IDX Duo 95 91Wh Li-ion V-Mount Battery with USB Output

IDX
IDX : Picture 1 thumbnail IDX : Picture 2 thumbnail IDX : Picture 3 thumbnail

List Price: $380.00

Our Price

$324.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About IDX

The IDX DUO 95 91Wh Li-ion V-Mount Battery is aimed at the emerging smaller form factor Cinema Cameras. Lightweight but still capable of taking a robust 6.3A/76W load. There are dual built-in D-Tap connectors and a dedicated USB power output to power the peripherals necessary to get the best from these system cameras.

IDX Features

  • 2 x (D-Tap) DC output connectors each capable of taking a 50W load within the maximum draw of 76W
  • USB Type-A power output, regulated at 5V (1A/5W max draw). Auto shut off function when not active for 30min
  • 5 Power Status LED's are located on the side of the DUO-95 for a quick and accurate check of remaining capacity
  • Battery circuit protection ensures the DUO-95 is fully protected against common causes of battery misuse, guarding against over charge, over discharge, over current and exposure to high temperatures
  • 12V auto cut-off prevents over-discharging (while a load is applied)
  • Lightweight compact high performance Li-ion battery with a durable innovative design
  • Attaching DUO-95 batteries to cameras without a standard V-Mount connection is possible through the use of P-V2 and P-VS2 adaptor plates, available separately from IDX
  • Unrestricted spare DUO-95 batteries for carry-on airline baggage under IATA regulations
  • The DUO-95 is fully compatible with all ENDURA V-Mount chargers and accessories

IDX Specifications

Battery Capacity
91Wh (14.4V, 6.3Ah)
Max. Output Voltage
16.8V DC
Nominal Voltage
14.4V DC
Max. Discharge Current
6.3A / 76W (total with D-Taps & USB)
D-Tap: 4.1A / 50W each
USB: 1A / 5W
End Voltage
12V (Auto cut-off protection)
Battery Protection
Reverse charge
Over charge (reset)
Over discharge (reset)
Over current (reset)
Temperature protection
Ambient Temperature
To charge
32deg.F - 104deg.F (50deg.F - 86deg.F recommended)
To discharge
-4deg.F - 113deg.F (50deg.F - 104deg.F recommended)
To store
-4deg.F - 122deg.F (one month)
Dimensions (WxHxD)
3.82x5.75x2.32" / 9.70x14.60x5.89cm
Weight
1.76lbs / 0.8kg
