| Projector Display System |
0.63" Polysilicon Active-Matrix TFT x 3 |
| Native Resolution |
1024 x 768 540 TV Lines |
| Number of Pixels |
786,432 |
| Colors |
16,700,000 Colors |
| Brightness |
3000 Lumens |
| Contrast Ratio |
2000:1 (Using Active Iris) |
| Aspect Ratio |
4:3 |
| System |
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N |
| HDTV Compatibility |
480i, 576i, 480p, 720p, 1080i, 1080p |
| Input |
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA, MAC16" |
| Sync |
H-Sync: 15kHz-106kHz V-Sync: 50Hz-120Hz |
| Lens |
F=1.2 |
| Throw Ratio |
0.3:1 |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Projection Tilt Option |
Yes |
| Built-in Speaker |
10W |
| Inputs/Outputs 1 |
RGB Input: Analog RGB: 15-pin D-sub Connector x 2 RGB Output: RGB: 15-pin D-sub Connector x 1 Digital Input: HDMI x 1 (HDCP Compliant) Video Input: S-Video: Mini DIN 4-pin Connector x 1 Composite Video: RCA Jack x 1 Component Video: 15-pin D-sub Connector (Shared with Analog RGB) Audio: Input: Stereo Mini Jack x 2 |
| Inputs/Outputs 2 |
Output: RCA (L/R) x 1 Pair Audio: Input: Microphone Jack x 1 Audio: Input: RCA (L/R) x 1 Pair Ethernet: RJ-45 Port x 1 Control Terminals: 9-pin D-sub Connector x 1 (RS-232 Control) USB Type-B x 1 (Remote Mouse) |
| Lamp (Bulb) |
210W UHP Approximately 3000 hours (Normal), 5000 hours (Eco-Mode) |
| Fan Noise |
35dB (29dB in Eco-Mode) |
| Remote Control |
Yes |
| Power Requirements |
AC90-132V/AC198-264V 50/60Hz Power |
| Power Consumption |
310W (0.3W @ Standby in Power Saving Mode) |
| Operating Temperature |
41-95 Deg.F (5-35 Deg.C) |
| Approvals |
UL, C-UL, FCC, CE |
| Dimensions (W x H x D) |
Mirror Closed: 13.6 x 3.4 x 11.9" (345.4 x 86.4 x 302.3mm) |
| Weight |
8.6 lbs (3.9kg) |
