| Resolution |
XGA |
| Brightness |
3000 ANSI Lumens (Normal Mode) 2500 ANSI Lumens (Eco Mode) |
| Contrast Ratio |
500:1 |
| Lens |
Standard |
| Mirror |
Yes (motorized) |
| Lamp Life |
3000 hours (Normal Mode) 4000 hours (Eco Mode) |
| Diagonal display size |
60-100" (152-254cm) |
| Keystone correction |
Fixed, 10:-2.2 upward shift |
| Distance to width ratio |
0.35:1 (fixed) |
| Computer Compatibility |
IBM Compatible VGA, SVGA, XGA, SXGA / SXGA+, UXGA (compressed), MAC 16" |
| Composite Video |
NTSC / PAL / SECAM / PAL-M,PAL-N / NTSC4.43 |
| Component Video |
SDTV: 525i(480i), 525p(480p), 625i(575i) HDTV: 750p(720p), 1125i(1080i, 1035i) |
| Plug & Play |
DDC2B |
| Computer Input |
2 x 15-pin Mini D-sub |
| Computer Output |
1 x 15-pin D-sub |
| Video input |
2 x Component D-sub (shared with analogue RGB) 1 x Component 1 x RCA for composite 1 x Mini-DIN for S-Video |
| Audio input |
2 x Stereo Mini Jack 1 x RCA (L / R) (selectable on OSD) |
| Audio Output |
1 x Stereo Mini Jack |
| Control |
1 x 9-pin D-Sub for RS-232C Control |
| Power supply |
100-120 / 220-240V Auto Switching |
| Power Consumption/Standby |
340W/<5W |
| Air filter |
Hybrid |
| Noise level |
35dB (Normal Mode) / 29dB (Eco Mode) |
| Dimensions (W x H x D) |
15.6 x 5.2 x 14" (396.2 x 132.1 x 355.6mm) |
| Weight |
12.8 lbs (5.8kg) |
