Anton Bauer Logic Series Dionic 90 Digital Interactive Lithium-Ion Battery, 14.4 volts, 90 watt hours, Anton Bauer 3-Stud Gold Mount
Mfr. Part: DIONIC 90 SKU: ABD90
|
|
 |
|
|
|
Item Includes
One Year Manufacturer's Warranty
|
Description
DIGITAL DIONIC with RealTime display... Dionic batteries are the perfect selection for the videographer with weight as the highest priority in selecting a battery. Dionic offers complete compatibility with PowerChargers already in the field (may require software chip update) and the Titan series.
Multiple electronic safety circuits, including the field proven reliability of the Digital Battery, and the mechanical integrity of IMPAC case construction have allowed Anton/Bauer to design an all new battery which safely employs lightweight cell chemistry for the rigors of Eng use.
Dionic 90 weighs only 1.7 lbs (770 grams) and is the highest capacity lithium ion battery which can be legally transported without restriction under the IATA and DOT safety regulations.
Dionic 160 contains an exclusive cell configuration unlike any other video battery. Instead of using cells originally designed for lighter duty applications, such as computers, this battery is constructed with specialized lithium ion cells originally designed for high rate military applications.
Because of these low resistance cells, Dionic 160 can be used to power lighting loads and other accessories with a total output of up to 10 amps a capability usually reserved only for nickel based chemistries. Dionic 160 weighs 30% less than a HyTRON 120, has 30% more capacity, and will run a typical camcorder for over 6 hours.
No single battery size, type or chemistry can offer the ultimate in all of these characteristics in every shooting situation for every type of video operation. That's why Anton/Bauer employs all three major chemistries - nickel metal hydride, lithium ion, and nickel cadmium.
The entire range of price, size and capabilities of Anton/Bauer Logic Series andInterActive batteries can be mixed and matched on the same InterActive charger.
The right battery is an Anton/Bauer system that allows you to work the way you need to, with unmatched features, performance, service life and value. Only Anton/Bauer Digital batteries communicate directly with every Anton/Bauer InterActive Charger.
Digital batteries also communicate directly with the InterActive viewfinder of current professional camcorders. No modification or special adaptors are necessary - the feature is standard equipment with the camera.
Available only from Anton/Bauer, this unique on board display provides the battery feature most requested by videographers today - both full-time analog fuel gauge and a remaining time indication available simultaneously. No set-up is required and the battery can be used on any piece of portable equipment. The RealTime display simultaneously provides remaining runtime indication along with an analog fuel gauge indication in the battery on-board LCD.
|
Specifications
| Chemistry Type | Li-Ion, Lithium Ion |
| Voltage Output | 14.4V
Operates 12 - 16.8V |
| Watt Capacity | 90 w |
| Connection Type | Anton Bauer Gold Mount |
| Weight | 1.7 lbs. / 770g |
| Dimensions | 5-1/4" X 3-1/2" X 2-1/8" / 13.3 X 8.89 X 5.39 cm |
| Typical Runtimes |
1.75hrs.@50watts
2.5hrs. @35watts
3.5hrs. @25watts |
| Note | Can only be used with PowerCharger & Titan series chargers only. |
| | |
|
|
