| Tripod: Attachment |
3/8" screw |
| Tripod: Bubble spirit levels |
1 |
| Tripod: Closed length |
25in / 635mm |
| Tripod: Column cross-section: |
Three-faceted |
| Tripod: Column tube diameter |
28mm / 1.10in |
| Tripod: Head bowl |
50mm / 1.97in |
| Tripod: Leg angles |
23deg., 47deg., 66deg., 89deg. |
| Tripod: Leg cross-section |
Round |
| Tripod: Leg sections |
3 |
| Tripod: Legs tube diameter |
29.2, 24.8, 20.4 mm / 1.15, 0.98, 0.80in |
| Tripod: Load capacity |
15.43 lbs / 6.99kg |
| Tripod: Material |
Carbon fiber legs, aluminum column + magnesium, aluminum castings |
| Tripod: Maximum height |
64.57" / 1640.078mm |
| Tripod: Max height |
54.72" / 1389.888mm (with center column down) |
| Tripod: Minimum height |
18.31" / 465.07mm |
| Tripod: Weight |
4.25 lbs / 1.93kg |
| Head: Front tilt |
+/- 90 degrees |
| Head: bowl |
60mm |
| Head: Lateral tilt |
+90/-20 degree tilt range |
| Head: Load capacity |
15.43 lbs |
| Head: Material |
24.4602 |
| Head: Pan drag |
Continuously adjustable from 0 to max level |
| Head: Panoramic rotation |
360 degrees |
| Head: Spring-loaded counter balance |
Proportional/free/off |
| Head: Tilt drag |
Continuously adjustable from 0 to max level |
| Head: Working height |
5.31" |
| Tripod: Weight |
4.25 lbs / 1.93kg |
| Head: Weight |
45.06 oz / 1277.43g |
