| Product type |
Interchangeable Lens Type Live View Digital Camera |
| Memory |
SD Memory Card (SDHC compatible) Class 6 is recommended for Movie shooting |
| Screen size |
17.3 mm (H) x 13.0 mm (V) |
| Lens mount |
Micro Four Thirds Mount |
| Effective Pixels number |
12.3 million pixels |
| Image Pick Up Unit Product type |
High speed Live MOS Sensor |
| Total no. of pixels |
Approx. 13.1 million pixels |
| Aspect ratio |
1.33 (4:3) |
| Filter array |
Primary color filter (RGB) |
| Dust reduction |
Supersonic Wave Filter (dust reduction system for image sensor) |
| Recording format |
DCF, DPOF compatible/Exif, PRINT Image Matching III |
| File format |
RAW (12-bit lossless compression), JPEG, RAW+JPEG |
| Recording image size |
[RAW] 4032 x 3024 pixels [JPEG] 4032 x 3024 pixels - 640 x 480 pixels |
| File Size RAW |
4032(H)x3042(V) (approx. 1/1.5 lossless compressed) Approx. 13.9MB Set1(LF): 4032(H)x3042(V) (1/4 compressed) Approx. 5.7MB Set2(LN): 4032(H)x3042(V) (1/8 compressed) Approx. 2.7MB Set3(MN): 2560(H)x1920(V) (1/8 compressed) Approx. 1.1MB Set4(SN): 1024(H)x768(V) (1/8 compressed) Approx. 0.3MB |
| File Size Large |
4032 x 3024 Super fine (1/2.7 compressed) Approx. 8.2MB 4032 x 3024 Fine (1/4 compressed) Approx. 5.7MB 4032 x 3024 Normal (1/8 compressed) Approx. 2.7MB 4032 x 3024 Basic (1/12 compressed) Approx. 1.8MB |
| File Size Middle |
3200 x 2400 Super fine (1/2.7 compressed) Approx. 5.4MB 3200 x 2400 Fine (1/4 compressed) Approx. 3.4MB 3200 x 2400 Normal (1/8 compressed) Approx. 1.7MB 3200 x 2400 Basic (1/12 compressed) Approx. 1.2MB 2560 x 1920 Super fine (1/2.7 compressed) Approx. 3.2MB 2560 x 1920 Fine (1/4 compressed) Approx. 2.2MB 2560 x 1920 Normal (1/8 compressed) Approx. 1.1MB 2560 x 1920 Basic (1/12 compressed) Approx. 0.8MB |
| File Size Small 1 |
1600 x 1200 Super fine (1/2.7 compressed) Approx. 1.3MB 1600 x 1200 Fine (1/4 compressed) Approx. 0.9MB 1600 x 1200 Normal (1/8 compressed) Approx. 0.5MB 1600 x 1200 Basic (1/12 compressed) Approx. 0.4MB 1280 x 960 Super fine (1/2.7 compressed) Approx. 0.9MB 1280 x 960 Fine (1/4 compressed) Approx. 0.6MB 1280 x 960 Normal (1/8 compressed) Approx. 0.3MB 1280 x 960 Basic (1/12 compressed) Approx. 0.3MB |
| File Size Small 2 |
1024 x 768 Super fine (1/2.7 compressed) Approx. 0.6MB 1024 x 768 Fine (1/4 compressed) Approx. 0.4MB 1024 x 768 Normal (1/8 compressed) Approx. 0.3MB 1024 x 768 Basic (1/12 compressed) Approx. 0.2MB 640 x 480 Super fine (1/2.7 compressed) Approx. 0.3MB 640 x 480 Fine (1/4 compressed) Approx. 0.2MB 640 x 480 Normal (1/8 compressed) Approx. 0.1MB 640 x 480 Basic (1/12 compressed) Approx. 0.1MB |
| Recording Movie format |
AVI Motion JPEG(30fps) |
| Movie Mode |
HD: 1280(H)x720(V) Aspect 16:9 SD: 640(H)x480(V) Aspect 4:3(VGA) |
| Compression Ratio |
1/12(HD), 1/8(SD) |
| Recording Movie File Size |
Max 2GB(limited by AVI format) |
| Maximum Movie Recording Time |
HD: 7min, SD: 14min |
| Recording Sound format |
Wave Format Base Stereo PCM/16bit, 44.1kHz |
| Maximum Sound Recording Time |
Picture with Sound: 30sec Movie: depend on Movie Recording Time |
| Mic/Speaker |
Mono/Mono |
| Live View Type |
Image Sensor(High Speed Live MOS) type |
| Field of view |
100% |
| Display Mode |
Normal Mode Grid Line Mode Histogram Mode(3 types) Magnified View Mode Comparable View Mode OFF Mode (for OVF user) |
| Magnification Ratio |
x7, x10, x14 |
| View finder information |
