| Standards |
802.11b/g/n (Wireless LAN) |
| Interface |
Four 10/100 Mbps RJ45 Ethernet LAN ports One 10/100 Mbps RJ45 Ethernet WAN port |
| Security |
64/ 128 bit, WEP (Wired Equivalent Privacy) with Pass Phrase WPA (WiFi Protected Access) and WPA2 with Pass Phrase |
| Radio Technology |
802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g: Orthogonal Frequency Division Multiplexing (OFDM) 802.11g: Orthogonal Frequency Division Multiplexing with Multiple Input and Multiple Output (MIMO) |
| Antennas |
Adjustable omni-directional dipole antenna |
| Transmission Rates |
1 Mbps to 150 Mbps |
| Range Coverage |
Indoor: Up to 100 Meters (328 Feet) depending on environment, 150 Mbps at 20MHz - 68dBm (Typical), 150 Mbps at 40MHz - 65 dBm (Typical) Outdoors: Up to 400 Meters (1312 Feet) depending on environment |
| Receiver Sensitivity |
54 Mbps: Typical -70 dbm at (Typical) 11 Mbps: Typical -88 dbm at (Typical) |
| LED Status Indicators |
Power Wide Area Network Link/Activity Wired LAN Activity: for each Ethernet port Wireless LAN Activity |
| Wireless LAN Frequency Range |
IEEE 802.11b/g/n 2.4000 to 2.4835 GHz US (FCC) Channel 1 through 11 Europe (ETSI) Channel 1 through 13 |
| Power Supply |
Output: 12V DC, 1 Amp |
| Temperature |
Operating 0 to 40 deg.C (32 to 104 deg.F) Storage -0 to 70 deg.C (-32 to 158 deg.F) |
| Humidity |
5-95% non-condensing |
| Transmit Power (typical) |
11b: 18± 1dBm 11g: 15± 1dBm 11n: 18± 1dBm |
| Compliance |
FCC CE Restriction of Hazardous Substances (RoHS) |
| System Requirements |
Configuration requires a computer with an Internet browser and either Wifi or an Ethernet port. Clients on the network must support TCP/IP |
| Dimensions (L x W x H) |
136 x 87 x 24mm / 5.4 x 3.4 x .9 inches |
| Weight |
152g / 0.32lbs |
