ATN OTS-X 0.5x Thermal Imaging Viewer with 14mm Lens, 30Hz Frame Rate, 640x480 Sensor, 2x / 4x / 8x Digital Zoom

ATN
SKU: ATNOTSXF614 MFR: TIMNOTSXF614
ATN OTS-X 0.5x Viewer: Picture 1 thumbnail ATN OTS-X 0.5x Viewer: Picture 2 thumbnail ATN OTS-X 0.5x Viewer: Picture 3 thumbnail ATN OTS-X 0.5x Viewer: Picture 4 thumbnail

List Price: $8,199.00

Made in USA

Our Price

$7,999.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About ATN OTS-X 0.5x Viewer

The ATN OTS-X 0.5x Thermal Imaging Viewer with 14mm Lens is designed to be a versatile, compact, lightweight yet rugged thermal viewer that can be easily carried in a cargo pocket for Law enforcement and Sportsmen alike.

The OTS-X is one of the most affordable thermal viewers on the market that includes a full 640x480. It features is the ability to interchange the objective lens so you can have multiple magnifications based on your need or mission.

ATN OTS-X 0.5x Viewer Features

  • Resolution 320 x 240
  • Ergonomic Design
  • Fast Imaging (30hz)
  • Compact Rugged Construction
  • Interchangeable Optics
  • Variable Geometry Display
  • E-Zoom
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity
  • VOx Vanadium Oxide Detector
  • 800x600 Display
  • Video Output
  • Export of this product outside of the United States of America is not allowed and is controlled by the US Department of State

ATN OTS-X 0.5x Viewer Specifications

Sensor (microbolometer)
640 x 480
Material
Vanadium oxide (VOx)
Image Size (output resolution)
800x600
Frame rate
30 Hz
Video output
Analog RS-170
Lens
14mm
Display
Color OLED matrix, SVGA< 800x600
Thermal Sensitivity
<50mK
Spectral Response
7-14 µm
Field of View
4,5deg.
Eye Relief
27 mm
Diopter Adjustment
-1.5
Optical Magnification
0.5x
E-Zoom
1x, 2x, 4x
Human Detection
500 m
Human Recognition
700 m
Human Identification
135 m
Vehicle Detection
1100 m
Vehicle Recognition
495 m
Vehicle Identification
300 m
Polarity control
White hot / Black hot / Multiple Color Modes
Start up time
<4 sec
Waterproof
Yes
Battery type
1 x CR123A battery type
Battery Life
2+ hrs
Dimensions
100x61x83 mm / 3.93x2.40x3.26"
Weight
0.83 lbs / 0.37kg
