Item Includes
IS-1 Camera - 4xAA type Alkaline Batteries - Shoulder Strap - USB cable (Mini-B) - A/V cable - Lens cap - Lens cap holder - Lens hood - CD-ROM1 with: USB Driver, FinePixViewer (Raw File converter included), ImageMixer VCD2 LE for FinePix, RAW File Converter LE - CD-ROM2 with: Hyper Utility Software - CD-ROM3 with: Owner's Manual (PDF file) - Fujifilm Warranty (Note: IR and IR Cut filters are optional. Camera photographs in combined visible and IR light - image takes on a pinkish appearance)
|
Description
· Fujifilm does it again with the follow-up to the popular S3 Pro UVIR camera.
· The IS-1 is a specially modified Neo-SLR digital camera with a built-in 10.7x zoom that helps reduce dust common in interchangeable lens SLR's. This camera is more suited to the point and shoot needs of forensic or scientific photographers, yet retains some of the basic features that made the S3 Pro UVIR so popular. The technology designed into the Fujifilm IS-1 was initially designed for traditional visible wavelength imagery. However, the natural low noise signature of the Fujifilm Super CCD produces high quality, high resolution images within a limited band of Visual to Infrared. Because of the wide range of light spectrums captured, focusing and exposure are often done manually. However if enough visible light is available auto focusing will work.
· Unfiltered color images will retain a pink hue due to the added presence of increased red and infrared light captured. A great deal of this cast can be eliminated by adding a hot mirror filter or UVIR cut filter to remove the presence of IR light.
Fujifilm IR UV Sensitive Digital Camera Firmware End User License Agreement (ULA)
By breaking the seal of the camera you acknowledge acceptance of Fujifilm's Ultraviolet (UV) and or Infrared (IR) sensitive digital camera firmware End User License Agreement. The cameras firmware contained in this system package is fully activated to engage the camerasUV and or IR abilities and ready for use. No other firmware modifications are necessary to activate the cameras UV and or IR wavelength sensitive CCD. THIS LICENSE IS NON TRANSFERABLE
You hereby acknowledge that your use of this camera's IR and UV light energy sensitive abilities as enabled by Fujifilm's camera firmware will be purely for; professional portrait, medical, academic, scientific, forensic, law enforcement OR fire investigative photographic activities. In addition, you further agree not to use the camera's firmware enabled abilities to engage in unethical photographic conduct involving the violation of ANYONE'S PERSONAL privacy, child endangerment, lewd photography, and orpaparazzi like activities. |
Features
 |
Fujifilm Super CCD sensor with 9.0 million effective pixels sensitive to both visible & infrared light, (approx. 400 nm - 900 nm). |
|
Fujifilm RP (Real Photo) Processor. |
|
Intelligent flash system. |
|
New 28mm - 300mm (10.7x) Fujinon zoom lens with manual twist barrel zoom control. |
|
Class leading sensitivity setting of ISO 1600 at full resolution for photography in low light conditiuons. |
|
Low sensitivity setting of ISO 80 for ultra high quality photography. |
|
2.0" tilting LCD screen for easy to see high & low angle shooting. |
|
Ultra fast responce times, 0.01 second shutter lag and 0.8 second start up. |
|
Real time histogram to assist exposure settings before shooting. |
|
Highlight warning feature for displaying highlight areas in playback. |
|
VGA movie capture of 30 frames per second with zoom capability & sound. |
|
Closed unit design to eliminate dust accumulation on the CCD |
|
Hot shoe & PC sync terminal. |
|
Hyper Utility Software HS-V2 version 3 for RAW format shooting. |
|
Accepts xD Picture Card, Compact Flash & Microdrive Memory Cards. |
Specifications
| CCD Sensor | 1/1.6-inch Super CCD HR |
| Number of Effective Pixels | 9.0 Million Pixels ( Visible - IR 400nm 900nm) |
