| Camera Type | Digital AF/AE SLR |
| Recording Medium | CF Card Type I and II, SD/SDHC Memory Card (1 slot each), and/or External media (USB v.2.0 hard drive, via optional Canon WFT-E2A transmitter) |
| Image Format | 1.11 x 0.74 in./28.1 x 18.7mm (APS-H size sensor) |
| Compatible Lenses | Canon EF, TS-E, and MP-E lenses (except EF-S lenses) |
| Lens Mount | Canon EF mount |
| Lens Focal Length Conversion Factor | 1.3x |
| Image Sensor Type | High-sensitivity, high-resolution, single-plate, CMOS sensor |
| Image Sensor Pixels | Approx. 10.10 megapixels |
| Image Sensor Total Pixels | Approx. 10.70 megapixels |
| Aspect Ratio | 3:2 (Horizontal:Vertical) |
| Color Filter System | RGB primary color filters |
| Low-pass Filter | Fixed position in front of the CMOS sensor |
| Recording Format | DCF 2.0 (Exif 2.21): JPEG, RAW and RAW+JPEG simultaneous recording possible. Multiple options for recording images on two memory cards, and onto compatible external USB hard drives (via optional Wireless File Transmitter WFT-E2A) |
| Image Format | JPEG, RAW (Canon .CR2) |
| File Size | (1) JPEG/Large: Approx. 10.1MB (3,888 x 2,592)
(2) JPEG/Medium 1: Approx. 8.0MB (3,456 x 2,304)
(3) JPEG/Medium 2: Approx. 5.3MB (2,816 x 1,880)
(4) JPEG/Small: Approx. 2.5MB (1,936 x 1,288)
(5) RAW: Approx. 10.1MB (3,888 x 2,592)
(6) sRAW: Approx. 2.5MB (1,936 x 1,288) |
| Folders | Can be manually created by user, and freely selected for subsequent images. |
| File Numbering | (1) Continuous numbering (2) Auto reset (3) Manual reset (the image numbering is reset to 0001, a new folder is created automatically) |
| Color Space | Selectable between sRGB and Adobe RGB |
| Interface | USB 2.0 Hi-Speed, mini-B port. NTSC/PAL for video output |
| Settings | Auto, Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash, five Custom WB settings (1-5), user-set Color Temperature (2,500~10,000K), five Personal White Balance PC-1 to PC-5 (Total 10 WB types) |
| Auto White Balance | Auto white balance, taken from imaging sensor |
| Color Temperature Compensation | White balance bracketing: Three consecutive images, Up to +/- 3 levels in 1-stop increments White balance correction: blue/amber bias and/or magenta/green bias +/- 9 levels; manually set by user
When blue/amber bias and magenta/green bias set with White balance correction, white balance bracketing cannot be set together during white balance correction |
| Viewfinder Type | Eye-level SLR with fixed pentaprism |
| Viewfinder Coverage | Approx. 100% horizontally and vertically |
| Magnification | 0.76x (-1 dpt with 50mm lens at infinity) |
| Eyepoint | Approx. 20mm |
| Dioptric Adjustment Correction | -3.0 to +1.0 diopter |
| Mirror | Quick-return half mirror (Transmission: reflection ratio of 37:63) |
| Viewfinder Information | AF (AF points, focus confirmation light), Exposure (metering mode, spot metering area, shutter speed, aperture, manual exposure, AE lock, ISO speed, exposure level, exposure compensation, exposure warning), Flash (flash ready, high-speed sync, FE lock, flash exposure level), Image (JPEG recording, RAW recording, shots remaining, white balance correction, memory card information), Battery check |
| Depth-of-Field Preview | Enabled with depth-of-field preview button; possible in Live View mode |
| Eyepiece Shutter | Built-in |
| Autofocus Type | TTL-AREA-SIR AF-dedicated CMOS sensor |
| AF Points | 19 cross-type AF points (plus 26 Assist AF points) |
| AF Working Range | EV -1 ~18 (ISO 100 at 73°F/23°C) |
| Focusing Modes | Autofocus (One-Shot AF, Predictive AI Servo AF), Manual Focus (MF) |
| AF Point Selection | Automatic selection; Manual AF point selection: 19 AF points, Inner 9 AF points (C.Fn III-9-1), Outer 9 AF points (C.Fn III-9-2) |
| Selected AF Point Display | Superimposed in viewfinder and on LCD panel |
| AF-assist Beam | None. Emitted by EX-series Speedlite or optional ST-E2 Speedlite Transmitter |
| Metering Modes | 63-zone TTL full aperture metering:
(1) Evaluative metering (linked to all AF points)
(2) Partial metering (approx. 13.5% of screen, at center)
(3) Spot metering (approx. 3.8% of screen): Center spot metering, AF point-linked spot metering, Multi-spot metering (max. 8 spot metering entries)
(4) Centerweighted average metering |
| Metering Range | EV 0-20 (ISO 100 at 73°F/23°C with EF 50mm f/1.4 USM lens, ISO 100) |
| Exposure Control Systems | Program AE (shiftable), Shutter speed-priority AE, Aperture-priority AE, E-TTL II program AE (Evaluative flash metering, Averaged flash metering), Manual |
| ISO Speed Range | Equivalent to ISO 100-3200 (in 1/3-stop or whole stop increments), ISO speed can be expanded to ISO 50 and 6400 (via C.Fn I-3) |
| Exposure Compensation | Exposure Compensation (user-set): +/-3 stops in 1/3- or 1/2-stop increments.
