ATN

ATN OTS-X-F670 3.5x Thermal Imaging Viewer with 70mm Lens, 640x480 Sensor, 30Hz Frame Rate, 27mm Eye Relief, 7x, 14x, 28x Zoom

SKU: ATNOTSXF670 MFR: TIMNOTSXF670
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$9,695.00 List Price

Our Price

$9,495.00
Free Expedited Shipping
Qty:
Add to Wishlist

About the ATN OTS-X-F670

The ATN OTS-X-F670 3.5x Thermal Imaging Viewer with 70mm Lens is designed to be a versatile, compact, lightweight yet rugged thermal viewer that can be easily carried in a cargo pocket for Law enforcement and Sportsmen alike.

The OTS-X is one of the most affordable thermal viewers on the market that includes a full 640x480. One of the most unique features is the ability to interchange the objective lens so you can have multiple magnifications based on your need or mission.

ATN OTS-X-F670 Includes

  • ATN OTS-X-F670 3.5x Thermal Imaging Viewer with 70mm Lens
  • Instruction Manual
  • Lens Tissue
  • Lithium Battery
  • Lens Cap
  • ATN 1 Year Warranty

ATN OTS-X-F670 Features

  • Ergonomic Design
  • Fast Imaging (30hz)
  • Compact Rugged Construction
  • Interchangeable Optics
  • E-Zoom
  • Variable Geometry Display
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity
  • VOx Vanadium Oxide Detector
  • 800x600 Display
  • Video Output
  • Export of this product outside of the United States of America is not allowed and is controlled by the US Department of State

ATN OTS-X-F670 Specifications

Sensor (microbolometer) 640x480
Material Vanadium oxide (VOx)
Image Size (output resolution) 800x600
Frame rate 30 Hz
Video output Analog RS-170
Lens 70mm
Display Color OLED matrix, SVGA< 800x600
Thermal Sensitivity <50mK
Spectral Response 7-14 µm
Field of View 9deg.
Eye Relief 27mm
Diopter Adjustment -1.5
Optical Magnification 3.5x
E-Zoom 7x, 14x, 28x
Human Detection 1800m
Human Recognition 700m
Human Identification 460m
Vehicle Detection 3800m
Vehicle Recognition 1400m
Vehicle Identification 1000m
Polarity control White hot / Black hot / Multiple Color Modes
Start up time <4 sec
Waterproof Yes
Battery type 1 x CR123A battery type
Battery Life 2+ hrs
Dimensions 7x3x3.3" (17.78x7.62x8.38cm)
Weight 1.75lbs (0.79kg)
