| Projection System |
3LCD, 3-chip technology, RGB liquid crystal shutter projection system |
| Projection Method |
Front / rear / ceiling mount |
| Driving Method |
Poly-silicon TFT Active Matrix |
| Pixel Number |
1,024,000 dots (1280 x 800) x 3 |
| Color Brightness (Color Light Output) |
3000 lumens x 2 projectors |
| White Brightness (White Light Output) |
3000 lumens x 2 projectors |
| Aspect Ratio |
Native 16:10 widescreen |
| Native Resolution |
1280 x 800 (WXGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1360 x 768 (WXGA 60-2), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 900 (WXGA++), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+ 60) |
| Lamp Type |
200 W UHE (E-TORL) |
| Lamp Life |
ECO mode: Up to 5000 hours
Normal mode: Up to 4000 hours |
| Throw Ratio Range |
1.42 - 1.56 |
| Size (projected distance) |
For stacked configuration
White screen: 80" - 150" (8.2' - 15.4')
Silver screen: 80" - 120" (8.2' - 12.5') |
| Keystone Correction |
Automatic
White screen: Vertical/Horizontal: ±15 degrees
Silver screen: Vertical/Horizontal: ±10 degrees |
| Mac Connectivity |
Projector is Mac compatible via USB, DVI to HDMI or VGA adapter (not included) |
| Contrast Ratio |
Up to 5000:1 (Stack 3D) |
| Color Reproduction |
Full color (16.77 million colors) |
| Passive 3D Stack Function |
Yes |
| 3D Format |
Auto / Side-by-Side / Top & Bottom / 2D / Frame Packing |
| Lens Type |
Manual Focus / Manual Optical Zoom |
| F-number |
1.58 - 1.72 |
| Focal Length |
16.9 mm - 20.3 mm |
| Zoom Ratio |
1.0 - 1.2 Optical |
| Lens Cover |
Slide lens shutter (A/V mute slide) |
| Display Performance |
NTSC: 480 lines
PAL: 576 lines |
| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM |
| Interfaces |
Computer: D-sub 15 pin x 2
Component video: D-sub 15 pin x 1 (shared with computer 1)
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (L and R)
USB connector: Type B x 1 (USB display, audio and mouse control, stack 3D control)
USB connector: Type A x 1 (USB memory/document camera, stack 3D control)
HDMI x 1
Serial: RS-232c x 1
Monitor out: D-sub 15 pin x 1 (shared with computer 2)
Audio out: Mini stereo x 1 |
| Speaker |
Two x 2 W monaural |
| Standby Audio |
Through Audio Out only |
| Operating Temperature |
41deg. to 95deg. F (5deg. C to 35deg. C) |
| Power Supply Voltage |
100 - 240V ±10%, 50 / 60Hz |
| Power Consumption |
ECO mode: 237 W
Normal mode: 289 W
Communication on: 3.2 W standby
Communication off: 0.36 W standby |
| Fan Noise |
ECO mode: 32 dB
Normal mode: 39 dB |
| Security |
Kensington security lock port
Padlock
Security cable hole
Password protect function |
| Remote Control: Operating Angle |
Right / Left: ±30 degrees
Upper / Lower: ±15 degrees |
| Remote Control: Operating Distance |
19.7' (6 m) |
| Dimensions (WxDxH) |
Single: 12.8x9.6x3.1" / 32.51x24.38x7.87cm
Dual Stacked: 14.6x13.8x8.8" / 37.08x35.05x22.35cm |
| Dual Stacked Weight |
17.4lbs / 7.89kg (includes mount and polarizing filters) |
