| Total Harmonic Distortion (THD) |
< 0.5% |
| Intermodulation Distortion (IMD) |
(60Hz and 7kHz at 4:1)
From full rated output to -30dB: <0.3% |
| Damping Factor (8 ohm): 10 Hz to 400 Hz |
> 200 |
| Crosstalk (below rated 8Ohm power) |
At 1kHz: > 85dB
At 20kHz: >55dB |
| Input Impedance (nominal) |
20 kOhm balanced, 10 kOhm unbalanced |
| Load Impedance |
2 to 8 Ohm per channel in Stereo
4 to 8 Ohm in Bridge Mono |
| AC Line Voltage & Frequency Config(±10%) |
120 VAC 60 Hz
100 VAC 50/60 Hz
220 and 240 VAC 50 Hz |
| Ventilation |
Flow-through ventilation from front to back |
| Cooling |
Internal heat sinks with forced-air cooling for rapid, uniform heat dissipation |
| Air Volume Req (per minute per unit) |
80.15 ft3 (2.27 m3) |
| Integrated Processing |
PureBand Crossover System
Crossover Filter: Linkwitz-Riley 24dB per Octave
Crossover Frequency Range: 50 HZ - 3 kHz
Crossover Mode: Crossover (CH1=LPF, CH2=HPF), LowPass (both channels LPF), HighPass (both channels HPF), Bridge (LPF or HPF).
Peakx limiters: Channel independent clip limiter designed to provide maximum output while protecting your loudspeakers |
| Input Connectors |
XLR (one per channel), 1/4-Inch (one per channel) and RCA (one per channel). 1/4-Inch connectors can be used as loop-thrus to distribute signal to additional amplifiers. |
| Output Connectors |
Two 4-Pole Speakon Output Connectors accept 2-pole or 4-pole Speakon connectors. The top Speakon connector is wired for both channels so it can be used for bridgemono wiring or for stereo wiring of two speakers to a single Speakon connector. |
| Construction |
8.12-Inch (20.62cm) depth |
| Dimensions |
EIA Standard 19-inch (48.3-cm) rack mount width
(EIA RS-310-B), 3.5-inch (8.9-cm) height, 7.7-inch (19.6-cm) depth |
| Net Weight |
8.6 lb (3.9kg) |