Aperture value, Shutter speed, Auto Bracket, AE Lock, AF mode, IS, Shooting Mode, Battery Check, My Mode, Internal Temperature Warning, Face Detection, Histogram, Number of storable still pictures, Record mode, ISO, Sequential shooting, Self-timer, White Balance, Metering Mode, AF confirmation mark, Exposure Compensation Value, Spot metering Area Flash Mode, Flash Status, Flash intensity Control, Super FP |
| Display of Face Detection |
Max 8 frames of face detection can be displayed |
| AF |
High speed imager AF |
| Image Stabilizer System |
Built in (Imager shift image stabilizer) |
| Mode |
3 modes (IS1:2 dimensional activation, IS2:1 dimensional activation in landscape frame to vertical direction moving, IS3:1dimensional activation in portrait frame to vertical direction moving ), OFF |
| Manual Function |
Input focal length 8, 10, 12, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Effective compensation range |
Approx.3EV steps (in maximum effect with 50mm lens) |
| Shutter speed range |
2 - 1/2000 sec. (Not available when Bulb is selected) |
| IS for Movie |
Shifting electronic image (so called Digital IS) |
| Monitor type |
HyperCrystal LCD AR(Anti-Reflective) coating |
| Monitor Size |
2.7 inches |
| Total no. of pixels(Monitor) |
Approx. 230,000 dots |
| Playback field of view(Monitor) |
100% |
| Brightness control( Monitor) |
+7 levels and -7 levels |
| Monitor Color balance |
+7 levels and -7 levels |
| AF system |
Imager Contrast Detection AF system When non High-speed imager AF compatible lens is used, it works as AF assist. |
| Focus mode |
Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR) |
| Focusing point |
11-area multiple AF with the contrast detection system (Auto, selectable in option) |
| Focusing point selection |
Auto from all 11 area, Single area from 11 area Auto from almost all area when Face detection is ON Free selection (from 225points) when Magnified View Mode is selected |
| AF lock |
Locked at first position of Shutter button in Single AF mode |
| Focus tracking |
Available |
| Manual Focus Assist |
When rotation of focus ring is detected under S-AF+MF or MF mode, LV is magnified automatically |
| Metering system |
TTL Image Sensor metering system (1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering (approx. 1% for the viewfinder screen. Highlight / shadow bases are available) |
| Metering range |
EV 0 - 18 (Digital ESP metering, Centre weighted average metering, Spot metering) (At normal temperature, 50mm f2, ISO 100) |
| Exposure mode |
(1) i Auto (2) P: Program AE (Program shift can be performed) (3) A: Aperture priority AE(4) S: Shutter priority AE (5) M: Manual (6) Scene select AE (7) Art Filter |
| Scene select AE |
Portrait, e-Portrait, Landscape, Landscape + Portrait, Macro, Sport, Night Scene, Night + Portrait, Children, High Key, Low Key, DIS mode, Nature Macro, Candle, Sunset, Document, Panorama, Fireworks, Beach & Snow |
| ISO sensitivity |
AUTO: ISO 200 - 3200(customizable, Default 200-1600) / Manual ISO 100 - 3200, 1/3 or 1 EV steps |
| Exposure compensation |
±3 EV in 1/3, 1/2, 1 EV steps selectable |
| Exposure Control AE lock |
Available |
| Exposure bracketing |
3 frames in 0.3, 0.5, 0.7, 1EV steps selectable |
| Metering standard value adjustment |
1/6 EV step, +/- 1EV range |
| Auto WB system |
High speed Live MOS sensor |
| Preset white balance |
8 settings (3000K - 7500K) Lamp (3000K), Fluorescent 1 (4000K), Fluorescent 2 (4500K), Fluorescent 3 (6600K), Daylight (5300K), Flash (5500K), Cloudy (6000K), Shade (7500K) |
| White balance compensation |
±7 steps in each A-B/G-M axis (in Auto WB / Preset WB mode / One touch WB) |
| CWB (Kelvin setting) |
1 setting can be registered at Kelvin temperature (2000K - 14000K) |
| One-touch white balance |