| Number of Recorded Pixels | Still image: 3,488 x 2,616 / 3,696 x 2,464 (3:2 format) / 2,592 x 1,944 / 2,048 x 1,536 / 1,600 x 1,200 / 640 x 480 pixels
Movie: 640 x 480 pixels (30 frames/sec.), 320 x 240 pixels (30 frames/sec.), with monaural sound |
| Storage Media | Slot No. 1: xD-Picture Card (16MB to 2GB) Slot No. 2: CF Card and MicroDrive (compatibility listed on Fujifilm website: http://www.fujifilm.com/products/digital) |
| File Formats | Still image: JPEG (Exif Ver. 2.2), CCD-RAWMovie: AVI (Motion JPEG), (Design rulefor Camera File system compliant / DPOF-compatible) |
| Lens | Fujinon 10.7x zoom lens, (F 2.8 - 4.9) (58mm lens threads) |
| Lens Focal Length | f=6.2 - 66.7mm/Equivalent to 28 - 300 mm on a 35 mm camera (IR and IR Cut Filters are Optional - 58mm) |
| Aperture Range | F 2.8 - F11, 13 steps in 1/3 EV increments Manual/Auto selectable |
| Digital Zoom ratio at Shooting | Approx. 2.0x (10.7x optical zoom lens is used together: Max. zoom scale: 21.4x) |
| Focus | Auto focus (Area, Multi, Center)/Manual focus/Continuous AF AF assist illuminator available, Effective range: up to 3.5m (Wide angle) |
| Focus Distance | Normal Approx. 1.3 ft. to infinity (wide), 6.6 ft. to infinity (telephoto)
Macro Approx. 3.9 in. to 9.8 ft. (wide), 3.0 ft. to 9.8 ft. (telephoto)
Super Macro Approx. 0.4 in. to 3.3 ft. (wide angle only) |
| Exposure Control | 256-zone TTL metering-Multi/Spot/Average |
| Exposure Modes | Programmed AE, Aperture Priority AE, Shutter Priority AE, Manual |
| Sensitivity | AUTO/ Equivalent to ISO 80/100/200/400/800/1600 (Recommend 200 or higher for IR photography) |
| Shutter Speed | 1/4 sec. to 1/4000 sec. (Auto/Picture Stabilization/Natural Light/Portrait/Landscape) Night: 4 sec. to 1/500 sec. P/S/A: 4 sec. to 1/4000 sec., M: 30 sec. to 1/4000 sec. Bulb (Up to 30 sec.) |
| White Balance | Automatic
Manual: Fine, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light, Custom (2 types) |
| Flash /visible light situations only | Auto flash
Effective range: Wide angle: Approx. 1.0 ft. to 18.4 ft.
Telephoto: Approx. 3.0 ft. to 9.8 ft.
Flash mode: Auto, Red-eye Reduction, ForcedFlash, Suppressed Flash, Slow Synchro, Red-eye Reduction + Slow Synchro |
| Flash Mode/visible light situations only | Auto, Red-eye Reduction, Forced Flash, Suppressed Flash, Slow Synchro, Red-eye Reduction + Slow Synchro |
| Effective Range (Auto Flash) | Effective range: Wide angle: Approx. 1.0 ft. - 18.4 ft. / Telephoto: Approx 3.0 ft. - 9.8 ft. |
| Self-timer | Approx. 2/10 sec. delay |
| Electronic Viewfinder | 0.44-inch Low temperature poly-silicon TFT (approx. 235,000 pixels), Approx. 100% coverage |
| LCD Monitor | 2.0-inch Low temperature poly-silicon TFT (approx. 235,000 pixels), Approx. 100%coverage |
| Video Output | NTSC/PAL selectable |
| Digital Interface | USB 2.0 high-speed |
| Power Source | 4xAA type alkaline batteries (included), 4xAA type Ni-MH rechargeable batteries (optional) or AC power adapter AC-5VX (optional) |
| Dimensions | 5.0 (W) x 3.7 (H) x 5.1 (D) in. |
| Weight | 22.9 oz. (excluding batteries and xD-Picture Card) |
| Shooting Modes | Normal: Auto, Scene Position (Picture Stabilization, Natural Light, Portrait, Landscape, Night)
Continuous: 1. Top-4: Max. 1.5 frames / sec. up to 4 frames 2. Final- 4: Max. 1.5 frames / sec. up to 4 frames 3. Long-period: Max 1.1 frames / sec up to 40 frames. |
| High Speed Shooting | Yes |
| Color Modes | Standard/Chrome/B&W |
| Movie Recording | 640 x 480 pixels, 30 frames/sec.
320 x 240 pixels, 30 frames/sec.
With monaural sound, AVI format (Motion JPEG), Direct recording to the media |
| Playback | Single frame, 9 Multi-frame, Exposure information with histogram, Sorting by date, Image rotate, Trimming, Automatic Playback. Navigation screen on playback zoom. |
| Voice Memo | Up to 30 seconds, WAV format |
| | |
|
