Iogear 8-Port VGA Video Splitter for Analog Displays

Iogear
SKU: IGGVS78 MFR: GVS78
Iogear 8-Port Monitor Cable: Picture 1 thumbnail Iogear 8-Port Monitor Cable: Picture 2 thumbnail

Our Price

$44.95
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Iogear 8-Port Monitor Cable: Picture 1 regular $44.95

About Iogear 8-Port Monitor Cable

The GVS78 is an 8-port VGA video splitter and a signal booster with Iogear's patented VSE (Video Signal Enhancement) Technology. It is the best choice for splitting and carrying a video signal to more that one display with the same quality as the original signal. The GVS78 VGA Video Splitter is used to take video input from a single source and direct it to eight video outputs for monitors using analog signals.

The signal boost obtained by using Iogear's patented VSE (Video Signal Enhancement) Technology allows you to not only split the signal but it also amplifies the video signal to increase the transmission distance to about 215 feet away. This is no small feat, your average VGA card, over a standard VGA cable, sends a clear VGA signal approximately 25 feet.

Operating with a bandwidth of 300MHz (300 million cycles per second) that is 50 times greater than a simple TV signal. The high bandwidth allows for the transmission of large amounts of information at a very high rate of speed, thus allowing for the use of high resolution settings upwards of 1920 x 1440 in 24- or 32-bit true color mode.

Iogear 8-Port Monitor Cable Features

  • Stream a single video source to 8 separate VGA monitors
  • Ultra High 300MHz Bandwidth Superior video quality, maintains highest signal strength in all applications up to 1920 x 1440
  • Includes Iogear's patented VSE (Video Signal Enhancement) Technology, which amplifies video signal strength throughout your desire set-up
  • Amplifies video signals increasing transmission distance up to 215 feet
  • Supports up to 8 VGA monitors
  • Cascadable; allows you to expand your video splitter set up beyond 8 displays
  • Hassle free, no software to install, instant installation and use
  • Hot-Plug capability, Hot-Swappable, Plug-n-Play
  • Compact design for easy placement
  • Supports DDC, DDC2, DDC2B at Port 1

Iogear 8-Port Monitor Cable Specifications

Video connections
Input: 1 x HDB-15 Male
Output: 8 x HDB-15 Female
LEDs
Power On: 1
VGA Bandwidth (-3db)
300MHz
Video Resolution
1920 x 1440 at 60 Hz
Signal Type
VGA, SVGA, XVGA, USXGA and Multi-sync
Cable Distance
65m (214.5ft)
Cascade
3 Level
Power Consumption
3.94W (Max)
Power
Voltage: DC 9V
Environment
Operation Temperature 0 - 50C
Storage Temperature: -20 - 60C
Humidity: 0 - 80% RH; Non-condensing
Housing Case
Plastic
Requirement
Video source with VGA (HDB-15) connection
Displays with VGA (HDB-15) connection
Dimensions
8.5" x 2" x 3.75"/ 22 x 5.08 x 10cm
Weight
1lbs/ 0.45kg
Mfr #
GVS78
SKU
IGGVS78
