Pharos Trips & Pics with GPS Receiver and USB Interface
Mfr. Part: PTP10 SKU: GPPHTAP
enlarge image
|
|
 |
|
|
|
Item Includes
Pharos GPS Receiver - Battery Dock - AC Adapter - USB Dongle - Trips & Pics CD - Pharos One Year Warranty
|
Description
The Pharos Trips and Pics is a trip recorder combined with photo journal. It allows you to track your trips along with trip photos and share the trip experience using Google Earth or Microsoft Streets and Trips
Make and log any journey! Pharos Trips and Pics captures your location and time automatically at any interval you set. Time your training runs. Record your child's athletic event. Show that great bicycle trip with times and photos. Save the memories from a great vacation.
Send the files to friends and family so they can see your photos and where and when you took the pictures. Add text to share even more information. Display your trips with photos on Google Earth or Microsoft Streets & Trips.
Pharos Trips and Pics automatically compensates for any difference between your camera's time and true GPS time, so the information is precise. Depending on the rate you set, the Pharos GPS logger can store from 1 ½ to 45 days of times and locations. The rechargeable battery will run the unit for 24 hours. An AC adapter is included in the package |
Features
 |
Record trips |
|
Geotag photos |
|
Work with any digital camera |
|
Results can be presented in both Google Earth and Microsoft Streets & Trips |
|
Support KMZ format for easy archiving, transporting and sharing |
|
Take input from multiple sources, including data from portable GPS devices of other companies (GPX format) |
|
Support GeoRSS for easy online sharing of your trips and geotagged photos |
|
Support both Express and Classic user interfaces. Trips & Pics Express allows a non-tech savvy user to accomplish many tasks in one click, from connecting the receiver, getting the log data from it, generating trips, to launching and viewing the result in Google Earth and Microsoft Streets & Trips |
|
Integrated with Pharos Ostia |
|
Home area shielding feature for added security when results are shared online |
|
Sophisticated trip statistics |
|
Non-dedicated hardware. The receiver and dock can be used for other GPS applications |
|
Light-weight, portable and long-lasting battery time (24 hours between charges) |
Specifications
| Chipset | SiRFstarIII GSC3fLP |
| Antenna | Integrated patch antenna |
| Frequency | L1, 1575.42 MHz |
| Sensitivity | -159 dBm |
| Channels | 20 Channel all-in-view tracking |
| Acquisition time in open sky | Cold Start: 35 sec, Hot Start: 1 sec |
| Reacquisition | 0.1 sec |
| Position update | 1Hz |
| Position | Autonomous < 10 meters, SBAS < 5m |
| Velocity | 0.1 meter/second |
| Time | 1 microsecond synchronized to GPS time |
| Datum | WGS-84 |
| Primary power | 3.3-5.5 Vdc, 50mA typical |
| Battery | 1100mAh Li-Polymer rechargeable/replaceable battery |
| OperationTime | 24 hours (typical) |
| Standard interface | USB 1.1 through USB dongle NMEA-0183 (V3.1) standard |
| Data rate | 4800 bps |
| NMEA message | GGA, GSA, GSV and RMC |
| WAAS/EGNOS | Enabled |
| Operation temperature | -10°C to 60°C (-14°F to 140°F) |
| Storage temperature | -20°C to 75°C (-4°F to 167°F) |
| Dynamics | Altitude < 20 km |
| Velocity | < 1,800 km/h |
| Acceleration | < 3g |
| Dimension | 2.82in (L) x 1.89in (W) x 0.89in (H) |
| Weight | 0.15lb (2.3 ounce) |
| Warranty | Pharos 1 year warranty |
| | |
|
|
|
|
