Epson BrightLink 485Wi Interactive Projector with Table Mount, 3100 Lumens Color/White Light Output, 1280x800 WXGA Resolution

SKU: IESBL485T MFR: V11H452520T
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

$2,099.00
Free Shipping
Qty:

Add to Wishlist

Protect your investment

About the Epson 485Wi

The Epson V11H452520T is a BrightLink 485Wi Interactive Projector with Table Mount. This high-performance, network-ready projector and interactive pens integrate interactive functionality into one machine without the constraints or expense of an interactive whiteboard.

Annotate from any source - directly on projected images sent over the network or on content from DVD/Blu-ray players and document cameras - without the use of a computer.

Plus, with dual pen support, two users can write simultaneously, making it easier than ever to actively engage your students in the curriculum. And, setup is easy with auto calibration and no PC driver to install.

The impressive ultra-short-throw projection of BrightLink 485Wi means you can project large, interactive, WXGA images up to 100" without shadow interference.

Add versatile wall or table mounting options, HDMI connectivity, a built-in 16 W speaker and convenient microphone jack and these fully loaded BrightLink projectors open the world to interactivity 3.0.

Epson 485Wi Includes

  • Epson BrightLink 485Wi Ultra-Short Throw Interactive Projector
  • BrightLink Welcome Kit
  • Quick User's Guide
  • Electronic User Manual
  • Projector Remote Control
  • 2x Interactive Pens
  • Pen Tray
  • 2x AA Batteries + Battery Charger
  • 2x AA Batteries
  • Power Cable
  • USB A/B Cable
  • Interactive Driver for Mac
  • Epson Easy Interactive Tools
  • Network Management Software
  • Teamboard Draw Software for Win & Mac
  • PrivateLine Support Card
  • Password Protection Sticker
  • Epson 2 Years Limited Warranty

Epson 485Wi Features

  • Built-in interactivity - powerful projector plus pen combination provides complete interactive solution without the need for expensive electronic whiteboard
  • PC-Free annotation - write on projected images from iPads, document cameras and Blu-Ray players, or directly on ordinary white boards without ever connecting to a computer
  • Dual Pen Support - innovative pen technology allows two users to annotate simultaneously, anywhere on the board
  • Easy setup - no driver installation; auto calibration; convenient tools including horizontal keystone correction, Quick Corner and more
  • Eliminate shadowing - project ultra-bright, ultra-wide WXGA images up to 100" from less than 13" away
  • Ultra Flexible - versatile mounting solutions transform most any wall or table into an interactive learning center
  • Bright performance - 3100 lumens color/white light output
  • Future-ready connectivity - HDMI digital connectivity for classrooms with the latest devices
  • Value-added communication features - built-in 16 W speaker, audio pass-through, microphone input and built-in closed captioning decoder
  • Versatile network connectivity - RJ-45 LAN connectivity for remote audio/video presentations and control; optional wireless capabilities for even greater flexibility
  • Energy-efficient lamp - up to 4000-hour lamp life
  • Added versatility - partner your projector directly with the Epson DC-06 document camera via USB
  • High-efficiency filter - 2x the surface area of previous filters for better protection against dust; cleaning schedule up to 5000 hours