1 custom setting can be registered |
| White balance bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis. |
| Color space |
sRGB, Adobe RGB |
| Picture Mode |
i-Enhance, Vivid, Natural, Portrait, Muted, Monotone |
| Adjustment parameter |
Contrast, Sharpness and Saturation level available in 5 steps for i-Enhance, Vivid, Natural, Portrait and Muted Contrast and Sharpness level available in 5 steps for Monotone. 3 effect levels are available in i-Enhance |
| Filter effect |
Yellow, Orange, Red or Green filter available for Monotone |
| Picture tone |
Sepia, Blue, Purple or Green tone available for Monotone |
| Gradation |
4 levels (Auto, High key, Normal, Low key) |
| Shutter type |
Computerized focal-plane shutter |
| Shutter speed |
60 - 1/2000 sec. Bulb: up to 30 min. (selectable longest time in the menu. Default: 8 min) 1/3, 1/2, or 1EV steps selectable. |
| Self-timer |
Operation time: 12 sec., 2 sec. (cancel available) |
| Drive mode |
Single-frame shooting, Sequential shooting, Self-timer |
| Sequential shooting speed |
Approx. 3 frames/sec. in sequential shooting |
| Max. recordable pictures |
RAW mode: Max. 10 frames. |
| on sequential shooting |
JPEG mode: Depends on compression ratio and no. of pixels (Large normal mode: approx. 18 with Toshiba Super High Speed type "Class 6" 4GB) |
| Built-in flash |
Available |
| Flash G.No |
10(Fno/m) at ISO200, 7(Fno/m) at ISO100 |
| Flash Mode |
TTL-Auto, Manual(Full, 1/4, 1/16, 1/64) |
| Flash Color Temperature |
5500±400°K |
| Wireless Flash Control |
Available(4ch, 3Groups) |
| Compatible external Flash |
E-system Flash(FL-50R, FL-36R, FL-50, FL-36, FL-20, FL-14) |
| External Flash control mode |
TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL |
| Flash mode of External Flash |
Auto, Red-eye reduction, Red-eye reduction slow sync., Slow sync at 1st curtain, Slow sync at 2nd curtain, Fill-in, Off. |
| Synchronization speed |
1/30-1/16 Super FP 1/125-1/2000 |
| Flash intensity control |
Up to ±3 EV in 0.3, 0.5, 1 EV steps |
| Art Filter Mode |
Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama, Gentle Sepia |
| Multi Exposure Number of picture |
2 frames |
| Multi Exposure Functions |
Auto gain, Live View, Exposing on Recorded picture |
| Multi Aspect Ratio |
4:3(Default), 3:2, 16:9 ,6:6 |
| Process |
RAW: Aspect ratio is recorded as Exif data JPEG: JPEG image is produced based on the aspect ratio |
| Super Control Panel Info (shooting) 1 |
Battery information, Shooting mode, Shutter speed, Aperture value, Exposure compensation value, ISO sensitivity, Exposure compensation indicator, Exposure indicator, Flash intensity compensation indicator, Date, Auto BKT setting, NR setting, WB, WB compensation value, Record mode |
| Super Control Panel Info (shooting) 2 |
Flash Status, Record mode, Image size, Drive mode, Flash intensity compensation value, Metering mode, Recordable still image number, Focusing mode, AF frame, Color space, Sharpness, Contrast, Saturation, Internal Temperature Warning Gradation, IS activating mode, Face detection, My Mode, Multi Exposure, Aspect Ratio, Super FP |
| Live Control Information 1(shooting) |
Battery information, Shooting mode, Shutter speed, Aperture value, Exposure compensation value, ISO sensitivity, Exposure compensation indicator, Exposure indicator, Flash intensity compensation indicator, Date, Auto BKT setting, NR setting, WB, Record mode, Flash Status, Image size, Drive mode, Flash intensity compensation value, Metering mode, Recordable still image number, |
| Live Control Information 2(shooting) |
