| Camera Type |
Digital, single-lens reflex, AF/AE camera with built-in flash |
| Recording Media |
SD/SDHC/SDXC card |
| Image Format |
0.88 x 0.59 in. / 22.3 x 14.9mm (APS-C size) |
| Compatible Lenses |
Canon EF lenses (including EF-S lenses) |
| Lens Mount |
Canon EF mount |
| Sensor Type |
High-sensitivity, high-resolution, large single-plate CMOS sensor |
| Pixels |
Effective pixels: Approx. 18.0 Megapixels: 5200 (H) x 3462 (V) pixels |
| Total Pixels |
Total pixels: Approx. 19.0 Megapixels: 5432 (H) x 3492 (V) pixels |
| Aspect Ratio |
3:2 (Horizontal: Vertical) |
| Color Filter System |
RGB primary color filters |
| Low Pass Filter |
Fixed position in front of the CMOS sensor |
| Dust Deletion Feature |
Self Cleaning Sensor Unit
Dust Delete Data appended to the captured image
Manual cleaning of sensor |
| Recording Format |
Design rule for Camera File System 2.0 and Exif 2.3 |
| File Size |
Large/Fine: Approx. 17.90 Megapixels (5184 x 3456)
Medium/Fine: Approx. 8.00 Megapixels (3456 x 2304)
Small 1/Normal: Approx. 4.50 Megapixels (2592 x 1728)
Small 2/Fine: Approx. 2.50 Megapixels (1920 x 1280)
Small 3/Fine: Approx. 0.35 Megapixels (720 x 480)
RAW: Approx. 17.90 Megapixels (5184 x 3456)
M-RAW: Approx. 10.10 Megapixels (3888 x 2592)
S-RAW: Approx. 4.50 Megapixels (2592 x 1728) |
| File Numbering |
Consecutive numbering, auto reset, manual reset |
| RAW + JPEG Simultaneous Recording |
Provided (sRAW+JPEG also possible) |
| Color Space |
sRGB, Adobe RGB |
| Picture Style |
Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1-3 |
| Settings |
Auto, Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash, Custom, Color Temperature setting |
| Auto White Balance |
Auto white balance with the image sensor |
| Color Temperature Compensation |
White balance correction: ±9 stops in full-stop increments
White balance bracketing: ±3 stops in full-stop increments
Blue/amber direction or magenta/green direction possible |
| Color Temperature Info Transmission |
Provided |
| Magnification |
Approx. 0.95x (-1m-1 with 50mm lens at infinity) / 27.0deg. angle of view |
| Eye Point |
Approx. 22mm (At -1m-1 from eyepiece lens center) |
| Dioptric Adjustment Correction |
-3.0 to +1.0m-1 (diopter) |
| Focusing Screen |
Interchangeable (Ef-D: Grid lines, Ef-S: Point of focus, Ef-A standard focusing screen provided) |
| Mirror |
Quick-return half mirror (transmission: reflection ratio of 40:60) |
| Viewfinder Information 1 |
AF information (AF points and focus confirmation light), Exposure information (Shutter speed, aperture, ISO speed (always displayed), AE lock, exposure level, Spot metering circle, exposure warning), Flash information (Flash ready, flash exposure compensation, high-speed sync, FE lock, red-eye reduction light) |
| Viewfinder Information 2 |
Image information (Highlight tone priority (D+), Monochrome shooting, maximum burst (2-digit display), white balance correction, card information), Electronic level (Horizontal only), Battery check |
| Depth Of Field Preview |
Enabled with depth-of-field preview button |
| AF Points |
9 (Cross-type, Center AF point with dual cross sensor for f/2.8) |
| AF Working Range |
EV 0-20 (at 73deg.F/23deg.C with EF 50mm f/1.4 USM lens, ISO 100) |
| Focusing Modes |
Autofocus, One-Shot AF, Predictive AI Servo AF, AI Focus AF, Manual focusing (MF) |
| AF Point Selection |
Automatic selection, manual selection |
| Selected AF Point Display |
Superimposed in viewfinder and indicated on LCD panel |
| AF Assist Beam |
Small series of flashes fired by built-in flash
Effective range: Approx. 13.1 ft./4.0m at center, approx. 11.5 ft./3.5m at periphery |
| Exposure Control Systems |
Program AE (Shiftable), Shutter-priority AE (Safety shift possible), Aperture-priority AE (Safety shift possible), Manual exposure, Bulb, Full Auto, Flash Off, Creative Auto, Programmed Image Control modes (Portrait, Landscape, Close-up, Sports, Night Portrait), E-TTL II Autoflash Program AE (Evaluative metering, Averaged metering) |
| ISO Speed Range |
ISO 100 - 6400 (in 1/3-stop or whole-stop increments)
ISO 12800 can be enabled with a Custom Function
With [Highlight tone priority], the ISO speed range will be automatically set within 200-6400 |
| Exposure Compensation |
Manual: ±5 stops in 1/3- or 1/2-stop increments
AEB: ±3 stops in 1/3- or 1/2-stop increments |
| AE Lock |
Auto AE lock - In the One-Shot AF mode with evaluative metering, AE lock takes effect when focus is achieved
Manual AE lock - With AE lock button |
| Shutter |
Vertical-travel, mechanical, focal-plane shutter with all speeds electronically-controlled 1/8000 to 1/60 sec., X-sync at 1/250 sec.
