| Type |
Digital AF/AE single-lens reflex camera |
| Recording Media |
SD card, SDHC card, SDXC memory card
* Compatible with Ultra High Speed (UHS-I) memory cards. |
| Image Sensor Size |
35.8mm x 23.9mm (Full-Frame) |
| Compatible Lenses |
Canon EF lenses (except EF-S and EF-M lenses) |
| Lens Mount |
Canon EF mount |
| Image Sensor Type |
CMOS Sensor |
| Pixels |
Effective pixels: Approx. 20.2 megapixels |
| Total Pixels |
Total pixels: Approx. 20.6 megapixels |
| Aspect Ratio |
3:2 (Horizontal: Vertical) |
| Pixel Unit |
6.55 um square |
| Aspect Ratio |
3:2 (Horizontal: Vertical) |
| Color Filter System |
RGB primary color filters |
| Low-pass Filter |
Fixed position in front of the CMOS sensor |
| Dust Deletion feature |
Self Cleaning Sensor Unit
Dust Delete Data acquisition and appending
Manual cleaning |
| Recording Format |
Complies with Design rule for Camera File system 2.0 and EXIF 2.30 |
| Image Type |
Still: JPEG, RAW (14-bit, Canon original), RAW+JPEG
Video: MOV (Image data: H.264, Audio: Linear PCM) |
| RAW + JPEG Simultaneous Recording |
Yes
Large RAW and JPEG images are recorded simultaneously |
| Size |
Large: Approx. 20.0 megapixels (5,472 x 3,648)
Medium: Approx. 8.9 megapixels (3,648 x 2,432)
Small 1: Approx. 5.0 megapixels (2,736 x 1,824)
Small 2: Approx. 2.5 megapixels (1920 x 1280)
Small 3: Approx. 350,000 pixels (720 x 480)
RAW: Approx. 20.0 megapixels (5,472 x 3,648)
M RAW: Approx. 11.0 megapixels (4,104 x 2,736)
S RAW: Approx. 5.0 megapixels (2,736 x 1,824) |
| File Numbering |
Consecutive numbering, auto reset, manual reset |
| Color Space |
sRGB, Adobe RGB |
| Picture Style |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined 1-3 |
| Backup Recording |
Not Availabled |
| White Balance Settings |
Auto, Preset (Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash), Custom (Approx. 2,000° - 10,000°K), Color Temperature (Approx. 2,500° - 10,000°K), White Balance Correction, and White Balance Bracketing |
| Auto White Balance |
Auto white balance with the image sensor |
| Color Temperature Compensation |
Blue/amber bias: ±9 levels
Magenta/green bias: ±9 levels
* Correction based on the current WB mode's color temperature |
| Color Temperature Info Transmission |
Provided |
| Viewfinder Type |
Eye-level SLR (with fixed pentaprism) |
| Viewfinder Coverage |
Vertical/Horizontal approx. 97% |
| Viewfinder Magnification / Angle |
Approx. 0.71x / 33.3 Degree |
| Viewfinder Eyepoint |
Approx. 21mm (from eyepiece lens center) |
| Built-in Dioptric Adjustment |
-3.0 to +1.0m-1 (diopter) |
| Focusing Screen |
Eg-A II provided. Interchangeable with Eg-D and Eg-S. Incompatible with Eg-A. |
| Viewfinder Mirror |
Quick-return half mirror (transmission: reflection ratio of 40:60) |
| Viewfinder Information |
AF information:AF points and focus confirmation
Exposure information: Shutter speed, aperture, ISO speed (always displayed), AE lock, exposure level, exposure warning
Flash information:Flash ready, flash exposure compensation, high-speed sync, FE lock
Image information:Highlight tone priority (D+), maximum burst (2-digit display), card information
Battery check
Composition information: Electronic level
Warning Symbol |
| Depth-of-Field Preview |
Enabled with depth-of-field preview button |
| AF Points |
11 pointsall cross-type AF (f/2.8 at center: Dual Cross Sensor)
Center: cross-type at f/5.6; vertical line-sensitive at f/2.8.
Upper and lower AF points: vertical line-sensitive AF at f/5.6.
Other AF points: Horizontal line-sensitive AF at f/5.6. |
| AF Working Range |
Center AF Point: EV -3 to 18 (at 73°F/23°C, ISO 100)
Other AF points: EV +0.5 to 18 (at 73°F/23°C, ISO 100) |
| Focusing Modes |
Autofocus: One-Shot AF - AI Servo AF - AI Focus AF
Manual focus |
| AF Point Selection |
Automatic selection
Manual selection |
| Selected AF Point Display |
Displayed or indicated by superimposed display in the viewfinder and on the LCD monitor. |
| AF-assist Beam |
Enable
Disable
IR AF-assist beam only |
| Metering Modes |
Max. aperture TTL metering with 63-zone SPC with the following selectable modes:
1) Evaluative metering
2) Partial metering (center: approx. 8% of viewfinder)
3) Spot metering (center: approx. 3.5% of viewfinder)
4) Center-weighted average metering |
| Metering Range |
EV 1-20 (at 73°F/23°C with EF50mm f/1.4 USM lens, ISO 100) |
| Exposure Control |
Creative Zone
Program AE (Shiftable), Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb, Custom shooting mode,
Basic zone
Scene Intelligent Auto (Program AE / non-shiftable), Creative Auto
Special Scene
Portrait, Landscape, Close-up, Sports, Night Portrait, Handheld Night Scene, HDR Backlight Control mode |
| ISO Speed (Recommended Exposure Index) |
Auto and Manual setting range of ISO 100-25600 (expansion possible to ISO 50, ISO 51200 and 102400) in 1/3-stop or whole-stop increments) |
| Exposure Compensation |
Manual: ±5 stops in 1/3- or 1/2-stop increments
AEB : ±3 stops in 1/3- or 1/2-stop increments |
| AE Lock |
Yes |
| Shutter Type |
Vertical-travel, mechanical, focal-plane shutter with all speeds electronically-controlled |
| Shutter Speeds |
1/4000 to 30 sec., X-sync at 1/180 sec. (Total shutter speed range. Available range varies by shooting mode.) |
| Shutter Release |
Soft-touch electromagnetic release |
| Shutter Lag Time |
(1) During SW-1 ON, time lag between SW-2 ON and start of exposure: approx. 0.060 sec.
