ATN Odin-32D 2x Waterproof Thermal Monocular, 35mm Lens, 60Hz Frame Rate, 800x600 Image Resolution

SKU: ATNMPOD32D MFR: TIMPOD32D
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$7,199.00 List Price

Our Price

$6,999.00 $272 per week
Free Expedited Shipping
Qty:
Add to Wishlist

About the ATN Odin-32D

The ATN Odin-32D 2x Waterproof Thermal Monocular (60Hz Frame Rate) features extremely small size and low weight because of its advanced construction and characteristics using the latest technologies in high grade polymers to make a Mil. Spec, system that is identical in size, weight and shape to a AN/PVS-14.The Odin-32D is a multi-purpose system using the latest in miniature thermal sensor technology combined with the new OLED Display to provide a superior stable image in the smallest package available. The system also includes an array of features that help the user to enhance the sight to meet all of their requirements.

The Odin-32D is one of the most capable thermal monocular systems on the market and comes with a very affordable price point. The Odin-32D 2x system is designed for hand held and head mounts operations. Designed to use the same accessories as the AN/PVS-14 Night Vision Monocular System. The Odin-32D has many options available for head mounting. The easiest is the easy to use J-Arm bracket and a standard head strap.

ATN Odin-32D Includes

  • ATN Odin-32D 2x Waterproof Thermal Monocular
  • Instruction Manual
  • Lens Tissue
  • Lithium Battery
  • Lens Cap
  • Demist Shield
  • Hard Case
  • J-Arm Head Mount Adapter with Head Strap
  • ATN 1 Year Limited Warranty

ATN Odin-32D Features

  • Ergonomic Design
  • Compact and Lightweight
  • PVS-14 Construction
  • Mil. Spec Optics
  • Head Mountable
  • Variable Geometry Display
  • E-Zoom
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity, Multiple Color Modes
  • VOx Vanadium Oxide Detector
  • 800x600 OLED Display
  • Video Output
  • Export of this product outside of the United States of America is not allowed and is controlled by the US Department of State

ATN Odin-32D Specifications

Sensor (microbolometer) 320 x 240
Type Uncooled
Material Vanadium oxide (VOx)
Image Size (output resolution) 800x600
Frame rate 60 Hz
Video output Analog RS-170
Lens 35mm
Display Color OLED matrix,SVGA< 800x600
Thermal Sensitivity <50mK
Spectral Response 7-14 um
Field of View 15deg.x11deg.
Eye Relief 27mm
Diopter Adjustment -6 to +4
Optical Magnification 2x
E-Zoom 4x, 8x
Human Detection 750 m
Human Recognition 300 m
Human Identification 180 m
Vehicle Detection 1650 m
Vehicle Recognition 660 m
Vehicle Identification 400 m
Polarity control White hot / Black hot / Multiple Color Modes
Start up time <4 sec
Waterproof Waterproof / Dustproof
Battery type 1 x CR123A battery type
Battery Life 2+ hrs
Dimensions 3.4x2.2x1.95" / 8.63x5.58x4.95cm
Weight 0.77lbs / 0.34kg
