ATN Odin-32C 2x Waterproof Thermal Monocular, 35mm Lens, 30Hz Frame Rate, 27mm Eye Relief, 800x600 Image Resolution

ATN
SKU: ATNMPOD32C MFR: TIMPOD32C
ATN Odin-32C: Picture 1 thumbnail ATN Odin-32C: Picture 2 thumbnail ATN Odin-32C: Picture 3 thumbnail ATN Odin-32C: Picture 4 thumbnail
Made in USA

Our Price

$6,499.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About ATN Odin-32C

The ATN Odin-32C 2x Waterproof Thermal Monocular (30Hz Frame Rate) features extremely small size and low weight because of its advanced construction and characteristics using the latest technologies in high grade polymers to make a Mil. Spec, system that is identical in size, weight and shape to a AN/PVS-14.The Odin-32C is a multi-purpose system using the latest in miniature thermal sensor technology combined with the new OLED Display to provide a superior stable image in the smallest package available. The system also includes an array of features that help the user to enhance the sight to meet all of their requirements.

The Odin-32C is one of the most capable thermal monocular systems on the market and comes with a very affordable price point. The Odin-32C 2x system is designed for hand held and head mounts operations. It is designed to use the same accessories as the AN/PVS-14 Night Vision Monocular System. The Odin-32C has many options available for head mounting. The easiest is the easy to use J-Arm bracket and a standard head strap.

ATN Odin-32C Features

  • Ergonomic Design
  • Compact and Lightweight
  • PVS-14 Construction
  • Mil. Spec Optics
  • Head Mountable
  • Variable Geometry Display
  • E-Zoom
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity, Multiple Color Modes
  • VOx Vanadium Oxide Detector
  • 800x600 OLED Display
  • Video Output
  • Export of this product outside of the United States of America is not allowed and is controlled by the US Department of State

ATN Odin-32C Specifications

Sensor (microbolometer)
320 x 240
Type
Uncooled
Material
Vanadium oxide (VOx)
Image Size (output resolution)
800x600
Frame rate
30 Hz
Video output
Analog RS-170
Lens
35mm
Display
Color OLED matrix,SVGA< 800x600
Thermal Sensitivity
<50mK
Spectral Response
7-14 um
Field of View
15deg.x11deg.
Eye Relief
27mm
Diopter Adjustment
-6 to +4
Optical Magnification
2x
E-Zoom
4x, 8x
Human Detection
750 m
Human Recognition
300 m
Human Identification
180 m
Vehicle Detection
1650 m
Vehicle Recognition
660 m
Vehicle Identification
400 m
Polarity control
White hot / Black hot / Multiple Color Modes
Start up time
<4 sec
Waterproof
Waterproof / Dustproof
Battery type
1 x CR123A battery type
Battery Life
2+ hrs
Dimensions
3.4x2.2x1.95" / 8.63x5.58x4.95cm
Weight
0.77lbs / 0.34kg