(2) Time lag between simultaneous SW-1/SW-2 ON and start of exposure: Approx. 0.144 sec.
* Time lag with the aperture stopped down by 3.5 stops or less (Excludes AF operation time). |
| Self-timer |
10-sec. or 2-sec. delay |
| Compatible Speedlites |
EX-series Speedlites |
| Flash Metering |
E-TTL II autoflash (evaluative flash metering and average flash metering) |
| Flash Exposure Compensation |
±2 stops in 1/3- or 1/2-stop increments |
| External Speedlite Control |
Provided
* Compatible with radio wireless flash photography. |
| FE Lock |
Provided |
| Drive Modes |
(1) Single shooting
(2) Continuous shooting
(3) Silent single shooting
(4) Silent continuous shooting
(5) 10-sec. self-timer/Remote control
(6) 2-sec. self-timer |
| Continuous Shooting Speed |
Continuous shooting: Max. approx. 4.5 fps
Silent continuous shooting: Max. approx. 3.0 fps |
| Maximum Burst |
Based on 8GB memory Card:
JPEG Large/Fine: Approx. 73 Shots
RAW: Approx. 14 Shots
RAW+JPEG Large/Fine: 7 Shots
Based on 8GB UHS-I memory card:
JPEG Large/Fine: Approx. 1250 Shots
RAW: Approx. 17 Shots
RAW + JPEG Large/Fine: 8 Shots |
| Focusing |
(1) Autofocus
1. FlexiZone - Single * One-point, contrast AF. Switching to another AF point is possible.
2. Face Detection Live mode
* Face detection, contrast AF. Face is selectable.
2. Face Detection Live mode
* Face detection, contrast AF. Face is selectable.
3. Quick Mode AF
* Phase-difference AF with 11 AF points.
(2) Manual Focus 1. Magnify the image by 5x or 10x and focus manually. |
| Metering Modes |
Real-time evaluative metering with image sensor.
(1) Evaluative metering (315 zones)
(2) Partial metering (approx. 11% of Live View screen)
(3) Spot metering (approx. 3% of Live View screen)
(4) Center-weighted average metering |
| Metering Range |
EV 1-20 (at 73°F/23°C with EF 50mm f/1.4 USM lens, ISO 100) |
| Grid Display |
Provided (Two-type grid displays) |
| Exposure Simulation |
Provided |
| Silent Shooting |
Provided (Mode 1 and 2) |
| Video File Format |
MOV (Image data: MPEG-4 AVC / H.264)
Audio: Linear PCM (Stereo) |
| Video Frame Rates |
1920 x 1080 (Full HD): 30p (29.97) / 24p (23.976) / 25p
1280 x 720 (HD): 60p (59.94) / 50p
640 x 480 (SD): 30p (29.97) / 25p |
| Video ISO Range |
Auto ISO range: ISO 100-12800
Manual ISO range: ISO 100-12800 in 1/3- or whole-stop increments (expandable to H: ISO 16000/20000/25600)
* If highlight tone priority is set, automatically set within ISO 200 or higher. |
| Video Shooting Time |
Based on 8GB Memory card
[1920 x 1080]
30 fps/25 fps/24 fps:
32 min. with IPB compression
11 min. with All-I compression
[1280 x 720]
60 fps/50 fps:
37 min. with IPB compression
12 min. with All-I compression
[640 x 480]
30 fps/25 fps:
97 min. with IPB or All-I compression |
| LCD Monitor Type |
TFT color, liquid-crystal monitor |
| Monitor Size |
3.0-inches (Screen aspect ratio of 3:2)
7.7cm diagonal (6.37cm wide, 4.25cm high) |
| Monitor Dots |
Approx: 1,040,000 dots |
| Monitor Coverage |
Approx. 100% |
| Brightness Adjustment |
Manually adjustable to one of 7 levels |
| Interface Languages |
25 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian,Ukraine, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Japanese) |
| Image Playback Display Format |
Single image display
Two types of single-image full display, two types of shooting information
Index display
o 4-image index and 9-image index
Jump display
Jump 1/10/100 images, Shooting Date, Folder, Movies, Stills, or Rating |
| Highlight Alert |
With single-image display (Info.) and single-image display, overexposed highlight areas will blink. |
| Histogram |
Brightness and RGB can be displayed. |
| USB Terminal |
For personal computer communication and direct printing (USB 2.0 Hi-Speed) |
| Audio/Video (Out) Terminal |
Audio/Video (Out) Terminal (1) AV stereo OUT terminal: NTSC/PAL selectable
(2) mini-HDMI OUT terminal (Type C) |
| Remote Control Terminal |
N3-type terminal |
| Battery |
One Battery Pack LP-E6
With the AC Adapter Kit ACK-E6, AC power is possible.
With Battery Grip BG-E13, two battery packs (LP-E6) can be used. Or six AA-sized/LR6 batteries can be used |
| Dimensions (W x H x D) |
Approx. 5.7 x 4.4 x 2.8 in./ 144.5 x 110.5 x 71.2mm |
| Weight |
Approx. 26.7 oz. / 755g (CIPA standard)
Approx. 24.0 oz. / 680g (Body only) |
