| Sensor |
1/2.3-inch CMOS |
| Total Pixels |
Approx. 12.8 Megapixels |
| Effective Pixels |
Approx. 12.1 Megapixels |
| Focal Length |
5.0 (W) to 25.0mm (T)
(35mm film equivalent: 28 (W) to 140mm (T)) |
| Digital Zoom |
4x |
| Focusing Range |
Normal: 2.0 in. (5cm) to infinity (W), 3.3 ft. (1m) to infinity (T)
Auto: 0.4 in. (1cm) to infinity (W), 3.3 ft. (1m) to infinity (T)
Macro: 0.4 in. to 1.6 ft. (1-50cm) (W) |
| Autofocus System |
TTL Autofocus |
| LCD Monitor |
3.0-inch TFT Color with wide-viewing angle |
| LCD Pixels |
Approx. 461,000 dots |
| LCD Coverage |
Approx. 100% |
| Maximum Aperture |
f/3.9-f/4.8 |
| Shutter Speed |
1-1/1600 sec.
15-1/1600 sec. (Total shutter speed range) |
| Sensitivity |
Auto, ISO 100/200/400/800/1600/3200 (When in P mode) |
| Light Metering Method |
Evaluative, Center-weighted average, Spot |
| Exposure Control Method |
Program AE, i-Contrast, AE Lock |
| Exposure Compensation |
+/-2 stops in 1/3-stop increments (not available when shooting movies) |
| White Balance Control |
Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Underwater, Custom |
| Built-in Flash |
Auto, Red-eye Reduction, Auto Red-eye Correction, Flash On, Flash Off; FE lock, Slow Synchro |
| Flash Range |
12 in. to 11 ft. (W), 3.3 in. to 9.8 ft. (T)
(30cm to 3.4m (W), 1.0 to 3.0m (T)) |
| Recycling Time |
10 sec. or less (battery voltage: 3.7 V) |
| Shooting Modes |
P, Auto, Movie Digest, Portrait, Smart Shutter, Handheld Night Scene, Low Light, Fisheye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Super Vivid, Poster Effect, Color Accent, Color Swap, Underwater, Underwater Macro, Snow, Fireworks, Long Shutter, Stitch Assist, iFrame Movie, Super Slow Motion Movie |
| Photo Effects |
My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin, Darker Skin, Vivid Blue, Vivid Green, Vivid Red, Custom Color |
| Self Timer |
Approx. 10-sec. delay, approx. 2-sec. delay, custom |
| Continuous Shooting |
Approx. 1.9 shots/sec. (in P Mode)
Approx. 1.9 shots/sec. (in Low Light Mode) Approx. 6.8 shots/sec. (in High-Speed Burst mode) |
| Storage Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| File Format |
Design rule for Camera File system, DPOF (Version 1.1) compliant |
| JPEG Compression Mode |
Still Image: Exif 2.3 JPEG
Video: MOV (Image data: H.264; Audio data: Linear PCM (monaural)) |
| Number of Recording Pixels: Still Images |
[16:9]
Large: 4000 x 2248, Medium 1: 2816 x 1584
Medium 2: 1920 x 1080, Small: 640 x 360
[3:2]
Large: 4000 x 2664, Medium 1: 2816 x 1880
Medium 2: 1600 x 1064, Small: 640 x 424
[4:3]
Large: 4000 x 3000, Medium 1: 2816 x 2112
Medium 2: 1600 x 1200, Small: 640 x 480
[1:1]
Large: 2992 x 2992, Medium 1: 2112 x 2112
Medium 2: 1220 x 1200, Small: 480 x 480 |
| Number of Recording Pixels Videos |
[iFrame Movie]
1280 x 720 (30 fps)
[Super Slow Motion Movie]
640 x 480, 320 x 240
[Miniature Effect]
1280 x 720, 640 x 480
[Other than the above]
1920 x 1080 (24 fps), 1280 x 720 (30 fps), 640 x 480 (30 fps) |
| Playback Modes File Stills & Videos |
Auto Rotate (Automatic vertical/horizontal detection), Image Advance (Operation Tools, Transition effects, Scroll Display), Rotate, Favorites, My Category, Smart Shuffle, Filtered Playback, Slide Show (Playback Interval, Repeat, Effect, Playlist) |
| Playback Modes File Still Images |
Single, Index (4-100 thumbnails), Magnification (2x-10x), Information Display, Red-eye Correction, i-Contrast, Trimming, Resize, My Colors, Focus Check, Histogram, Overexposure Warning |
| Playback Modes File Videos |
Normal Playback, Slow Motion, Special Playback, Editing, Resume |
| Erase Modes |
Select image, select range, all images (all filtered images) |
| Video Out |
NTSC/PAL (Dedicated connector (female) with unified type of digital, audio and video), Mini-HDMI connector |
| Audio Out |
Monaural (Dedicated connector (female) unified type of digital, audio and video) |
| Other Interfaces |
Mini-HDMI cable: connection to high definition monitor; SD Memory card slot; direct connection to Canon SELPHY Compact Photo Printers, PIXMA Inkjet Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-speed cable |
| Power Source |
Rechargeable lithium-ion Battery NB-6L
Compact Power Adapter CA-DC10 (included with AC Adapter Kit ACK-DC40) |
| Shooting Capacity |
Approx. 280 shots |
| Playback Time |
Approx. 5 hours |
| Operating Temperature |
14 to 104Deg.F/10 to 40Deg.C |
| Operating Humidity |
10 to 90% |
| Dimensions (W x H x D) |
4.42 x 2.79 x 1.10 in. / 112.3 x 70.8 x 28.0 mm |
| Weight |
Approx. 7.23 oz. (205g) (camera only)
Approx. 8.04 oz. (228g) (including the battery and memory card) |
