TRENDnet TFC-1600 16-Bay Fiber Converter Chassis System
See all TRENDnet items

TRENDnet TFC-1600 16-Bay Fiber Converter Chassis System

SKU: TNFC1600
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

TRENDnet TFC-1600 Specifications

  • Capacity

    16 slots for housing up to 16 TFC series media converters

  • Management Ports

    1 x 10/100Mbps Fast Ethernet RJ45 and 1 x RS-232

  • Management Protocol

    SNMP(RFC1157), ARP(RFC826), IP(RFC791), ICMP(RFC792), UDP(RFC768), TCP(RFC793), TFTP(RFC783), Telnet(RFC854), BOOT(RFC951), MIB II (RFC1213)

  • Diagnostic LEDs

    Power x 2, In Use x 2, Fan Fault x 2

  • Power

    One power supply; optional second power supply

  • Input

    AC 100 - 240 VAC Power Consumption: 150 watts max

  • Power Overload Protection

    All outputs protected from short circuit condition with automatic recovery

  • Cooling

    Single cooling fan (internal) mounted at the rear panel

  • Housing

    Steel sheet metal

  • Operating Temperature

    0deg. - 40deg. C (32deg. - 104deg. F)

  • Storage Temperature

    -10deg. - 50deg. C (14deg. - 122deg. F)

  • Operating Humidity

    10% - 90%

  • Storage Humidity

    5% - 90% (no-condensing)

  • Dimensions

    415x390x89mm (16.33x15.35x3.50")

  • Weight

    7Kg (15.43lbs) (with one power supply)

About TRENDnet TFC-1600

The TRENDnet TFC-1600 16-Bay Fiber Converter Chassis System provides housing for up to 16 TFC series media converters. Designed for continuous operation, the chassis is equipped with dual cooling fans and redundant power supplies (optional). Its Plug-and-Play and Hot-Swap features allow installing/removing the converter unit without powering off the chassis. TFC-1600 rack-mount chassis eliminates the external power adapters for TFC series media converters and organizes multiple converters in a single unit, which makes it the perfect solution for managing multiple TFC series converters.

TRENDnet TFC-1600 Features

  • Provides housing for up to 16 TFC series media converters
  • Front panel LEDs indication
  • Standard 19" rack-mount size, 2U height
  • Hot-Swappable; easy & quick replacement of converter and power supply
  • Single cooling fan (internal) mounted at the rear panel
  • Optional redundant power supply to ensure non-stop reliable operation
  • Optional Management Module
  • Load Sharing mechanism to minimize downtime (available only with redundant power supplies)
  • Power isolation designed with converter bays: ensures each bay is electrically isolated from others

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Provides housing for up to 16 TFC series media converters
  • Front panel LEDs indication
  • Standard 19 rack-mount size, 2U height
  • Hot-Swappable; easy & quick replacement of converter and power supply
  • Single cooling fan (internal) mounted at the rear panel
  • Optional redundant power supply to ensure non-stop reliable operation

What's in the box:

  • TRENDnet TFC-1600 16-Bay Fiber Converter Chassis System
  • Quick Installation Guide
  • Power Cord
  • Mounting Brackets
  • TRENDnet 3 Year Limited Warranty
