| Projection System |
DLP |
| Native Resolution |
XGA (1024 x 768) |
| Brightness |
2700 ANSI lumens |
| Contrast Ratio |
10000: 1 |
| Display Color |
1.07 Billion Colors |
| Lens |
F=2.54-2.73, f=21-23.1mm |
| Aspect Ratio |
Native 4:3 (5 aspect ratio selectable) |
| Throw Ratio |
1.64-1.97 ( 60"@ 2m ) |
| Image Size (Diagonal) |
35"-300" |
| Zoom Ratio |
1.2:1 |
| Lamp (Normal/Economic Mode) |
190W, 4500/6000 hours |
| Keystone Adjustment |
1D, Vertical ± 40 degrees |
| Projection Offset |
110%±5% |
| Resolution Support |
VGA (640x480) to UXGA (1600x1200) |
| Horizontal Frequency |
31K-102KHz |
| Vertical Scan Rate |
23-120Hz |
| Interface |
Computer in (D-sub 15pin) x 2 Monitor out (D-sub 15pin) x 1 Composite Video in (RCA) x 1 S-Video in (Mini DIN 4pin) x 1 Audio in (Mini Jack) x 2 Audio L/R in (RCA) x 1 Audio out (Mini Jack) x 1 Speaker 10W x 1 LAN (RJ45) x 1 USB (Type Mini B) x 1 RS232 (DB-9pin) x 1 IR Receiver x 2 |
| HDTV Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video Compatibility |
NTSC, PAL, SECAM |
| On-Screen Display Languages |
English/ France/ Germany/ Italian/ Spanish/ Russian/ Traditional Chinese/ Simplified Chinese/ Japanese/ Korean/ Swedish/ Dutch/ Turkish/ Czech/ Portuguese/ Thai/ Polish/ Hungarian/ Croatian/ Romanian/ Norwegian/ Danish/ Bulgaria/ Finnish/ Indonesian/ Greek/ Hindi/ Arabic (28 Languages) |
| Picture Modes |
Dynamic/Presentation/sRGB/Cinema/User 1/User 2 |
| 3D Support and Compatibility |
PC: 120Hz Frame Sequential 2D for resolutions up to WXGA. PC: 60Hz Frame Sequential 3D for resolutions up to WXGA, PC: 60Hz Top-bottom 3D for resolutions up to SXGA+, Video: 60Hz Frame Sequential 3D for resolutions up to 480i |
| Audible Noise |
31/26 dBA (Normal/Economic mode) |
| Power Supply |
AC 100 to 240 V, 50/60 Hz |
| Power Consumption |
265W(Typical), Standby<1W |
| Dimensions(W x H x D) |
287.3 x 114.4 x 232.6 mm / 11.3 x 4.5 x 9.1" |
| Weight |
2.5 kg (5.51lbs) |
