Elinchrom Quadra Hybrid Li-Ion Ringflash Set

Elinchrom
SKU: EL104051 MFR: EL 10404.1

This item is no longer available.

Elinchrom : Picture 1 regular

About Elinchrom

The Elinchrom Quadra Hybrid Li-Ion Ringflash Set is ideal for many applications such as Fashion, Portrait, Nature, Medical, Dental and Research imaging. The Quadra Ringflash combination contains the Eco-Ringflash with a white diffuser cap, a 2m flash cable and a complete Quadra Hybrid RX with a Lithium-Ion battery, multi-voltage quick charger and a shoulder belt. With the Lithium-Ion battery, the whole pack only weighs 2 kg and allows you -320 flashes at full power while being an incredible 15x8.5x18cm.

The unit can be triggered and controlled at a distance via the EL-Skyport Transmitter Speed included in this kit. No extra EL-Skyport Receiver is required as the Quadra already offers a built-in Receiver for triggering, flash power control and Group settings.

Elinchrom Features

  • El-Skyport (built-in): Radio remote control of power settings and flash triggering
  • Unique control: full control over the units with the EL-skyport app for apple devices via the optional Wi-Fi module or with the EL-skyport software via the optional USB transceiver RX
  • Power options: two outlets - 2: 1 ratio. single high power channel and single superfast channel
  • Versatility: Pre-flash detector system to enable the use of Quadra Hybrid with speedlights
  • Battery: Lithium-ion for best performance/weight
  • Security: 5V sync socket for maximum protection of digital cameras and secured battery
  • Stability: Power auto-Dump & power controlled
  • Portability: Only 2 kg with Lithium battery. Super small and lightweight heads - compact and only 0.25 kg
  • Family: With the EL-Reflector adapter all accessories and Rotalux softboxes up to 135 cm can be used

Elinchrom Specifications

Energy (Ws/J)
400
Power distribution
Asymmetrical 2:1 ratio
F-Stop (1m, 100 ISO, reflector 48deg.)
At 100%: 64.5
Power range f-stop
6.6
Power range Ws
100%: 25 - 400 - 66%
Output A: 17 - 268 - 33%
Output B: 8.2 - 132
Power range
1/1 - 1/32
Power increments in f-stop
1/10 to programmable 5/10 - 1/1
Flash duration
t0.5 at max. power in s: RQ S / A head
Output A (100%): 1/1200 / 1/2800
Output B (33%): 1/3000 / 1/5700
Output A+B (100%): 1/1500 / 1/4000
Recycling, FAST in s
Output A: 0.36 - 2.0
Output B: 0.17 - 0.73
Recycling, SLOW in s
Output A: 0.86 - 6.6
Output B: 0.33 - 2.3
Color temperature in deg.K
At max. power: 5500
Auto Power Dumping
Adjusts power settings automatically
Power stability
± 0.5%
Modeling lamp mode
On, off, programmable timer and continuous
Flashes out of one charged battery
At min. power, SLOW / FAST recycle: 4800 / 4200
At max. power, SLOW / FAST recycle: 320 / 280
Battery
Lithium-Ion 16.8 V / 3.3 Ah
Quick charger: approx. recharge time
1 h 30 min
EL-Skyport (Built-in)
Integrated transceiver, 8 Frequency Channels and 4 Groups with full RX features
Sync voltage
5 V (compatible with all cameras)
Sync socket
3.5 mm Jack
Dimensions
Ranger Quadra Hybrid including Battery box: 15x8.5x18.5cm / 5.90x3.34x7.28"
Weight
2kg / 4.40lbs
Mfr #
EL 10404.1
SKU
EL104051
Q&A

Questions & Answers Powered by TurnTo®

Questions about this item:

Todd P  Is this a ringflash set or the A Head set that comes with 2 heads? Picture makes it confusing.
Andrew R  This set includes one (1) ringflash head.
Todd P  Is this a ringflash set or the A Head set that comes with 2 heads? Picture makes it confusing.
Andrew R  This set includes one (1) ringflash head.
Todd P  Is this a ringflash set or the A Head set that comes with 2 heads? Picture makes it confusing.
Andrew R  This set includes one (1) ringflash head.
