| Scanner Type |
Sheet-fed, one-pass duplex color scanner |
| Photoelectric Device |
Color Epson MatrixCCD line sensor |
| Optical Resolution |
600 dpi |
| Output Resolution |
75 to 600 dpi |
| Effective Pixels |
5,100 x 21,600 pixels |
| Color Scan Mode (output bit depth) |
48-bit internal/24-bit external |
| Grayscale Scan Mode (output bit depth) |
16-bit internal/8-bit external |
| Monochrome (output bit depth) |
1-bit |
| Automatic Document Feeder Capacity |
75 sheets |
| Automatic Document Feeder Speed |
25 ppm (Simplex) 50 ipm (Duplex) (A4 size, 200 dpi, Speed Priority) |
| Document Feeder Paper size Minimum |
2.1" x 2.9" (53.5 x 73.7 mm) |
| Document Feeder Paper size Maximum |
8.5" x 36" (216 x 914.4 mm) |
| Document Feeder Paper size Paper weight |
45 to 200 g/m2 |
| Buttons |
4 push buttons: Start, Cancel, Up-arrow, Down-arrow; Mechanical power switch |
| Light Source |
ReadyScan LED technology |
| Interface |
Hi-Speed USB 2.0 |
| Scanning Speed Full Color |
1.230 msec/line |
| Scanning Speed Grayscale |
1.230 msec/line |
| Scanning Speed Monochrome (A4, 300 dpi) |
1.230 msec/line |
| Daily duty cycle |
1200 sheets |
| Consumables |
Roller assembly kit - 100,000 cycles |
| Operating Temperature |
Operating 50 ° to 95 °F (10 ° to 35 °C) |
| Operating Humidity |
10 - 80% (no condensation) |
| Voltage |
100 - 240 VAC |
| Frequency |
50 - 60 Hz |
| Power consumption |
40 W |
| Power consumption Ready |
13 W |
| Power consumption Sleep |
5.5 W |
| Power consumption Off |
1 W |
| Windows Requirements |
Intel Pentium II 450 Mhz with 128MB of RAM (512MB of RAM for XP Professional x64 and Windows Vista) and 215MB of free hard disk space, Microsoft Windows 2000 Professional, XP Home Edition, XP Professional, XP Professional x64, Windows Vista (32/64-bit), USB 2.0 |
| Macintosh Requirements |
PowerPC G3 400 Mhz or Intel-based CPU with 128MB of RAM or higher and 200MB of free hard disk space Mac OS X 10.3.9 - 10.5.x, USB 2.0 |
| Other Features |
Rigid plastic ID card scanning (including embossed cards) Business card scanning 10 user-definable one-button scan job settings with personalized job descriptions on LCD display 2 line x 16 character LCD Security lock (Kensington type) |
| Software |
Epson Scan EMC Captiva ISIS ABBYY FineReader Sprint Plus OCR Nuance ScanSoft PaperPort SE NewSoft Presto! BizCard 5 TWAIN and ISIS drivers |
| Dimensions |
11.9" (W) x 8.0" (D) x 8.4" (H) |
| Weight |
11 lbs (5 Kg) |
| Warranty |
Epson 1 year limited warranty |
