| PANEL: Type |
TFT LCD |
| Size |
7.0-inch Diagonal (6 x 3.5 in) |
| Pixel Pitch (mm) |
0.135mm (H) x 0.135mm (V) |
| Brightness (cd/m2) |
250cd/m |
| Contrast Ratio |
800:1 |
| Viewing Angle |
160°/ 150°(H/V) (L/R: 160 deg. - U/D: 150 deg.) |
| RESOLUTION: Maximum (Analog) |
1920x1080 (maximum) |
| Native |
1024x600 |
| SIGNAL INPUT: Input Video Signal |
Input Signal: HDMI x1, Loop-through output: HDMI x1 |
| POWER: On/Working |
10W @ 12VDC |
| WEIGHT: Net(Physical) |
Weight: (Approx.) 1.06 lb (480g) |
| Voltage |
Input Voltage: DC 6.5-24V |
| Power Consumption |
10W |
| Power Supply |
Sony NPF-750 |
| Input |
Current: 800mA |
| DIMENSIONS: Physical (WxHxD) |
Size (WHD): 7.74 x 5.71 x 1.22 inches/ 196.5×145×31mm 196.5×145×41mm (with sun shade closed) 196.5×145×151.3mm (with sunshade open) |
| Key Button Functions |
Up selection key: to select items on OSD menu. Press to switch on/off 5D-II mode Down selection key: to select items on OSD menu. Press to switch on/off Pixel-to-Pixel mode. |
| Functions |
5D-II/P (Advanced Functions) 5D-II/O/P (Advanced Functions) F1-F4, 4 user-definable buttons, default function: F1: Peaking Filt er F2: False Colors F3: Exposure F4: Histogram |
| More Functions |
Peaking Filter, False Colors, Exposure, Histogram, 5D Camera, Center Marker, Pixel-to-Pixel, Aspect Ratio, Check Field, Underscan/Overscan, Freeze Input, H/V Delay, 4x Zoom, Image Flip. |
