Iogear 8-Port VGA CAT5e/6 Audio/Video Splitter
Iogear

Iogear 8-Port VGA CAT5e/6 Audio/Video Splitter

SKU: IGGVS148TX MFR: GVS148TX
What's Included
What's Included With This Item:
  • Iogear 8-Port VGA Audio/Video Splitter
  • 1 x Power Adapter
  • 1 x Rack Mount Kit
  • 1 x Foot Pad Set (4pc)
  • 1 x Grounding Wire
  • 1 x Quick Start Guide
  • 1 x Warranty Card
  • Iogear 3 Years Limited Warranty
Write a Review
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 / 212-741-0052

Our Price

$229.95
Qty:

Add to Wishlist
OverviewFeaturesTech Specs
Its never too late...Click by 8! Same day shipping.

About this item

The GVS148TX VGA Audio/Video Splitter from Iogear utilizes CAT5e/6 cables to output video and audio signals from a single source to eight monitors or displays. The more impressive feature of the GVS148TX is that it can output the video and audio signals to those eight monitors or displays from over 900 feet away. Operating with a bandwidth of 225MHz allows for the transmission of large amounts of information at a very high rate of speed capable of high resolution settings of up to 1920x1200. The GVS148TX can maintain this data transfer bandwidth for over 300m (990ft).

What's Included With This Item

  • Iogear 8-Port VGA Audio/Video Splitter
  • 1 x Power Adapter
  • 1 x Rack Mount Kit
  • 1 x Foot Pad Set (4pc)
  • 1 x Grounding Wire
  • 1 x Quick Start Guide
  • 1 x Warranty Card
  • Iogear 3 Years Limited Warranty

Key Features

  • Split and extend 1 VGA source with audio over 4 VGA monitors and powered speakers via CAT5e/6
  • High resolution 1920x1200 @ 60Hz
  • Provides local VGA video and 3.5mm audio port
  • Supports up to 225MHz bandwidth
  • Built-in 8KV / 15KV ESD protection
  • Plug-n-Play

Technical Specs

Chassis Metal
Resolution Max. 1920x1200 @ 60Hz (492ft/150m)
Max. 1280x1024 @ 60Hz (984ft/300m)
Video Input 1 x HDB-15 (Male)
Video Output 1 x HDB-15 (Female)
Audio Input 1 x 3.5mm Mini Audio Jack (Green)
Audio Output 1 x 3.5mm Mini Audio Jack (Green)
Power Adapter DC Power Jack
Voltage Input 100 - 240V
Voltage Output 5V
Dimensions (W x H x D) 7.8 x 1.8 x 3.0" (19.7 x 4.5 x 7.6 cm)
Weight 1.4 lb (0.6 kg)
