| Projection System |
Epson 3LCD, 3-chip optical engine |
| Projection Method |
Front / rear / ceiling mount |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
786,432 dots (1024 x 768) x 3 |
| White Light Output |
2600 lumens (ISO 21118 Standard) |
| Color Light Output |
2600 lumens |
| Aspect Ratio |
4:3 |
| Native Resolution |
1024 x 768 (XGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1152 x 864 (SXGA), 1280 x 800 (WXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1440 x 900 (WSXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA) |
| Lamp Type |
E-TORL 200 W UHE |
| Lamp Life |
ECO mode: Up to 6000 hours
Normal mode: Up to 5000 hours |
| Effective Scanning Frequency Range |
Pixel Clock: 13.5MHz to 162MHz
Horizontal: 15KHz to 92KHz
Vertical: 50Hz to 85Hz |
| Throw Ratio Range |
1.39 - 2.26 (4:3) |
| Size (projected distance) |
30" - 300" (2.7' - 45.5') |
| Keystone Correction |
Automatic: Vertical: ±30 degrees |
| USB Plug 'n Play |
PC & Mac compatible |
| Contrast Ratio |
Up to 2000:1 |
| Color Reproduction |
16.77 million colors |
| Projection Lens Type |
Manual focus / Optical zoom |
| F-number |
1.49 - 1.94 |
| Focal Length |
18.2 mm - 29.2 mm |
| Zoom Ratio |
Optical zoom 1.0 - 1.6 |
| Display Performance |
NTSC: 480 line
PAL: 560 line (depends on observation of the multi-burst pattern) |
| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM |
| Interfaces |
Computer/Component video: D-sub 15 pin x 2
Audio in x 3 (RCA (L&R) x 1, mini stereo x 2)
Variable Audio Out: mini stereo x 1
USB connector: Type B x 1 (USB display and mouse/keyboard control), Type A x 1 (for USB memory device)
Serial: RS-232c x 1
LAN Networking: RJ-45 x 1
Monitor Out: Mini D-sub 15 pin x 1
Microphone: stereo mini jack x 1
Wireless LAN port: 802.11 a/b/g (optional - module sold separately) |
| Speaker |
10 W monaural |
| Operating Temperature |
41 deg. to 95 deg. F (5 deg. to 35 deg. C) |
| Power Supply Voltage |
100 - 240 V ±10%, 50/60 Hz |
| Power Consumption |
Normal mode: 289 W
Communication on: 9.4 W Standby
Communication off: 0.4 W Standby |
| Fan Noise |
ECO mode: 28 dB
Normal mode: 35 dB |
| Security |
Kensington-style lock provision
Padlock and security anchor bar |
| Operating Angle |
Right / Left: ±30 degrees
Upper / Lower: ±30 degrees |
| Operating Distance |
19' |
| Dimensions (W x D x H) |
Including feet: 12.9" x 9.8" x 4.3" / 327.66 x 248.92 x 185.42 mm
Excluding feet: 12.9" x 9.8" x 3.7" / 327.66 x 248.92 x 91.44 mm |
| Weight |
7.0 lb / 3.2 Kg |
