Canon TS-E 45mm f/2.8 Tilt and Shift Manual Focus Lens - USA

SKU: CA4528AFU

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Q&A

Questions & Answers

Shopper : Is this lens useful for architecture and interior shots. Or would 24mm be better?CHARLES C : The 24mm T/S is much more useful overall for architectural / interior shots. However the 45 T/S is great for detail shots of spaces, exteriors that you may want to shoot from farther away, or shooting wide open to isolate an particular subject.JAMES B : I use both lenses for interiors. I use the 45 more often but the 24 is very useful sometimes. I recommend having both lenses.DAVID C : Better for portrait work. 24mm and the 17mm are more what you are looking for. STEPHEN J : The 24mm will serve you better for what you're looking to do.
Shopper : With the shift that allows you do a panoramic photo, what would be the number of degrees total viewing angle? Like 24mm? I'm trying to decide which one to buy.VICTOR C : If you are shooting in landscape orientation, since this lens can shift up to about 12mm, assuming you are using a full-frame camera such that the sensor size is 24mmx36mm. So shifting it by 12mm horizontally increases your angle of view by 33%, thus increasing AOV from 51 degrees to 68 degrees. However, if you stitch a left-shifted w/ a right-shifted image, then you should have a 66% gain resulting in 85% AOV, which is very wide--wide enough for panoramic shots.JANICE P : Horizontally a three shot panorama with this lens can exceed 14mm equivalent I believe. I did not like the 24mm version because people were too distorted outside of the center.
Shopper : does the Canon TS-E 45mm f/2.8 apart from tilt and shift, does it also rotate?DAN W : I don't believe so. I have not used mine yet.JUSTIN B : Yes. It rotates so you can apply the tilt/shift on any plane. It locks at both right angles for easier use. ERCUMENT K : Of course there for you can make the tilt to any direction you want.JEREMY B : The lens rotates which allows you to shift L/R or rise up/down. You can tilt in the opposing axis based on your selected axis movement (shift vs rise/fall). The second generation lenses give you the ability to tilt and select shift independently but as far as I know they have not released a 2nd generation 45mm. imo this is one of the big shortcomings of these lenses is the fact that you have to choose either shift or rise, you can't do both as you could with a camera with standards. I also consider the optics of this lens to be mediocre. Schneider makes a T/S that is a lot more expensive but I think it is probably way better. I have never used it. good luck. JeremyD MICHAEL D : The lens rotates 90 degrees so that the plane of shifting and tilting is either vertical or horizontal. Perspective correction and focal plane adjustment may be made in either the horizontal or vertical planes - in other words, for example, along a wall, or up the side of a building.JOHN E : No, it does not rotate. If you have never used a tilt shift, I would suggest renting one for a few days to try it out. It can be a fun lens and a helpful lens depending on what you use it for.JOE S : it rotates. all the way around. this allows you to create your tilted focal plane to every angle around the lens. you can shift in 360 degrees too. it's a cool lens. no auto focus b/c of all that tilting and shifting tho.TISHA S : Yes, it will rotate 90 degrees in each direction for a total of 180 degrees of rotation!ASHLEY H : Yes, it does also rotate! Great lens!RAYMOND N : Yes, it rotates by depressing a button on the side of the lens. From Canon tilt and shift are 90 degrees apart. That can be changed via a minor modification. Many YouTube videos and blogs describing how to do that.SYED Y : Yes the lens can rotate. Canon calls it the "TS rotation lock release button" When press down while mounted on the camera you can turn the tilt component. Use it horizontal or in vertical position (or in between) Hope this helps answer your question

Reviews about this item

Review Summary

2016-12-18T19:00:00

Rated 5 out of 5

Fun lens for creative results

I've owned this lens for about 4 years now, and I will occasionally use it for architecture photography, when I have the time to get the shot right (and the results are stunning but 95% of the time I use it during weddings for interesting atmosphere and unexpected portraits results. The blur it can create is not for everyone, but I love it, and so do many clients. It does take some practice getting used to, but I find it relatively easy to handle with a little patience.

