IOGEAR Wireless-N USB 2.0 Adapter
See all Iogear items

IOGEAR Compact Wireless-N USB 2.0 Adapter, 300Mbps Data Rate, 802.11n Support

SKU: IGGWU625
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

IOGEAR Wireless-N USB 2.0 Adapter Specifications

  • Power Consumption

    Transmit: < 380mA
    Receive: < 250mA

  • Operating Temp

    32 to 122deg. F (0 to 50deg. C)

  • Storage Temperature

    14 to 158deg. F (-10 to 70deg. C)

  • Humidity

    5-90%, Non-Condensing

  • Transmission Power

    17dBm

  • Frequency Band

    2.4 to 2.483GHz Unlicensed ISM Band

  • Modulation

    IEEE 802.11n: BPSK, QPSK, 16-QAM, 64-QAM

  • Data Rate

    IEEE 802.11n: 6, 9, 12, 18, 24, 36, 48, 54, 60, 90, 120, 180, 240, 270, and up to 300Mbps

  • Interface

    USB 2.0, Backward Compatible with 1.1 and 1.2

  • Security

    64-bit or 128-bit WEP/WPA TKIP

  • Management

    Windows-Based Utility

  • Operating Range

    330 to 1320 feet (100 to 400 m) Dependent on Environment

  • Encryption

    64-bit or 128-bit WEP, TKIP, AES

  • Antenna Type

    On-Board Chip Antenna

  • POP

    10'' Peg Hook: 3
    6'' Peg Hook: 2

  • System Requirements

    Windows XP, Vista, or 7
    Mac OS X 10.4 and Above
    Linux Fedora 10 (Kernel 2.6.27.5-117)
    Available USB Port
    Wireless Network

  • Dimensions (W x H x D)

    2 x 1 x 0.25 inch (51 x 25 x 6mm)

  • Weight

    0.3 oz (9g)

  • UPC Code

    881317507600

About IOGEAR Wireless-N USB 2.0 Adapter

The IOGEAR Compact Wireless-N USB Adapter allows you to connect your laptop or desktop to any Wireless-N network in your home or office. The Wireless-N (IEEE 802.11n) USB 2.0 Adapter is the perfect solution for those users who want to upgrade older computers to the next generation of wireless technology.

Using dual antennas (1T2R) this product provides data rates up to 300Mbps and reduces Wi-Fi dead zones in your wireless environment. This new standard supplies sufficient bandwidth for faster file transfer, music downloads, video streaming, on-line gaming & HD multi-media applications. In addition to the increased speed and coverage, you will be pleased to know that it is compatible with your existing 802.11b and 802.11g routers and access points. The unit also features a WPS (Wi-Fi Protected Setup) button. This button assures quick and secure network setup.

IOGEAR Wireless-N USB 2.0 Adapter Features

  • Add high-speed Wireless-N (802.11n) Internet access to any USB enabled computer
  • 1T2R multiple radio technology improves effective throughput and range over existing 802.11 b/g products
  • Compact and portable adapter plugs into your computer's USB port
  • Compatible Network Standards: IEEE 802.11n (up to 300Mbps) IEEE 802.11g (up to 54Mbps) IEEE 802.11b (up to 11Mbps)
  • Push-button Wi-Fi Protected Setup (WPS) simplifies secure and easy wireless configuration
  • WEP,TKZP, AES, WPA and WPA2 hardware encryption schemes
  • Frequency Band Modulation Method: QPSK / BPSK / 16-QAM / 64-QAM
  • Supports Ad Hoc and Infrastructure modes
  • Supports USB 2.0 with up to 300Mbps transfer rate; backward compatible to USB 1.1 and 1.2
  • Compatible with Microsoft Windows, Mac or Linux OS

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Add high-speed 802.11n to any Ethernet enabled device
  • 1T2R multiple radio technology
  • Compact and portable adapter plugs into your computer's USB port
  • Compatible Network Standards
  • Push-button Wi-Fi Protected Setup (WPS)
  • WEP,TKZP, AES, WPA and WPA2 hardware encryption schemes

What's in the box:

  • IOGEAR Compact Wireless-N USB Adapter
  • 1 x Driver CD
  • 1 x Quick Start Guide
  • 1 x Warranty / Registration Card
  • IOGEAR 3 Year Limited Warranty
