ATN OTS-X 2.5x Thermal Imaging Viewer with 50mm Lens, 640x480 Sensor, 30Hz Frame Rate, 27mm Eye Relief, 5x, 10x, 20x Digital Zoom

SKU: ATNOTSXF650 MFR: TIMNOTSXF650
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$9,195.00 List Price

Our Price

$8,995.00
Free Shipping
Qty:

Add to Wishlist

About the ATN OTS-X 2.5x Viewer

The ATN OTS-X 2.5x Thermal Imaging Viewer with 50mm Lens is designed to be a versatile, compact, lightweight yet rugged thermal viewer that can be easily carried in a cargo pocket for Law enforcement and Sportsmen alike. The OTS-X is one of the most affordable thermal viewer on the market that includes a full 640x480. One of the most unique features is the ability to interchange the objective lens so you can have multiple magnifications based on your need or mission.

ATN OTS-X 2.5x Viewer Includes

  • ATN OTS-X 2.5x Thermal Imaging Viewer with 50mm Lens
  • Instruction Manual
  • Lens Tissue
  • Lithium Battery
  • Lens Cap
  • ATN 1 Year Warranty

ATN OTS-X 2.5x Viewer Features

  • Ergonomic Design
  • Fast Imaging (30hz)
  • Compact Rugged Construction
  • Interchangeable Optics
  • E-Zoom
  • Variable Geometry Display
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity
  • VOx Vanadium Oxide Detector
  • 800x600 Display
  • Video Output
  • Export of this product outside of the United States of America is not allowed and is controlled by the US Department of State

ATN OTS-X 2.5x Viewer Specifications

Sensor (microbolometer) 640x480
Material Vanadium oxide (VOx)
Image Size (output resolution) 800x600
Frame rate 30 Hz
Video output Analog RS-170
Lens 50mm
Display Color OLED matrix, SVGA< 800x600
Thermal Sensitivity <50mK
Spectral Response 7-14 µm
Field of View 14deg.
Eye Relief 27 mm
Diopter Adjustment -1.5
Optical Magnification 2.5x
E-Zoom 5x, 10x, 20x
Human Detection 1300
Human Recognition 500
Human Identification 320
Vehicle Detection 2800
Vehicle Recognition 1100
Vehicle Identification 700
Polarity control White hot / Black hot / Multiple Color Modes
Start up time <4 sec
Waterproof Yes
Battery type 1 x CR123A battery type
Battery Life 2+ hrs
Dimensions 6.5x2.4x3.3" (16.51x6.09x8.38kg)
Weight 1.4lbs (0.63kg)