1/8000 to 30 sec., bulb (Total shutter speed range. Available range varies by shooting mode) Soft-touch electromagnetic release 10-sec. or 2-sec. delay (self-timer/remote control) For Remote Switch RS-60E3 |
| Shutter Speeds |
1/8000 to 1/60 sec., X-sync at 1/250 sec.
1/8000 to 30 sec., bulb (Total shutter speed range. Available range varies by shooting mode) |
| Shutter Release |
Soft-touch electromagnetic release |
| Self Timer |
10-sec. or 2-sec. delay (self-timer/remote control) |
| Remote Control |
For Remote Switch RS-60E3 |
| Guide Number |
43/13 (ISO 100, in feet/meters) |
| Recycling Time |
Approx. 3 sec. |
| Flash Ready Indicator |
Flash-ready icon lights in viewfinder |
| Flash Coverage |
Up to 17mm focal length (equivalent to approx. 28mm in 135 format) |
| FE Lock |
Provided |
| Zooming to Match Focal Length |
Provided |
| Flash Metering |
E-TTL II autoflash |
| Flash Exposure Compensation |
±3 stops in 1/3- or 1/2-stop increments |
| External Flash Settings |
Flash function settings, Flash C.Fn settings |
| Drive Modes |
Single, high-speed continuous, low-speed continuous, 10-sec. self-timer/ remote control, or 2-sec. self-timer/remote control |
| Continuous Shooting Speed |
High-speed: Max. 5.3 shots/sec. (approx.)
Low-speed: Max. 3.0 shots/sec. (approx.) |
| Maximum Burst |
JPEG (Large/Fine): approx. 58
RAW: approx. 16
RAW+JPEG (Large/Fine): approx. 7 |
| Shooting Modes |
Live View shooting
Remote Live View shooting (with a personal computer installed with EOS Utility) |
| Focusing |
Autofocus (One-Shot AF)
Live mode - One-point, contrast AF. Switching to another AF point possible
Face Detection Live mode - Face Detection, Contrast AF. Face selectable
Quick mode - Nine-point, phase-difference AF, same as normal shooting
Manual focus - Magnify the image by 5x or 10x and focus manually |
| Metering Modes |
Real-time Evaluative metering with the image sensor |
| Metering Range |
EV 0-20 (at 73deg.F/23deg.C with EF 50mm f/1.4 USM lens, ISO 100) |
| Magnified View |
By 5x or 10x at AF point position |
| Grid Display |
Provided (Two-type grid displays) |
| Silent Shooting |
Provided (Mode 1 and Mode 2) |
| Display Type |
TFT color, liquid-crystal monitor |
| Monitor Size |
Wide 3.0-inch (Screen aspect ratio of 3:2) |
| Coverage |
Approx. 100%
Viewing angle: Approx. 160deg. |
| Brightness Control |
7 levels provided |
| Interface Languages |
25 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukraine, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Japanese) |
| Display Format 1 |
Single image display (Two types of single-image full display and two types of shooting information display), Index display (4-image index and 9-image index), Jump display (1/10/100 images, shooting date, by folder, video, stills, rating), AF point display, Histogram (1. Brightness 2. RGB), Magnify zoom display (1.5x to 10x enabled in 15 steps) |
| Display Format 2 |
Rotated display (Manual, Auto) Slide Show (Image selection: Playback according to All images, Date, Folder, Movies, Stills, or Rating; Display time: 1, 2, 3, 5, 10, or 20 sec.; Repeat: Enable/Disable; Transition effect: Off, Slide in, Fade 1, Fade 2) |
| Highlight Alert |
With single-image display (Info.) and single-image display, overexposed highlight areas will blink |
| Protection |
Erase protection can be applied/canceled for a single image, all images in a folder, or all images in the card |
| Erase |
Erase single image, erase selected images, erase all images on folder, erase all images in a card, or erase only unprotected images |
| Compatible Printers |
PictBridge-compatible printers |
| Printable Images |
JPEG images compliant to Design rule for Camera File System 2.0 and Exif 2.3 (DPOF printing possible) and RAW images captured with the EOS 60D |
| DPOF |
Version 1.1 compatible |
| Compatible Images |
Direct image transfer with the camera has been abolished since the personal computers' OS-based support has become adequate for image transfers |
| Custom Functions |
Total 20 |
| Camera User Settings |
Register under Mode Dial's setting |
| My Menu Registration |
Up to six top-tier menu options and Custom Function settings can be registered |
| Battery |
One Battery Pack LP-E6 |
| Battery Check |
Auto |
| Power Saving |
Provided. Power turns off after 1, 2, 4, 8, 15 or 30 min. |
| Date/Time Battery |
Built-in secondary battery
When fully-charged, the date/time can be maintained for about three months |
| Start-up Time |
Approx. 0.1 sec. (Based on CIPA testing standards) |
| Working Temperature Range |
32-104deg.F/0-40deg.C |
| Working Humidity Range |
85% or less |
| Dimensions (W x H x D) |
Approx. 5.69 x 4.17 x 3.09 in./144.5 x 105.8 x 78.6mm |
| Weight |
755g / 26.6 oz (CIPA)
675g / 23.8 oz (body only) |
