Celestron Infiniview LCD Digital Microscope, 5MP, CMOS Sensor, 10x Magnification, 320x240 Resolution, 4x Digital Zoom, 4:3 Aspect Ratio

SKU: CNMSIV

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Celestron Infiniview LCD Digital Microscope Specifications

  • Powers

    20x to 200x (800x with digital zoom)

  • Magnification (low power)

    4x with LCD, 20x with computer

  • Magnification (high power)

    160x with LCD, 200x with computer

  • Objective Lense Diameter

    5-element IR cut, high quality glass lens

  • Lens

    15.8mm

  • Focuser Range

    10mm to infinity

  • LCD Screen

    3.5 in (90 mm) TFT LCD with 4x digital zoom, 4

  • Imaging Sensor

    5.0 MP CMOS, 10x magnification in lieu of eyepiece

  • Shutter Speed

    1 sec. to 1/1000 sec.

  • Image Stabilization

    Flicker Control 50Hz/60Hz

  • Still Image Resolution

    5MP, 3MP, 1.3MP, VGA (12MP interpolation)

  • Video Capture Resolution

    VGA, 30fps

  • Measuring Software

    Robust measuring software with note taking capabilities. Calibration tool included.

  • AC Adapter

    Input Universal 100 to 240Volt 50/60HZ (US version only)

  • TV Output

    AV cable for external monitor

  • USB Connection

    2

  • Continuous Video (VGA)

    Yes, 30 fps

  • Batteries

    1050 mAh rechargeable Li-Ion, 2 hours continuous use

  • Illumination

    8 adjustable white LEDs in ring configuration

  • Stage

    Fully adjustable with metal clips

  • Memory

    Micro SD card slot, supports up to 32G card- (card not included)

  • Software Compatibility

    XP/Vista/7/8, Mac OS X 10.6 or 10.7

  • Software

    Proprietary Celestron Portable CapturePro software

  • Screen Resolution

    320 x 240 pixels

  • Dimensions

    149 mm x 104 mm x 227 mm (5.8 in x 4.1 in x 8.9 in)

  • Weight

    56 oz, 1600 g

0 Accessories for Celestron Infiniview LCD Digital Microscope, 5MP, CMOS Sensor, 10x Magnification, 320x240 Resolution, 4x Digital Zoom, 4:3 Aspect Ratio

About Celestron Infiniview LCD Digital Microscope

The Celestron Infiniview LCD Digital Microscope is a versatile microscope that is just as useful out in the field as it is in the lab. With an a 3.5 TFT LCD screen, onboard software, rechargeable lithium-ion battery, and Micro SD card slot, you can enjoy up to 2 hours observing and capturing images in the field. The grab-and-go microscope is lightweight and easy to carry.

Back in the lab, plug InfiniView into an AC outlet and your computer via USB 2.0. The Portable Capture Pro software allows you to take accurate measurements of your specimens. Depending on your screen size, you can achieve up to 200x magnification for up-close viewing of traditional slides or 3D specimens like stamps, coins, bugs, plants, rocks, skin, gems, circuit boards, and more.

Great for the discriminating hobbyist or professional, the InfiniView LCD Digital Microscope is well suited for jobs such as entomology, industrial quality control and inspection, medicine, scientific research, and forensics, just to name a few.

On board (LCD) languages supported - English, German, French, Spanish, Italian, Portuguese, Japanese, Chinese Simple, Chinese traditional

On Computer languages supported - English, German, French, Spanish, Russian, Italian, Portuguese, Dutch, Polish, Japanese, Korean, Chinese

Celestron Infiniview LCD Digital Microscope Features

  • Built-in 5MP digital camera captures and saves high-resolution images of your specimens
  • Full-color 3.5 LCD screen and rechargeable lithium-ion battery for use in the field
  • High-quality 5-element IR cut glass lens ensures sharper images
  • 4x to 160x magnification using LCD screen, up to 200x using computer monitor
  • 4x digital zoom
  • Adjustable stage for viewing different sized subjects
  • TV out for display in a classroom or lab
  • Includes Portable Capture Pro software with measurement feature
  • Shutter trigger on base to ensure sharp images
  • Connect via USB to both Windows and Mac systems
  • Accessories Included

Key Features

  • High-quality 5-element IR cut glass lens ensures sharper images
  • 4x digital zoom
  • Adjustable stage for viewing different sized subjects
  • TV out for display in a classroom or lab
  • Includes Portable Capture Pro software
  • Shutter trigger on base to ensure sharp images

What's in the box:

  • Capture Pro Software
  • Calibration Ruler
  • USB Cable
  • AV Cable
  • Rechargeable Battery
  • AC Adapter
  • 2-Year Warranty
