| Camera Type |
Digital interchangeable lens system camera |
| Camera Effective Pixels |
12.10 Megapixels |
| Image Sensor |
Type: Live MOS Sensor
Total pixels: 13.06 Megapixels
Color filter: Primary color filter |
| Dust Reduction System |
Supersonic wave filter |
| Mount |
Micro Four Thirds mount |
| Focus |
Type: Contrast AF system/Focus mode: AFS/ AFC/ MF Face detection / AF Tracking / 23-area-focusing / 1-area-focusing Touch (1- area-focusing in Face detection / AF Tracking / Multi-area-focusing / 1-area-focusing) |
| AF detective range |
EV 0-18 (F3.5 lens, ISO 100) |
| Focus Others |
Quick AF, Continuous AF (during motion image recording), AF+MF, Touch shutter, Touch MF Assist |
| AF/AE Lock |
Set the Fn button in custom menu to AF lock
Set the Fn button in custom menu to AE lock |
| AF Assist Lamp |
Yes |
| ISO Sensitivity |
Auto / Intelligent ISO / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 |
| White Balance |
Auto / Daylight / Cloudy / Shade / Halogen / Flash / White Set 1, 2 / Color temperature setting |
| White Balance Adjustment |
Blue/Amber Bias
Magenta/Green Bias |
| Color Temperature Setting |
2500-10000K in 100K |
| Exposure |
Program AE, Aperture Priority AE, Shutter Priority AE, Manual |
| Exposure Compensation |
1/3 EV Step, ± 3 EV |
| Auto Bracketing (AE) |
3,5 frame, in 1/3 or 2/3 EV Step, ±4/3 EV |
| Light Metering System |
144-zone multi-pattern sensing system |
| Light Metering |
Intelligent Multiple / Center-weighted / Spot |
| Metering Range |
EV 0-18 (F2.0 lens, ISO 100) |
| Still Image Scene Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / /Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset |
| Movie Scene Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / /Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset |
| Shutter Speed/Shutter System: Type: |
Focal-plane shutter |
| Shutter Speed |
Still Images: 1/4000 - 60 |
| Self Timer |
10sec, 3 images/ 2sec / 10sec |
| Recording Format |
Still Image: JPEG (DCF, Exif 2.3), RAW, DPOF compatible MPO (When attaching 3D lens in Micro Four Thirds standard)
Motion Image: AVCHD / QuickTime Motion JPEG |
| Image Quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard,
MPO+Fine, MPO+Standard (with 3D lens in Micro Four Thirds standard) |
| Color Space |
sRGB, Adobe RGB |
| 4:3 Aspect Ratio (Still Image) |
[4:3] 4000 x 3000 (L) / 2816 x 2112 (M) / 2048 x 1536 (S) / 1600 x 1200 (When attaching 3D lens in Micro Four Third System standard) |
| 3:2 Aspect Ratio (Still Image) |
[3:2] 4000 x 2672 (L) / 2816 x 1880 (M) / 2048 x 1360 (S) / 1600 x 1064( When attaching 3D lens in Micro Four Third System standard) |
| 16:9 Aspect Ratio (Still Image) |
[16:9] 4000 x 2248 (L) / 2816 x 1584 (M) / 1920 x 1080 (S) / 1600 x 904 (When attaching 3D lens in Micro Four Third System standard) |
| 1:1 Aspect Ratio (Still Image) |
[1:1] 2992 x 2992 (L) / 2112 x 2112 (M) / 1504 x 1504 (S) / 1440 x 1440 (When attaching 3D lens in Micro Four Third System standard) |
| Motion Picture Recording 4:3 |
Motion JPEG: [4:3] QVGA: 320 x 240, 30fps / VGA: 640 x 480, 30fps |
| Motion Picture Recording 16:9 |
Motion JPEG: [16:9] WVGA: 848 x 480, 30fps |
| Motion Picture Recording HD Movie |
1280x720 pixels 30fps (Motion JPEG) |
| Motion Image (AVCHD) NTSC |
[Full HD] 1920 x 1080, 60i (sensor output is 30p) (FSH:17Mbps, FH:13Mbps)
[HD] 1280 x 720, 60p (sensor output is 30p) (SH:17Mbps, H:13Mbps) |
| Aspect Ratio |
4:3, 3:2, 16:9, 1:1 |
| Protection/Erase |
Protection: Single / Multi or Cancel
Erase: Single / Multi / All / Except FAVORITE |
| LCD Monitor: Type |
TFT LCD with Touch panel |
| LCD Monitor: Monitor size |
3.0inch / 3:2 Aspect / Wide-viewing angle |
| LCD Monitor: Pixels |
460K dots |
| LCD Monitor: Field of View |
100% |
| LCD Monitor: Monitor Adjust |
Brightness (7 levels), Color (7 levels) |
| Live View |
Still image: Max.2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.)
Motion image: 3.1x (SH/H in AVCHD and HD/WVGA in Motion JPEG), 4.2x (VGA/QVGA in Motion JPEG) |
| Live View: Other Functions |
Guide Lines (3 patterns)/Real-time Histogram |
| Playback Mode |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (16x Max.), Slideshow (duration & effect is selectable) |
| OSD Language |
English, French, Spanish, Portuguese |
| Recording Media |
SD memory card, SDHC memory card, SDXC memory card |
| Microphone |
Stereo, Wind-cut: Off / Low / Standard / High
Microphone level adjustable: Lv1 / Lv2 / Lv3 / Lv4 |
| Speaker |
Monaural |
| HDMI |
miniHDMI Type C
Video: Auto / 1080i / 720p / 480p
Audio: Dolby Digital Stereo Creator |
| Direct Print |
PictBridge compatible (Print size, Layout, Date setting is selectable) |
| Power |
ID-Security Li-ion Battery Pack (7.2V, 1010mAh) (Included) Battery Charger |
| Operating Humidity |
10% to 80% |
| Operating Temperature |
32deg.F to 104deg.F (0deg.C to 40deg.C) |
| Built-in-Flash: Type |
TTL Built-in-Flash, GN6.0 equivalent (ISO 100 m), Built-in Pop-up |
| Built-in-Flash: Flash mode |
Auto, Auto/Red-eye Reduction, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off |
| Built-in-Flash: Synchronization |
Less than 1/160 second |
| Flash Synchronization |
1st. Curtain Sync |
| Hot shoe |
TTL Auto with FL220/FL360/FL500(Optional) |
| Software |
PHOTOfunSTUDIO 6.0 HD Edition
SILKYPIX Developer Studio 3.1 SE
Super Loilo Scope (trial version)
USB Driver |
| My Color Mode |
(Still image & Movie) Expressive/Retro/Pure/Elegant/Cinema/Monochrome/Dynamic Art/Silhouette/Custom (Color/Brightness/Saturation/ Contrast adjustable) |
| Burst Speed |
H: 3.2 frames/sec, M: 2.6 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Burst Shooting |
Number of recordable images: 7 images (when there are RAW files with the particular speed)
Unlimited consecutive shooting (when there are no RAW files) (depending on memory card size, battery power, picture size and compression) |
| USB |
USB 2.0 High Speed |
| Audio video output |
Stereo Type, NTSC |
| Dimensions (W x H x D) |
4.44" x 2.67" x 1.29" / 11.28 x 6.78 x 3.28 cm |
| Weight |
9.35 oz / 265 g |
