F,(50 to 350C): Humidity Operating: 10° to 80°,storage 10° to 85° (no condensation) |
| Power Requirements |
Voltage: AC100 - 120V, Frequency: 50 - 60hz, Power Consumption: 16W |
| Windows Requirements |
IBM compatible PC with Pentium II 450 MHz or higher processor USB 1.1 - Windows 98SE, 2000 Professional, Me, XP Home Edition/XP Professional, XP Professional x64 Edition Hi-Speed USB 2.0 - Windows 2000 Professional, XP Home Edition/XP Professional, XP Professional x64 Edition 128MB RAM (256MB recommended), 350MB of available hard drive space minimum, CD-ROM drive (4x or faster), available USB connection (Hi-Speed USB 2.0 recommend for optimum performance) |
| Macintosh Requirements |
PowerPC G3 400 MHz or Intel-based CPU USB 1.1 - Mac OS X 10.2.8 or later Hi-Speed USB 2.0 - Mac OS X 10.2.8 or later 128MB RAM (256 MB recommended), 735MB hard disk space minimum, CD-ROM drive (4x or faster), available USB connection |
| Physical Dimensions |
Width: 16.9" (430.1mm): Depth: 11" (280.3mm): Height: 2.2" (56.6mm) Weight: 5.5 lbs (2.5 kg approx.) |
| Software |
Epson Scan with Epson Easy Photo Fix Technology, Epson Creativity Suite, ArcSoft PhotoImpression, ABBYY FineReader Sprint Plus OCR |
| Warranty |
One year limited warranty in the U.S. and Canada |