nystedtphoto

2016-04-06T20:00:00

Rated 3 out of 5

Think of it like a 4x5 lens

It's not that sharp. The maximum aperture is just okay. There's some notable chromatic aberration, and it's hard to fix in post. Of course, there's no autofocus. For all its foibles, though, I like shooting with it. The movements are simply not available on many lenses, and they open up a bunch of creative options. The 45mm focal length is practical for general-purpose photography, and if you pair it with an APS-C sensor and/or extenders, you get a really neat portrait lens. My advice is to think of this lens like the lens on a technical camera. You focus and compose wide-open, but the lens really wants to be used around f/8 to f/11. Once it's stopped down, the optical performance is really pretty good. My main complaint is CA. There's some lateral CA and it can be hard to fix since it won't be in the center after you shift. More irritating is the longitudinal CA, which gives green and magenta bokeh. It's really hard to fix and means you have to be really careful of your backgrounds when you tilt with gusto. Also, when I'm shooting un-tilted and un-shifted, I really do miss autofocus. I'd like to see an autofocus system in the next version for people (like me!) who mostly shoot the lens as a regular old prime and only use movements occasionally. The autofocus points on my cameras still work, so the only thing preventing autofocus is the lack of an autofocus system. It's not advertised as such, but you can use Canon extenders with this lens. It doesn't correctly record the aperture, but the image quality is fine at f/8. Would I recommend it to a friend? Well, I don't think any of my friends would really want a tilt-shift! But if someone knows they want a tilt-shift, this lens certainly comes recommended.

Charles M.

2011-03-10T19:00:00

Rated 3 out of 5

Not crisp

I have a lot of canon lenes this one was not up to snuff the 90 mm T's is far better not crisp for macro w

Arnold

2011-03-03T19:00:00

Rated 3 out of 5

Needs improvement

I've owned a 45mm TS-E for 7 years and find it fun and an enjoyable experience to use. However, it needs improvement in several areas. It needs a circular aperture, rotatable tilting, and Canon's SSC lens coating. With these improvements the lens will be world-class. Focus across the image plane is adequate but could be sharper. At large apertures there is significant color fringing. An updated version of this lens would be welcome.

cb_photo

2009-02-14T19:00:00

Rated 5 out of 5

Go places with this lens that few others dare!

I bought the 45mm TS-E lens for one use and ended up using it most of the time for completely different purposes. WIth film cameras, I mostly used it as an urban landscape or architectural lens. But now with 1.6X crop sensor digital cameras I find it an excellent macro or near macro lens! The shift and tilt capabilities are a real bonus, to give even greater control over the plane of focus. It's become my main "table top" small product lens. I also use the 24mm TS-E. Now that lens is more of an architectural lens for me. If I were shooting with full frame digital cameras, I'd want the 90mm, too, for macro and near macro work. These lenses are extremely well made. They are manual focus only, but that's not an issue for the types of shooting their designed to do. Besides, every EOS camera I've ever used TS-E lenses on gives a focus confirmation, making it easy to use the lenses manually. The only thing I'd like to see done differently if the TS-E lenses were ever revised would be to build in another rotation, that allows the user to set the tilt and shift planes ligned with each other, or set 90 degrees out of phase. As it is now, the lens comes with the two adjustments at 90 degrees, but you can send them in to Canon Service Department to have them aligned, if you wish. Build quality and the "feel" of all three TS-E lenses are the same, excellent, although only the 24mm gets an L designation. The TS-E lenses are about as close as you will come to view camera movements on a full frame or crop sensor digital camera. A full featured 4x5, for example, will have more types of movements possible, as well as a bit more range of movement. Still, it's a lot more practical to use the TS-E lenses and EOS cameras out in the field! If you've used a view camera in the past, these lenses will be easy to use. If not, there will be a bit of a learning curve using them. Read the manual and, if still scratching your head, pick up a book on using view cameras.

amfoto1

2007-12-29T19:00:00

Rated 4 out of 5

Unique lens, requires thoughtful user

For the unitiated: this is really a unique lens; you can just grab it and go, shooting normally, as manual focus-only, and it will render quite sharp, contrastive images. However, the real fun behind this type of lens is the tilt/shift mechanism, it allows you to place your depth of field in a way that's independent of the usual f/stop method. It also allows the user to rotate the whole assemblage about the camera axis, so your T/S features can be angled at nearly any plane you see fit (it features 30° detentes on the rotate as well), so you're not merely limited to focus plane alteration in the horizontal. It's a rewarding lens to use, very versatile, but you really must shoot a lot with it to get the hand of the T/S concepts and be able to effectively use them to capture what you've envisioned. The T/S effects are most notable on a full-frame body, this is both good and bad (Chrom. Ab., vignetting, etc (no free lunch!)....however I'd recommend that one pairs it with a a FF sensor body so as to further your potential for unique perspectives with this lens.