Focusing mode, AF frame, Internal Temperature Warning, IS activating mode, Face detection, My Mode, Multi Exposure, Aspect Ratio |
| Live Guide Setting Menu 1 |
Battery information, Shooting mode, Shutter speed, Aperture value, Exposure compensation value, ISO sensitivity, Exposure compensation indicator, Exposure indicator, Flash intensity compensation indicator, Date, Auto BKT setting, NR setting, WB, WB compensation value, Record mode, Flash Status, Record mode, Image size |
| Live Guide Setting Menu 2 |
Drive mode, Flash intensity compensation value, Metering mode, Recordable still image number, Focusing mode, AF frame, Color space, Sharpness, Contrast, Saturation, Internal Temperature Warning Gradation, IS activating mode, Face detection, My Mode, Multi Exposure, Aspect Ratio, Super FP |
| Playback mode |
Single-frame Information Display Index Display(4/9/16/25/100 frames, Calendar) Close-up (2 - 14X) Movie (w/sound, FF/REW/Pause) Slideshow(Still/Movie/Still+Movie, Slide show w/BGM/BGM+Sound/Sound) |
| Playback Information display |
Histogram (independent luminance / RGB available), Highlight / Shadow point warning, AF frame, Shooting information |
| Menu Languages |
Japan: Japanese, English Others: English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian |
| Reset & custom setting My mode |
2 setting recordable |
| Image Editing Erasing function |
Single frame, All, Selected frames(from Index) |
| Protect function |
Single frame, Selected frames, All Frames, Release protect (Single/All selected) |
| RAW picture editing |
RAW development based on settings of the camera(including Art Filter) |
| JPEG editing |
Shadow adjustment, Red-eye fix, Trimming, Monotone, Sepia, Saturation (color depth), Resize (producing another file, 1280x960, 640x480, 320x240), e-portrait |
| Image Overlay |
Up to 3 RAW images |
| Print function |
Print reservation (DPOF), Direct print (PictBridge compatible) |
| PC interface |
USB 2.0 High Speed for storage and camera control through Multi-connector(MTP mode is available) |
| TV interface |
HDMI(HD/Mono or Stereo Sound), VIDEO-OUT(SD/Mono Sound) |
| USB/Video connector |
Dedicated multi-connector (Video: NTSC/PAL selectable, USB cable is available) |
| HDMI |
Mini HDMI type-C(1080i/720p/576p/480p) |
| Flash attachment |
Hot shoe |
| DC-in |
No |
| Accessory attachment |
Accessory port |
| Battery |
BLS-1 Li-ion battery (included) |
| Sleep mode |
Available (1, 3, 5, 10 min., off selectable) |
| No. of recordable pictures |
Approx. 290 shots (IS ON, CIPA test standard)(with BLS-1 and Toshiba Class 6 SDHC 4GB card under CIPA testing standard) |
| Temperature |
0 - 40° (operation) / -20 - 60° (storage) |
| Humidity |
30 - 90% (operation) / 10 - 90% (storage) |
| Dimensions (Body) |
4.51 in (W) x 2.84 in (H) x 1.63 in (D) / 114.6 mm (W) x 72.2mm (H) x 41.5mm (D) (excluding protrusions) |
| Weight(Body) |
10.44 oz / 296g (body only), 12.13 oz. / 344g(including Battery and Memory card) |
| Lens Focal Length |
14-42mm (35mm equivalent focal length 28-84mm) |
| Lens construction |
9 Elements in 8 Groups, including ED lens, HR lens & 2 Aspherical lenses |
| Lens Angle of View |
75 - 29 Degree |
| Lens Closest Focusing Distance |
0.25m |
| Maximum Image Magnification (Lens) |
0.24x (35mm equivalent Maximum Image Magnification 0.48x) |
| Minimum Field Size(Lens) |
51.4 x 68.5mm |
| Number of Blades(Lens) |
7 (Circular Aperture Diaphragm) |
| Maximum Aperture(Lens) |
F3.5 (14mm) - F5.6 (42mm) |
| Minimum Aperture(Lens) |
F22 |
| Filter Size(Lens) |
Diameter 40.5mm |
| Dimensions (Lens) |
Diameter 62 x 43.5mm |
| Weight(Lens) |
150g |
