| Printing Method |
Direct Thermal |
| Operation Modes |
PC Connected / Stand Alone(ESC/P or P-touch Template) |
| Cutter |
Auto |
| Cutter Life |
300000 (Based on Brother internal testing using die-cut labels) |
| Maximum Print Speed |
69 labels per min |
| Display |
3 color LED |
| Tape Sizes |
Die-cut and Continuous |
| Maximum Tape Width |
4" / 10.16cm |
| Maximum Print Width |
3.9" / 9.90cm |
| Maximum Label Length |
9.8 ft /2.98m |
| Maximum Resolution |
300 dpi |
| Font Styles |
True Type for Windows, Bitmap(5), Outline(3) |
| Memory |
8 MB |
| Memory for Transferred Data (number) |
Yes (99 files or 2048 kb) |
| Symbols for Windows |
1379 ( No. of Clip arts in P-touch Editor) |
| Multiple Copies |
Up to 9999 copies |
| Mirror Printing |
Yes |
| Vertical Printing |
Yes |
| Rotate Printing |
Yes |
| Date/Time Stamp |
PC Generated |
| Bar-codes Types |
CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked), PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode |
| Microsoft Add-ins |
Yes |
| Database File Compatibility |
Csv, txt, mdb, xls, Microsoft SQL Server Database |
| Interface |
USB, RS-232C, 10/100 BASE-TX Wire Ethernet |
| Compatibility |
PC & Mac |
| Operating System |
Windows 2000/XP/Vista/7/Server 2003/Server 2008; Mac OS X 10.8.x |
| Dimensions (W x H x D) |
6.7 x 8.7 x 5.8" / 17.01 x 22.09 x 14.73cm |
| Weight |
5.8 lbs / 2.63kg |