GREGORY K.

2007-05-07T21:00:00

Rated 4 out of 5

good stuff

good quality lens. Tilt/shift effects work well however, not as dramatic as a large format bellows tilt effect. Great lens nonetheless.

jar p.

2007-02-04T19:00:00

Rated 5 out of 5

Photo comes really GREAT with 45mm TS-E!

Hard to use the lens but the photos come really NICE!

TaeLimSeeYa

Canon 45mm F/2.8 Specifications

General

General

Jump to...
  • Brand

    Canon

  • MPN

    2536A004

  • Lens Series

    Canon EF

  • Color

    Black

  • Lens Type

    Standard

  • Lens Mount

    Canon EOS

  • Format Compatibility

    Full Frame

  • Focus Type

    Manual Focus

  • Focusing Technology

    Not Applicable

  • Closest Focus Distance

    15" / 40cm

  • Distance Information

    N/A

  • Built-In Motor

    Not Applicable

  • Focal Length

    45mm

  • Angle Of View

    51 deg. (without tilt or shift)

  • 35mm Equivalent Focal Length

    Not Applicable

  • Coverage

    N/A

  • Minimum Aperture

    f/22

  • Maximum Aperture

    f/2.8

  • Maximum Magnification

    0.15x

  • Lens Coating

    N/A

  • Aspherical Elements

    N/A

  • ED Glass Elements

    N/A

  • Filter Size

    72mm

Construction

Jump to...
  • Lens Elements / Groups

    10 Elements / 9 Groups

  • Diaphragm Blades

    N/A

  • Dimensions

    3.2 x 3.5" (81.0 x 90.1mm)

  • Weight

    22.7oz / 645g

Features

Jump to...
  • Image Stabilization Type

    None

  • Tripod Collar

    Yes

  • Waterproof / Water Resistant

    N/A

  • Dust Resistant

    N/A

  • UPC Code

    082966212741

About Canon 45mm F/2.8

FEATURED REVIEWS

Go places with this lens that few others dare!

By amfoto1

I bought the 45mm TS-E lens for one use and ended up using it most of the time for completely different purposes. WIth film cameras, I mostly used it as an urban landscape or architectural lens. But now with 1.6X crop sensor digital cameras I find it an excellent macro or near macro lens! The shift and tilt capabilities are a real bonus, to give even greater control over the plane of focus. It's become my main "table top" small product lens. I also use the 24mm TS-E. Now that lens is more o...

View full Review

Photo comes really GREAT with 45mm TS-E!

By TaeLimSeeYa

Hard to use the lens but the photos come really NICE!

Normal lens featuring tilt and shift movements. The floating system and rear focusing give sharp and stable delineation from 1.3 ft. (0.4m) to infinity. The 45mm focal length is ideal for obtaining a natural-looking perspective.

Canon 45mm F/2.8 Features

  • TS rotation lets users freely combine tilting and shifting within the range of +/- 90° in the direction of movement.
  • Designed with UD glass to minimize and compensate for chromatic aberrations and a specially coated aspherical element for the highest possible glare-free image quality
  • Features an angle of view of 84° on a full-frame camera.

Key Features

  • Normal lens featuring tilt and shift movements
  • Sharp and stable delineation from 1.3 ft. to infinity
  • Focal Length & Maximum Aperture: 45mm 1:2.8
  • Lens Construction: 10 elements in 9 groups
  • Closest Focusing Distance: 0.4m / 1.3 ft

What's in the box:

  • Front Lens Cap E72
  • Rear Lens Cap E
  • EW-79BII Lens Hood
  • LP-1216 Case
  • Canon 1 Year Warranty
