Electro-Voice FMR-500 UHF Wireless Microphone System, Band A: 648-676MHz
See all Electro-Voice items

Electro-Voice FMR-500 UHF Wireless Microphone System, Includes Diversity Receiver, WT-500 Belt-Pack Transmitter, RE92TX Cardioid Lavalier Microphone, Frequency Band A: 648-676MHz

SKU: EVFMR500CA

This item is no longer available.

Recommended Alternatives

Electro-Voice RE3 Bodypack Set: Picture 1 regular
Electro-Voice RE3 Bodypack Set, RE3-BPT Tx, RE3-RX Diversity Rx, 560-596MHz
$603.00
Electro-Voice RE3 Bodypack Set: Picture 1 regular
Electro-Voice RE3 Bodypack Set, RE3-BPT Tx, RE3-RX Diversity Rx, 488-524MHz
$603.00
Electro-Voice RE3 Bodypack Set: Picture 1 regular
Electro-Voice RE3 Bodypack Set, RE3-BPT Tx, RE3-RX Diversity Rx, 653-663MHz
$603.00
Electro-Voice RE3-BPOL: Picture 1 regular
Electro-Voice RE3-BPOL Wireless Bodypack System, Omni Lavalier Mic, 488-524MHz
$735.00$659.00
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Electro-Voice Wireless Mic System Specifications

  • Receiver Type

    Synthesized PLL

  • Receiver: Frequency Range (RF)

    Band A: 648-676MHz

  • Receiver: Number of Channels

    1112 possible frequencies Programmable in 25kHz steps

  • Receiver: Modulation

    +/- 40kHz

  • Receiver: Diversity

    Digital Posi-Phase True Diversity

  • Receiver: RF Sensitivity

    <1.0 mV for 12dB SINAD

  • Receiver: Image Rejection

    >60dB

  • Receiver: Squelch

    Tone Code plus Amplitude

  • Receiver: Ultimate Quieting

    >100dB

  • Receiver: FCC Certification

    Approved under Part 15

  • Receiver: Power Requirements

    12VAC/DC 300mA

  • Receiver: Operating Temperature

    -7 to 49 deg. C / 19 to 120 deg. F

  • Audio Parameters: Frequency Response

    50-15kHz +/- 2dB

  • Audio Parameters: Balanced Output

    Mic Position: 10dBV
    Line Position: Adjustable 10mV - 2V RMS (maximum at 40kHz deviation)

  • Audio Parameters: Unbalanced Output

    Adjustable 10mV - 1V RMS

  • Audio Parameters: Distortion

    <1.0%, 0.5% typical (ref 1kHz, 40kHz deviation)

  • Audio Parameters: Signal-to-Noise Ratio

    >100dB A Weighted

  • Audio Parameters: Dynamic Range

    >100dB

  • Transmitter: Radiated Output

    30mW typical

  • Transmitter: TA4 Connector Wiring

    Pin 1: Ground; Pin 2 Mic Input
    Pin 3: +5V bias
    Pin 4: +5V bias through a 3kOhms resistor

  • Transmitter: Audio Gain Adjustment

    40dB

  • Transmitter: Power Requirements

    9V Alkaline Battery

  • Transmitter: Battery Life (Typical)

    >8 hours with 9V Alkaline Typical

  • Transmitter: Bodypack Antenna

    Flexible external 1/4 wave

  • Transmitter: Handheld Antenna

    Internal 1/2 wave

  • Microphone: Material

    Metal

  • Microphone: Connector Type

    TA4F

  • Microphone: Current Consumption

    <500 uA

  • Microphone: Diameter (Max)

    24mm / 0.94"

  • Microphone: Element

    Back Electret Condenser

  • Microphone: Finish

    Non-reflecting Black

  • Microphone: Maximum SPL (1% THD)

    135dB

  • Microphone: Open Circuit Voltage

    5.6 mV/Pascal

  • Microphone: Polar Pattern

    Cardioid

  • Microphone: Wireless

    Yes

  • Microphone: Height

    10.5mm / 0.41"

  • Dimensions (H x W x D)

    Receiver: 1.72 x 7.5 x 5.9" / 4.37 x 19.05 x 14.99cm
    Transmitter: 3.8 x 2.38 x .92" / 9.65 x 6.05 x 2.34cm

  • Weight

    Microphone: 0.81oz / 22.96g

  • UPC Code

    701001020652

About Electro-Voice Wireless Mic System

The FMR-500 brings professional features and performance to the small and medium sized wireless microphone installs that are so popular today. One touch Auto ClearScan selects the clearest channel in the clearest group of compatible channels in just seconds with the push of one button. The WT-500 bodypack transmitter features a cell phone style beltclip, dual latching battery door and a TA4 connector with a wide variety of lapel and head worn microphone options. The combination of sound and RF features is hard to beat at twice the price.

The RE92Tx is a miniature professional-quality electret condenser lavalier microphone with a cardioid pickup pattern. Designed for speech, it is an excellent choice for use in presentations, houses-of-worship and broadcast or theater applications.

Electro-Voice Wireless Mic System Features

  • RE92Tx Lavalier Microphone - Back-electret condenser element
  • RE92Tx Lavalier Microphone - Cardioid polar pattern
  • RE92Tx Lavalier Microphone - Integrated 6' (180cm) cable
  • RE92Tx Lavalier Microphone - TA4F connector is compatible with all EV bodypack transmitters
  • RE92Tx Lavalier Microphone - Use with TXA for wired XLR applications
  • Up to 10 systems can operate simultaneously from the pre-set groups of channels in one operating band. Groups of 16 coordinated channels between the two bands are also pre-set
  • Advanced ClearScan and one touch Auto ClearScan automatic group and channel selections, for quick and easy system setup
  • Completely programmable in 25kHz steps across 28MHz for 1112 possible frequencies
  • Backlit receiver LCD display shows the Group/Channel, Frequency, transmitter battery status, diversity operation and RF and Audio level meters
  • Balanced XLR audio output for Microphone or Line level signals and a 1/4" line level jack to match any application
  • Fourth generation Posi-Phase diversity and advanced audio circuits provide maximum range and professional sound quality
  • Includes single and dual rack mount hardware with front mount antenna cables
  • "Smart" battery circuit means there is no way to put the battery in wrong
  • Tone Code plus Amplitude squelch with one button on/off

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Electro-Voice FMR-500 Diversity Receiver
  • WT-500 Belt-Pack Transmitter
  • RE92TX Cardioid Lavalier Microphone
  • Rack Mount Hardware
  • 2x 1/4 Wave Antenna
  • Wall Pack Power Supply
  • Electro-Voice 3 Year Warranty
