| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM |
| NTSC Display |
480 lines |
| PAL Display |
560 line |
| Interfaces |
Computer: D-Sub 15 pin x 1 Component Video: RCA x 3 (Red/Green/Blue) Composite video: RCA (Yellow) x 1 Audio in: RCA x 2 (White/Red) USB connector: Type B x 1, Type A x 1 (USB memory) HDMI port Microphone input Headphone output (stereo mini jack) Digital Audio Output (Coaxial) |
| Projection System |
Epson 3LCD, 3-chip optical engine |
| Projection Method |
Front only |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
1,024,000 dots (1280 x 800) |
| White Light Output |
2500 lumens (ISO 21118 Standard) |
| Color Light Output |
2500 lumens |
| Aspect Ratio |
16:10 |
| Native Resolution |
1280 x 800 (WXGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+) |
| Throw Ratio Range |
1.30 - 1.56 (16:10) 1.56 - 1.87 (4:3) |
| Plug 'n Play |
Projector is Mac compatible via DVI to HDMI or VGA adapter (not included) USB Plug 'n Play for Windows 2000 or later |
| Projection Lens Type |
Manual zoom/Manual focus |
| F-number |
1.58 - 1.72 |
| Focal Length |
16.9 mm - 20.28 mm |
| Zoom Ratio |
Optical zoom 1.0 - 1.2 |
| Lamp Type |
200 W UHE (E-TORL) |
| Lamp Life |
Up to 5000 hours (Eco Mode) Up to 4000 hours (Normal Mode) |
| Screen Size: (Projected Distance) |
33" - 318" (2.75' - 26.5') |
| Keystone Correction Automatic |
Vertical: ± 11 degrees |
| Keystone Correction Manual |
Vertical: ± 30 degrees |
| Contrast Ratio |
Up to 3000:1 |
| Color Reproduction |
16.77 million colors |
| Sound Output |
Speaker: 10 W x 2 (stereo) |
| Operating Temperature |
41° to 95° F (5° to 35° C) |
| Power Supply Voltage |
100 - 240 V ±10%, 50/60 Hz |
| Power Consumption |
310 W, 0.3 W Standby |
| Fan Noise |
33 dB (Normal) 29 dB (Eco) |
| Remote Control Features |
Source search selection, power, aspect, color mode, volume, A/V mute, menu, page up and down, keystone, mic input level, DVD control, eject, surround, aspect, zoom, user, visual setup, setup, return, mute, audio, subtitle, angle |
| Remote Control Operating Angle |
Right/left: ± 30 degrees Upper/lower: ± 15 degrees |
| Remote Control Operating Distance |
19' (6 m |
| Security |
Kensington-style lock provision, security cable hole, Padlock |
| Dimension |
Including feet: 13.2" x 9.4" x 5.4" Excluding feet: 13.2" x 9.4" x 5.0" |
| Weight |
9.5 lb/4.3 kg |
| Warranty |
Epson 2 years projector and 90-day lamp limited warranty |