Epson 485Wi Specifications

Projection System EPSON 3LCD, 3-chip technology
Projection Method Front / Rear / Wall Mount / Table
Driving Method Poly-silicon TFT Active Matrix
Pixel Number 1,024,000 dots (1280 x 800) x 3
Color Light Output 3100 lumens
White Light Output 3100 lumens (ISO 21118 standard)
Aspect Ratio 16:10
Native Resolution 1280 x 800 (WXGA)
Resize 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA / 435Wi only), 1152 x 864 (SXGA), 1280 x 800 (WXGA / 430i only), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA 60-1 / 430i only), 1360 X 768 (WXGA 60-2), 1440 X 900 (WXGA+), 1400 X 1050 (SXGA+), 1600 X 1200 (UXGA)
Lamp Type 215 W UHE
Lamp Life ECO mode: Up to 4000 hours
Normal mode: Up to 3000 hours
Size (projected distance) 4:3: 53" - 88"
16:9: 59" - 97"
16:10: 60" - 100
Keystone Correction Manual:
Vertical: ±15 degrees
Horizontal: ±15 degrees
USB Plug 'n Play Mac 10.5 or later
USB Plug 'n Play for Windows 2000 or later
Contrast Ratio Up to 3000:1
Color Reproduction 16.77 million colors
Projection Lens Type Manual focus
F-number 1.8
Focal Length 3.71 mm
Throw Ratio Range 4:3: 0.33 - 0.44
16:9: 0.27 - 0.37
16:10: 0.27 - 0.3
Zoom Ratio Digital zoom 1.0 - 1.35x
Display Performance NTSC: 480 lines
PAL: 560 lines
Input Signal NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60/ SECAM
Interfaces HDMI
Computer / component video: D-sub 15 pin x 2
S-video: Mini DIN x 1
Composite video: RCA x 1
Audio in x 3: RCA (L and R) x 1, Mini stereo x 2
Variable audio out: Mini stereo x 1
LAN networking: RJ-45 x 1
Serial: RS-232c x 1
Monitor out: D-sub 15 pin x 1
USB Type B x 1 (USB display, mouse, interactivity)
USB Type A x 1 (USB memory/document camera)
Wireless port 802.11 b/g/n (optional module sold separately)
Microphone port
Speaker 16 W monaural
Operating Temperature 41deg. to 95deg. F (5deg. to 35deg. C)
Power Supply Voltage 100 - 240 V ±10%, 50/60 Hz AC
Power Consumption Normal mode: 313 W
Communication on: 7.5 W standby
Communication off: 0.21 W standby
Direct Power On / Off
Instant Off
Fan Noise ECO mode: 28 dB
Normal mode: 35 dB
Security Kensington security lock port, padlock and security cable hole, password protect function
Interactive Technology Infrared; 940 nm
Interactive Area 60" to 100" diagonal (16:10, WXGA)
Interactive Modes Computer interactivity / input
Interactive and Whiteboard modes, Dual user
PC-Free input
Annotation, Single user
Calibration Method Automatic or Manual
Interactive Connectivity USB cable required
Interactive Software Requirements-1 Easy Interactive Driver:
Windows and Linux: No driver required
Macintosh: Mac OS X 10.3.9, 10.4.x, 10.5.x, 10.6.x, 10.7.x
Easy Interactive Tools
Microsoft Windows XP SP2, Windows XP SP3, Windows Vista, Windows Vista SP1, Windows Vista SP2, Windows 7, Windows 7 SP1
Macintosh OS X 10.4.x, Mac OS X 10.5.x, Mac OS X 10.6.x, Mac OS X 10.7.x
Interactive Software Requirements-2 TeamBoard Draw Software (included)
Windows XP SP3, Windows Vista, Windows 7, Quicktime player and Flash player installed
Macintosh Intel Mac OS X 10.5x or later
RM Easiteach Next Generation (optional)
Windows XP SP3, Windows Vista, Windows 7
Apple Macintosh 10.5 or later
PC-Free Annotation Supported, single user
PC-Free Annotation Tools EPSON Easy Interactive Tools
PC-Free Annotation Sources Document cameras, DVD / Blu-Ray player, iPod / iPad devices
Type of Interactive Input Device Digital pen (two included)
Multiple Pen Support Yes, Dual pen
Interactive Pen Functions Mouse functions (left and right click), Electronic pen, LED battery status indicator
Interactive Pen Power AAA batteries, rechargeable
Compatible Pen Battery Types SANYO eneloop(HR-3UTG / HR-3UTGA)3, Manganese dry cell, alkaline dry cell
Remote Control Operating Angle Rear
Right / Left: ±55 degrees
Upper / Lower: +75 to +15 degrees
Front
Right / Left: ±30 degrees
Upper / Lower: 0 to +60 degrees
Remote Control Operating Distance 19.7' (6 m)
Interactive Pen Dimensions (L x W) 6.5 x 0.98" / 16.51 x 2.48cm
Dimensions (W x D x H) Excluding feet: 14.5 x 14.8" x 5.7" / 36.83 x 37.59 x 14.47cm
Weight Without slide plate: 11.9 lb/ 5.39kg
With slide plate: 13.5 lb/ 6.12 kg
Interactive Pen: 1.2 oz / 34.01g