Auto Bracketing (AEB): 3 shots, up to +/- 3 stops, in 1/3 or 1/2 stop increments, in all exposure modes. Can be changed via C.Fn I-6 to 2, 5, or 7 shots. Bracketing order can be changed via C.Fn I-5. |
| AE Lock | Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved
Manual (user-set): By AE lock button in all metering modes |
| Shutter Type | Vertical-travel, mechanical, focal-plane shutter with all speeds electronically controlled |
| Shutter Speeds | 1/8000 to 30 sec. (1/3-stop increments), X-sync at 1/300 sec. (with EOS Speedlites; 1/250 maximum with other shoe-mount flashes, and up to 1/60 with studio strobes) |
| Shutter Release | Soft-touch electromagnetic release |
| Self-timer | 10 sec. delay, 2 sec. delay |
| Remote Control | Canon N3 type terminal |
| EOS External Flash/Dedicated Speedlites | E-TTL II autoflash with all EX Series Speedlites |
| PC Terminal | Provided; accepts third-party flash units with sync line voltages up to 250V maximum |
| Drive Modes | Single, silent, high-speed continuous (approx. 10 fps), low-speed continuous (approx. 3 fps), 10- or 2-sec. self-timer |
| Continuous Shooting Speed | Approx. 10 fps (at a shutter speed of 1/500 sec. or faster in all recording modes); fastest speed can be lowered if desired via C.Fn III-15 |
| Max. Burst During Continuous Shooting | JPEG: approx. 110 frames (Large/Fine, at standard level 8 compression setting)
RAW: approx. 30 frames
RAW+JPEG: approx. 22 frames (Large/Fine) |
| LCD Monitor Type | TFT color, liquid-crystal monitor |
| Screen Monitor size | 3.0 in. |
| LCD Monitor Pixels | Approx. 230,000 pixels |
| LCD Monitor Coverage | Approx. 100% |
| Brightness Control | 7 levels provided |
| Image Display Format | Single image, 4-image index, 9-image index, Jump, Magnified zoom (approx. 1.5x to 10x), Histogram, Auto rotate, Rotate
Live view: view image before shooting on LCD monitor; live histogram and live simulation of exposure level possible with C.Fn IV-16-1 |
| Highlight Alert | In the single image display and (INFO) display, over-exposed highlight areas will blink |
| Protection | Single image, all images in a folder, or all images in the memory card can be protected or cancel the image protection |
| Erase | Single image, all images in a folder, all images in the memory card or check-marked images can be erased or unprotected. |
| Direct Printing from the Camera | Possible with compatible PictBridge-enabled printers |
| Compatible Printers | CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge compatible printers (via USB Interface Cable IFC-200U, included with camera kit) |
| Settings | Print quantity, style (image, paper size, paper type, printing effects, layout, date, file number), trimming |
| Dust Delete Feature | Self-cleaning sensor: IR-cut filter in front of CMOS sensor automatically vibrates at ultrasonic rates to shake off any foreign matter for approx. 4 seconds when camera is turned on or off. Can be user-activated with menu command while shooting, or completely disabled with menu command. |
| Picture Style | WAV |
| Recording Time | Max. 30 sec. per recording |
| Menu Categories | (1) Shooting (2) Playback (3) Setup, (4) Custom function/My Menu |
| LCD Monitor Language | 18 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Simplified/Traditional Chinese, Korean, Japanese) |
| Battery | One dedicated lithium-ion battery LP-E4
AC power can be supplied via the AC Adapter Kit ACK-E4 |
| Battery Check | Automatic |
| Power Saving | Provided. Power turns off after 1, 2, 4, 8, 15, 30 min. |
| Back-up Battery | One CR2025 lithium battery |
| Operating Temperature Range | 32-113°F/0-45°C |
| Operating Humidity Range | 85% or less |
| Dimensions (W x H x D) | 6.1 x 6.2 x 3.1 in./156 x 156.6 x 79.9mm |
| Weight | 40.7 oz./1,155g |
| | |
